Sida 1/5

TABLE

OF CONTENTS

1. What is the Linksys LGS116P Switch?

2. What is PoE?

3. What kind of devices can be connected to the switch?

4. What should I do when my computer cannot connect to the Internet while

connected to the switch?

5. What is the advantage of having a switch when it comes to data transfer?

6. What is the maximum PoE power budget for each PoE switch?

7. What are the protocols supported by the LGS116P?

8. Can I wall-mount my switch?

9. What should I do if my switch experiences excessive data collisions?

10. Can I use a switch to share Internet connection to all computers in the

network?

11. Which ports on my PoE switch can I plug in a PoE device?

12. How is port PoE prioritization done?

13. What is the warranty period for the Linksys LGS116P?

14. What are the supported PoE standards?

15. My PoE device is not powering ON, what should I do?

1. What is the Linksys LGS116P Switch?

The Linksys LGS116P is a 16-Port Gigabit PoE Switch. This unmanaged switch offers

a quick and easy solution to extend your office network with a plug-and-play

installation. It is also useful in transferring data across a local network at up to Gigabit

speeds.

2. What is PoE?

Power over Ethernet (PoE) is a technology that enables an Ethernet network cable to

deliver both data and power.

3. What kind of devices can be connected to the switch?

You can connect the following devices to your LGS116P switch:

LGS116P Frequently Asked Questions

Computers

Routers

Switches

Network Printers

Other network devices

4. What should I do when my computer cannot connect to the Internet while

connected to the switch?

Follow the steps provided below to resolve this issue:

Verify if LEDs are properly lit on the switch.

System LED - Blue

Link/Act/GB – Green-Amber

PoE Max - Amber

PoE - Green

Power down everything and power ON the switch first. Next, power ON the

computer.

NOTE: DHCP capabilities Only routers or modems with can allow sharing of Internet

connection between computers.

5. What is the advantage of having a switch when it comes to data transfer?

The switch acts as a repeater which regenerates data signals as they pass through it.

This feature acts as a safeguard to deter data loss and ensure that transmissions arrive

securely at their destinations. Moreover, a switch is capable of intelligent filtering of

data based on source and destination as compared to the repeater which can only

regenerate the signal without checking its recipients.

6. What is the maximum PoE power budget for each PoE switch?

The Linksys LGS116P has dedicated PoE power budget for the entire switch. 80 Watts

7. What are the protocols supported by the LGS116P?

The Linksys LGS116P switch is compliant with IEEE 802.3, 802.3u, 802.3x, 802.3ab,

and 802.3az standards.

8. Can I wall-mount my switch?

Yes, the Linksys LGS116P can be wall-mounted.

9. What should I do if my switch experiences excessive data collisions?

Verify if your network cabling is securely crimped and installed properly.

10. Can I use a switch to share Internet connection to all computers in the

network?

No. The switch is not capable of sharing Internet connection across the network.

However, what it does is it allows more computers to be connected to a local network.

NOTE: DHCP capabilities Only routers or modems with can allow sharing of Internet

connection between computers.

11. Which ports on my PoE switch can I plug in a PoE device?

You can plug the PoE device to the switch’s . first eight (8) ports (1-8)

12. How is port PoE prioritization done?

The switch has a feature called where power is provided based onPoE prioritization

port priority for PoE devices connected to the PoE ports. This follows the criteria

below:

a. Port ID1 has higher priority.

b. The higher the Port ID, the lower the priority.

c. Rebooting the switch reprioritizes PoE per port.

NOTE: This is only applicable for those ports that have a PoE device connected to it.

An example is if all seven (7) PoE devices have maxed out the power budget on the

switch. When an eighth PoE device connects, since it exceeds the power budget, the

connection is declined and Port 8 will not provide power to a PoE device. However

unplugging Port 1 will then provide power to Port 8 for the PoE device connected to it.

QUICK TIP: If the device is a non-PoE device this behavior does not apply.

If the PoE device is reconnected back to Port 1, Port 1 remains OFF. In order to

restore power to Port 1 for the PoE device either unplug PoE device from Port 8 or

reboot the switch. Rebooting the switch prioritizes PoE for each port all over again.

13. What is the warranty period for the Linksys LGS116P?

Linksys LGS116P has a limited lifetime warranty.
