140m 4 Port USB 2.0 Cat.6 Extender

User Manual English

Benutzerhandbuch Deutsch

Manuel Utilisateur Français

Manuale Italiano

No. 42710

lindy.com

Tested to comply with

FCC Standards

For Home and Oce Use!

User Manual English

Introduction

Thank you for purchasing the Lindy 140m 4 Port USB 2.0 Cat.6 Extender. This product has been designed

to provide trouble free, reliable operation. It benets from both a LINDY 2 year warranty and free lifetime

technical support. To ensure correct use, please read this manual carefully and retain it for future

reference.

This Lindy USB 2.0 Cat.6 Extender extends the distance between four USB peripheral devices and the

computer up to distances of 140m (459.31ft) using a single Cat.6 UTP or higher network cable and up to

120m (393.7ft) with a Cat.5e UTP/STP cable. Optionally, these distances can be doubled by use of a

signal repeater (No. 42709).

Package Contents

• Transmitter Unit (Tx)

• Receiver Unit (Rx)

• USB 2.0 A/B male cable (approximately 50cm)

• Multi-Country Power Supply, 5 2 A with DC connector 5.5/2.5 and adapters (EU, UK, US, DC V .6 mm

AUS)

• 2 sets with 4 screws & 4 dowels for transmitter and receiver

• This Manual

Features

• Supports USB 2.0 high-speed and USB 1.1 (full-speed, low-speed) devices

• Integrated four port USB hub

• Supports distances up to 14 (459.31ft) using low cost Cat.6 (or better) UTP cables 120m 0m and

(393.7ft) with low cost Cat.5e UTP/STP cables

• The max. distance can be doubled up to 240m (787.39ft) or 280m (918.62ft) by using the signal

repeater No. 42709

• Green LED for power and blue LED for visual confirmation of a successful link

• Supports all major Operating Systems with USB support

• Transmitter and Receiver units both feature integrated mounting brackets

Specication

• Transmitter: Input Port 1x USB 2.0 Type B, Output Port 1x RJ45

• Receiver: Input Port 1x RJ45, Output Port 4x USB 2.0 Type A, DC Socket for PSU 5.5/2.5mm

• Dimensions: Tx: 120x67x27mm (4.72x2.64x1.06in) Rx: 130x67x27mm (5.12x2.64x1.06in) ,

• Weight: Tx: 0.19kg (0.42lb), Rx: 0.21kg (0.46lb)

• Operating Temperature: 0° - 55°C (32°F - 131°F)

• Storage Temperature: -20°C - 85°C (-4°F - 185°F)

• Humidity: - 95% RH (non-condensing) 0

Installation

1. Connect the transmitter to a USB por o th host computer by using the included USB cable.t n e

2. Place the receiver unit near the USB device(s) in the desired remote location.

3. Connect the power adapter to the receiver unit.

4. Connect the transmitter to the receiver unit by using a Cat.5e/6 (or better) cable (not included).

5. The Extender is now correctly installed and the USB devices can be connected.

Produktspecifikationer

Varumärke:	Lindy
Kategori:	Wifi-repeater
Modell:	42709
Vikt:	162 g
Bredd:	67 mm
Djup:	110 mm
Höjd:	27 mm
Förpackningens bredd:	115 mm
LED-indikatorer:	Ja
Certifiering:	CE, FCC, RoHS & REACH, CP65
Modell:	Nätverksrepeater
Uteffekt:	2.6 A
Kabeltyper som stöds:	Cat5e, Cat6
Produktens färg:	Svart
bruksanvisning:	Ja
Förpackningstyp:	Låda
Låddjup:	115 mm
Vikt inkl. förpackning:	300 g
Antal per förpackning:	1 styck
Antal LAN (RJ-45) anslutningar:	2
Temperatur vid drift:	0 - 55 ° C
Temperaturintervall (förvaring):	-20 - 85 ° C
Intervall för relativ operativ luftfuktighet:	0 - 95 %
Hållbarhetscertifiering:	RoHS
Utgångsspänning:	5 V
Material, hölje:	Gjuten aluminium
Likströmsingång:	Ja
AC-adapter inkluderad:	Ja
Harmonized System (HS)-kod:	85176990
Kretsar:	AST1620
Faktisk dataöverföringshastighet:	480 Mbit/s
Maximal överföringshastighet avstånd:	280 m
Typer av nätkontakter som ingår:	EU, UK, US
