Marantz Turret Bruksanvisning

Marantz mikrofon Turret

Läs gratis den bruksanvisning för Marantz Turret (40 sidor) i kategorin mikrofon. Guiden har ansetts hjälpsam av 29 personer och har ett genomsnittsbetyg på 4.9 stjärnor baserat på 15 recensioner. Har du en fråga om Marantz Turret eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/40

User Guide

English (2–8)

Guía del usuario

Español (9–15)

Guide d'utilisation

Français (16–22)

Guida per l'uso

Italiano (23–29)

Benutzerhandbuch

Deutsch (30–36)

Appendix

English (38–39)

User Guide (English)

Introduction

The Turret answers the need for a high-performance equipment package that includes everything

needed for streaming and podcasting. This system has a full HD webcam with built-in H.264 video

compression, a high-quality 48 kHz/16-bit USB condenser microphone with pop filter and an LED

light ring, daylight-balanced, with both cool and warm filter accessories. The Marantz Turret is a

unique, all-in-one broadcast system that gives any gamer, live Internet streamer or podcaster high-

quality components with a multitude of configurations for creating a professional presentation. It’s

compact and simple, perfect on a desktop and portable enough to take on location.

To make the system capable of handling any streaming/podcast task without the need for additional

equipment, Turret has a high-speed USB-C computer output for high speed and low latency, an

internal USB hub and an onboard headphone amplifier so audio monitoring is a snap. Everything the

demanding streaming/broadcasting enthusiast needs is right here, in one convenient, high-

performance package.

Please see this guide’s Setup chapter to learn how to integrate Turret with your audio system, and

then refer to the Operation chapter to start using Turret.

Box Contents

Tower

Base

Microphone

Pop Filter

Replacement Shockmount Bands

(3) Lighting Filters (Diffuse, Cool Diffuse, Warm Diffuse)

USB Type-C–to–Type-A Cable

Power Adapter

User Guide

Safety & Warranty Manual

Support

For the latest information about this product (documentation, technical specifications, system

requirements, compatibility information, etc.) and product registration, visit marantzpro.com.

For additional product support, visit marantzpro.com/support.

Setup

Connection

Items not listed under Introduction > Box Contents are sold separately.

1. Use the included power adapter to connect the Power Input to a power outlet.

2. Use the included USB cable to connect the USB Port labeled To PC to your computer.

3. Optional: Connect USB flash drives to USB Ports 1 and/or 2. You can to use your computer to

access these drives.

4. Optional: Use a 1/8” (3.5 mm) stereo audio cable to connect this output to the input of an

external mixer, speaker, etc.

5. Optional: Attach the desired lighting filter to the LED Ring Light. Use the Brightness knob to

adjust the brightness of the light ring around it.

Note: Remove the plastic film from the lighting filter before use.

6. Connect 1/8” (3.5 mm) stereo headphones to the Headphone Output. Use the Headphone

Volume knob to adjust the volume.

7. Use the Mix knob to adjust the balance between the microphone signal (Mic) and the signal

from your computer (PC) that you hear in the headphones.

8. Open your video or audio recording software, and select Marantz Turret as your computer’s

default playback and recording devices.

9. You’re now ready to start recording.

Produktspecifikationer

Varumärke:	Marantz
Kategori:	mikrofon
Modell:	Turret
Produkttyp:	Personligt videokonferenssystem
Vikt:	3500 g
Videoformat som stöds:	H.264
Videolägen som stöds:	720p, 1080p
Maximal bildfrekvens:	30 fps
Bildsensorstorlek:	- "
Maximal videoupplösning:	1920 x 1080 pixlar
Färgtemperatur:	5600 K
Antal personer:	- personer
Mikrofonfrekvens:	150 - 15000 hz
Inbyggt stativ:	Ja
Produktens färg:	Svart
HD-typ:	Full HD
AC-inspänning:	100 - 240 V
Strömkälla av typen:	AC, DC
Bildkomprimeringsformat:	MJPEG
Mikrofon känslighet (utnivå):	34 dB
Kamera inkluderad:	Ja
Megapixel:	2 MP
Mikrofon inkluderad:	Ja
Likströmsdriftspänning:	12 V
Streaming-kapacitet:	Ja
Lampteknik:	LED
Antal mikrofoner inkluderade:	1
Mikrofonens färg:	Svart
