Sida 1/26

MAN-525503/525534-UM-0413-01

WIRELESS N

USB ADAPTER

USER MANUAL

INTRODUCTION

Thank you for purchasing this Manhattan

™

Wireless N USB Adapter.

Because many netbooks and laptops (especially those more than a couple of

years old) no longer feature the latest in wireless networking technology —

offering Wireless G that maxes out at speeds of 54 Mbps, for example — this

Wireless N Adapter is great for upgrading the wireless capabilities of your PC,

with enhanced link speeds.* Accelerated speeds will enhance how you watch

streaming media, play online games and experience the Internet. Meanwhile,

improved range and signal delity mean you will encounter fewer “dead spots” in

your home or ofce.**

Both of these adapters connect easily through an available USB port on your PC,

and the included software walks you through the conguration process so you

can take advantage of the many features, such as Wi-Fi Protected Setup (WPS)

and WEP, WPA and WPA2 data encryption.

Manhattan is also proud to present these products with our Three-Year Warranty.

For a complete list of country-specic warranties and their details, visit our

website: manhattan-products.com/warranty.

Package Contents

• Wireless N USB Adapter

• Software CD with user manual

• Quick install guide

System Requirements

• Notebook or Desktop PC with Pentium 1 GHz-compatible processor or higher

• Windows XP/Vista or Windows 7/8

• Available Hi-Speed USB 2.0 type-A port

* Actual data throughput will vary. Network conditions and environmental factors — including

 volumeofnetworktrafc,buildingmaterialsandconstruction,andnetworkoverhead—lower

the actual data throughput rate.

** Environmental factors may adversely affect wireless signal range.

TABLE OF CONTENTS

1 Initial Setup....................................................................................................... 4

1.1 Installing the Driver and Utility.................................................................... 4

1.2 Connecting to a Wireless Access Point...................................................... 7

1.2.1 Using the Manhattan Utility................................................................ 7

1.2.2 Using the Windows AutoCong (Zero Conguration) Tool.............. ...8

2 Conguration Utility......................................................................................

2.1 General .................................................................................................... 12

2.2 Prole........................................................................................................ 13

2.2.1 Conguring the Prole................ ......................................................13

2.3 Available Network ....................................................................................

2.4 Status........................................................................................................ 16

2.5 Wi-Fi Protected Setup (WPS) .................................................................. 16

2.5.1 PIN Input Conguration........ .......................................................... 17

2.5.2 Pushbutton Conguration (PBC)..................................................... 18

2.6 Using the Wireless Adapter as as Access Point........................................ 20

2.6.1 Access Point Mode........................................................................ ...20

2.6.2 Virtual Wi-Fi Mode........................................................................... 24

Produktspecifikationer

Varumärke:	Manhattan
Kategori:	Nätverkskort/adapter
Modell:	Mini 300N
Bredd:	18.8 mm
Djup:	36.75 mm
Höjd:	9.5 mm
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Snabbstartsguide:	Ja
Certifiering:	FCC, CE
Gränssnitt:	WLAN
Värdgränssnitt:	USB
Bandbredd:	2.4 GHz
Maximal dataöverföringshastighet:	300 Mbit/s
Produktens färg:	Vit
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	0 - 60 ° C
Intervall för relativ operativ luftfuktighet:	10 - 95 %
Hållbarhetscertifiering:	RoHS
Kryptering/säkerhet:	128-bit WEP, 64-bit WEP, WEP, WPA, WPA2
USB-ström:	Ja
Anslutningsteknologi:	Trådlös
Modulator:	16-QAM, 64-QAM, BPSK, OFDM, QPSK
Kommunikationsstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Intern:	Nej
Tillgängliga dataöverföringshastigheter, WLAN:	11, 54, 300 Mbit/s
Wi-Fi-standard:	Wi-Fi 4 (802.11n)
Kretsar:	RTL8192SU
Minimikrav, processor:	Pentium 300MHz
Länk-/aktivitets-LED:	Ja
