Sida 1/18

WM2

AWM2P

™

MICROMODULE

20262 / 20101011 • AWM2P

LAUNAM RESU 3

2 © MARMITEK

ENGLISH

1. Phase clamp (230V)

2. Load clamp

3. Neutral clamps

4. Indicator light (LED)

5. Set up button

6. Wire connections to wall switches

MICROMODULE AWM2P

NEDERLANDS

1. Fase aansluiting (230V)

2. Aansluiting voor belasting

3. Nulklemmen

LED indicator

5. Programmeerknopje

Aansluitdraden voor schakelaars

3AWM2P™

ENGLISH

MARMITEK MICROMODULE AWM2P

Marmitek X-10 transmitter for 2 addresses with a built-in

appliance module.

SAFETY WARNINGS

• The wiring of your electrical installation is live (230 V) and

extremely dangerous. Never connect the module when plugged

into the mains. Always turn off the main switch before starting

the installation.

• This product is for professional use and should be installed by a

certified installer.

•

To prevent short circuits, this product should only be used inside and

only in dry spaces. Do not expose the components to rain or moisture.

Do not use the product close to a bath, swimming pool etc.

• Do not expose the components of your systems to extremely

high temperatures or bright light sources.

• In case of improper usage or if you have altered and repaired

the product yourself, all guarantees expire. Marmitek does

not accept responsibility in the case of improper usage of the

product or when the product is used for purposes other than

specified. Marmitek does not accept responsibility for additional

damage other than covered by the legal product responsibility.

• This product is not a toy. Keep out of reach of children.

• Do not open the product: the device may contain live parts.

The product should only be repaired or serviced by a qualified

repairman.

• A

utomatic switching devices provide comfort, but can also

be dangerous. They can surprise people or can ignite clothing

hanging over an electric heat source. Please be careful and take

appropriate measures to avoid accidents.

HOW DOES MARMITEK X-10 WORK?

rmitek X-10 components use the existing mains wiring to

communicate (using Marmitek X-10 signals). You can build a

complete system using the three different kind of components of

the Marmitek X-10 System:

Produktspecifikationer

Varumärke:	Marmitek
Kategori:	ej kategoriserat
Modell:	AWM2P
Spänning:	230 V
Ingångsfrekvens:	50 hz
Produktstorlek (BxDxH):	46 x 46 x 16 mm
Temperatur vid drift:	-10 - 35 ° C
Temperaturintervall (förvaring):	-20 - 70 ° C
Antal uttag AC:	- AC-utgångar
