MegaView 65/66

User manual

Gebrauchsanleitung

Guide utilisateur

Modo de empleo

Manuale d’istruzioni

Gebruiksaanwijzing

ai157313055341_1_MegaView 65 66 Front Usermanual_124x176.pdf 1 7-11-2019 13:42:33

MegaView 65/66™

ENGLISH

1 Table of contents

1 Table of contents ................................................................................................... 3

2 Safety warnings ..................................................................................................... 3

3 Introduction ............................................................................................................ 4

4 Package contents .................................................................................................. 4

5 CAT5e/CAT6 cable requirements ........................................................................... 4

6 Installation .............................................................................................................. 5

6.1 Setting signal strength ............................................................................................ 5

6.2 Installation IR return (MegaView 66™) ................................................................... 6

6.3 Usage .................................................................................................................... 6

7 Frequently asked questions ................................................................................... 7

8 Technical information ............................................................................................. 8

9 Notification ............................................................................................................. 9

9.1 Declaration of Conformity ....................................................................................... 9

9.2 Copyrights .............................................................................................................. 9

9.3 Recycling ............................................................................................................... 9

2 Safety warnings

Please read these instructions thoroughly before you use the device and keep

them for future reference.

• To prevent short circuits, this product should only be used inside and only in dry

spaces. Do not expose the components to rain or moisture. Do not use the

product close to a bath, swimming pool etc.

• Do not expose the components of your systems to extremely high temperatures or

bright light sources.

• Do not place the product in an enclosed space, such as a TV cabinet or

equivalent. Provide adequate ventilation to ensure that the product is functioning

properly and to protect against overheating.

• In case of improper usage or if you have altered and repaired the product

yourself, all guarantees expire. Marmitek does not accept responsibility in the

case of improper usage of the product or when the product is used for purposes

other than specified. Marmitek does not accept responsibility for additional

damage other than covered by the legal product responsibility.

• This product is not a toy. Keep out of reach of children.

• Do not open the product: the device may contain live parts. The product should

only be repaired or serviced by a qualified expert.

• Only connect the adapter to the mains after checking whether the mains voltage is

the same as the values on the identification tags. Never connect an adapter or

power cord when it is damaged. In that case, contact your supplier.

Produktspecifikationer

Varumärke:	Marmitek
Kategori:	AV extender
Modell:	MegaView 66
Höjd:	190 mm
Förpackningens bredd:	260 mm
Ljudformat som stöds:	PCM
Videolägen som stöds:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Maximal upplösning:	1920 x 1080 pixlar
Ljudsystem:	Stereo
HDCP:	Ja
Modell:	Sändare och mottagare för AV-utrustning
Bandbredd:	225 MHz
RJ-45 utgångsportar:	1
HDCP-version:	1.3
Antal HDMI-utgångar:	1
RJ-45 ingångsportar:	1
Driftspänning:	5 V
Sändarens mått (BxDxH):	82 x 67 x 21 mm
Sändarens vikt:	104 g
Kabeltyper som stöds:	Cat5e, Cat6
IR-förlängare ingår:	Ja
IR-sändare ingår:	Ja
Infrarött (IR) frekvensområde:	20 - 60 kHz
Kabellängd:	1 m
Produktens färg:	Grå
bruksanvisning:	Ja
Låddjup:	70 mm
Temperatur vid drift:	0 - 70 ° C
Intervall för relativ operativ luftfuktighet:	10 - 85 %
AC-inspänning:	100 - 240 V
3D kompatibilitet:	Ja
Anslutningsteknologi:	Kabel
Likströmsingång:	Ja
Växelström Frekvens:	50 - 60 hz
AC-adapter inkluderad:	Ja
Ström:	1 A
Max uppdateringsfrekvens:	60 hz
Maximal överföringshastighet avstånd:	60 m
Fjärrstyrd IR-utgång:	1
Mottagarvikt:	104 g
Mottagare (B x D x H):	82 x 67 x 21 mm
HDMI-in:	1
Fjärrstyrd (IR) ingång:	1
IR-mottagare ingår:	Ja
EDID (Extended display identification data):	Ja
