Features

Comply with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3az, IEEE802.3af/at standards

Support IEEE802.3x full-duplex flow control; support Auto MDI/MDIX

24 Ports support 48V-56VDC power to PoE powered devices

Provide 15.4W or 30W power to powered devices

2 Combo Uplink port: 10/100/1000Mbps RJ-45 or 1000Base-x optical fiber port SFP

420 watts PoE budget

PoE data & power transmission distance up to 100meters

Excellent anti-thunder, anti-static and anti-interference ability

Support 10K lenght Jumbo frame transmission

Restart function helps master IC reset whoolly

Built-in 420W power supply

Easy and convenient to use, plug & play, no need to configure

Galvanized housing for stable and durable working life

Front panel

1.Rack-mounting ears: Cabinets for product installation or Wall installation

2.Power Indicator: Red Light on: with power; Light off: no power

3.PoE Indicator: Yellow Light on: when device is powered

Light off: when device is not detected or not powered

4. Link/ Act Indicator: Green LED on: link up off: link down blinks: data transfer

5. Reset Button: Whole machine will restart while press button

6.Uplink SFP port: Speed 1000Base-X, transfer data from PoE ports to other devices

(NVR/Switch /ADSL)

7.Uplink Gigabit RJ45 port: Transfer data from PoE ports to other devices (NVR/Switch

/ADSL)

7. Downlink port: Transfer data from other IP devices to the switch

Rear panel

1. Input:AC 96264V~

2. Power Switch: Turn on with power, Turn off no power

3. Waiting Content

5. Ground Connection

6. Fuse: Max 10A

visit our website

www.machpower.it

USER MANUAL SW-UF24P2G2SV-063
