Sida 1/12

PF 0300 - PF 0800

PF 0403 - PF 1100

Submersible Pump

ESMX

Bomba Sumergible

OPERATING INSTRUCTIONS

ESMX

INSTRUCCIONES DE

OPERACIÓN

Submersible Pump

ENGLISH (Original instructions)

1. Safety measures

Carefully read the operating instructions before assembling

and starting. The appliance must not be used by persons

who are not thoroughly acquainted with the instructions

handbook (operating instructions). Children and persons

under the age of 16 cannot use the pump and must be kept

well away from the appliance when it is connected.

The user is liable towards third parties in the area where

the appliance is in operation.

This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

While the pump is operating persons

must not be in the liquid to be pumped.

The pump may be connected only by

means of a safety switch for fault currents, with

a rated opening current up to 30 mA and a socket

with an earth contact installed in conformity with

the regulations.

Protection: at least 10 A

Operation in swimming pools and garden ponds is

admitted.

For other operation, the provisions in conformity with

the standard VDE 0100 part 702 must be respected.

CAUTION: Before checking, connect the pump and

the system with no voltage!

Replacing the line connecting up with the mains

requires using special tools and therefore may be done

only by the manufacturer or its service engineers.

The pump may operate only with a pipe connecting the

appliance (extension) that is no lighter than a rubber

hose mod. H07 RNF in conformity with the DIN 57282

or DIN 57245 standard.

(For your safety)

The voltage (120 Volts alternating current)

indicated on the pump’s rating plate must

correspond to the available mains voltage.

Before starting it is necessary to make sure by having a

check made by qualied personnel that there are the

necessary electrical protection measures.

• Earth connection.

• Earthed neutral.

• The safety switch for fault currents corresponds to the

safety regulations of the electricity board and functions

perfectly.

• Plug connections must be protected from water. If there

is a risk of ooding, plug connections must be placed

somewhere safe.

• Denitely avoid pumping aggressive liquids and abrasive

products.

In the event of the pump failing, repair work may only

be carried out by the repair workshops of the technical

service. Only genuine spare parts must be used.

It is notied that in conformity with the law on product

liability

we cannot be held responsible

for the damage caused by our appliance:

a) because of improper repairs not carried out by the

personnel of the assistance points authorized by us;

b) or if GENUINE SPARE PARTS are not used to replace

parts;

c) or if the indications and provisions given in the

instructions handbook are not complied with.

The same provisions hold for the accessories.

Resistance

The maximum temperature of the delivery liquid should

never exceed +35°C in continuous operation.

Inammable, combustible or explosive liquids cannot

be conveyed with this pump!

In particular, do not use engine fuels, detergents, or other

chemical products.

2. Use

CAUTION! Sector of use

“DRAINAGE” – To transfer and empty fresh to

slightly polluted water from rainwater barrels and

casks.

“VORTEX” – Portable submersible pump

for discharge and waste water with solids in

suspension.

Also used as emergency pump, in case of

overowing with muddy water, thanks to its large

suction lter.

To achieve excellent motor cooling the pump

casing is provided with a breather hole that enables

water to ow out.

The pump must be protected from running dry.

Starting

First put the pump into water and then

connect the plug.

The pump is ready for use.

Note: pollution of liquid could occur due to leakage of lubricant.

Produktspecifikationer

Varumärke:	Makita
Kategori:	Vattenpump
Modell:	PF0300
Vikt:	4230 g
Bredd:	168 mm
Djup:	160 mm
Höjd:	305 mm
Korrekt användning:	Dränering
Produktens färg:	Black, Blue
Effekt:	300 W
AC-inspänning:	230 V
Internationellt skydd (IP) kod:	IPX8
Strömkälla av typen:	AC
Växelström Frekvens:	50 hz
Ström:	1.5 A
Front speaker type:	- Bar
Maximal inmatningskapacitet vattentemperatur:	35 ° C
Maximal leverans höjd:	- m
Flöde:	- l/h
Tryckhöjd:	7 m
