Manhattan 460873 Bruksanvisning

Manhattan Streckkodsläsare 460873

Läs gratis den bruksanvisning för Manhattan 460873 (72 sidor) i kategorin Streckkodsläsare. Guiden har ansetts hjälpsam av 8 personer och har ett genomsnittsbetyg på 4.8 stjärnor baserat på 4.5 recensioner. Har du en fråga om Manhattan 460873 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/72

LONG RANGE

CCD

barcode

scanner

user

manual

MAN-460873-UM-0110-01

460873

Content

Introduction............................................................................ 1

1.1 General ...................................................................1

1.2 EMI certificated .......................................................1

1.3 Legislation and WEEE symbol ................................1

1.4 Pin Assignment .......................................................2

How to Configure................................................................... 3

2.1 Flow Chart............................................................... 3

2.2 General Process .....................................................3

2.3 Start Over ................................................................4

2.4 Recall ......................................................................4

2.5 Set All Default.......................................................... 4

2.6 Version Information .................................................4

Operation............................................................................... 5

3.1 Beeper Option ......................................................... 5

3.2 Output Characters ................................................... 5

3.3 Reverse Output Characters ....................................7

3.4 Upper/Lower Case ..................................................7

3.5 Interscan Code Delay..............................................8

Code Type ...........................................................................10

4.1 Code Selection......................................................10

4.2 Bar Code ID ..........................................................14

4.3 User Define Code ID ............................................. 15

4.4 UPC/EAN/JAN ......................................................17

4.5 Code 39.................................................................19

4.6 Code 128...............................................................22

4.7 Interleave 25 .........................................................24

4.8 Industrial 25...........................................................26

Content

4.9 Matrix 25 ...............................................................28

4.10 CODABAR/NW7 .................................................29

4.11 Code 93 ............................................................... 32

4.12 Code 11 ............................................................... 33

4.13 MSI/PLESSEY Code...........................................35

4.14 Code 2 of 6..........................................................37

4.15 Telepen................................................................ 38

4.16 LCD 25 ................................................................40

4.17 RSS-14................................................................41

4.18 RSS Limited ........................................................42

4.19 RSS Expanded....................................................43

PREFIX/SUFFIX..................................................................44

5.1 Standard Suffixes ..................................................44

5.2 Insertion Data........................................................45

5.3 Deletion Data.........................................................51

Appendix .............................................................................57

A-Decimal Value..........................................................57

B-ASCII Table.............................................................. 58

C-Function Key Table..................................................67

Produktspecifikationer

Varumärke:	Manhattan
Kategori:	Streckkodsläsare
Modell:	460873
Vikt:	351.5 g
Bildsensortyp:	CCD
Maximal räckvidd:	20 m
Standardgränssnitt:	RJ-45, USB
Ljuskälla:	Red LED
Skanningshastighet:	270 sek/sida
Arbetsavstånd:	300 mm
Produktens färg:	Svart
Produktstorlek (BxDxH):	177 x 89 x 25 mm
Material, hölje:	Plast
Avkodningsstandard:	UPC/EAN/JAN + Addon 2/5, Code 39, Code 39 ASCII, Code 11, Matrix 25, Code 128, Code 93, Interleave 25, Industrial 25, Codabar/MW7, MSI/PLESSEY, China Postage, Code2 /6, LCD25, Telepen, GS1 DataBar
