Sida 1/8
Package content
1x Split 61x Pro splitter
1x quick guide
1x power adapter
Pro
Split 61x Pro
multi-port splitter
Connect one source to multiple screens
- 4K60hz
- EDID management
- Downscaler
Safety Instructions
Please read these instructions thoroughly before you
use the device and keep them for future reference.
• Indoor use only.
• Do not expose the product to extremely high or low
temperatures, strong light sources or direct sunlight.
• This product is not a toy. Keep out of reach of
children.
• Repairs or service should only be performed by
qualified personnel.
Requirements
Use certified HDMI 2.0 cables that support 18 Gbps
bandwidth.
Installation
Switch off the HDMI devices before connecting.
• Connect your HDMI source to the HDMI port marked
‘Input’.
• Connect the HDMI ports marked ‘Output’ to your
HDMI compatible display devices.
• Use the power adapter to connect the ‘DC/5V’ port to
a power socket.
Notes on using the product
resolution and audio format is being used.
• ‘Auto’: Automatically detects the highest possible
common image resolution and audio format that is
supported by all display devices.
format of the display connected to ‘Output 1’.
• ‘Scaler’: Down scales the resolution from 4K to
1080p. This ensures that all display devices
show video at their highest resolution.
Technical specifications
Connections
Input
Output
1 x HDMI (female)
2,4,8,16 x HDMI (female)*
*depending on the model
Video
Resolution Max. 4K 60Hz with HDR
HDCP Support HDCP 1.4 and 2.2
Colour formats RGB and YCbCr 4:4:4,
4:2:2 or 4:2:0
Colour depth Max. 12-bit
Bandwidth 18 Gbps
Audio
HDMI audio formats DTS-HD Master Audio,
DTS:X, Dolby TrueHD,
Dolby Digital/ AC3, LPCM
7.1 and PCM 2.0CH
Housing and environment
• The HDMI splitter has three EDID modes: Auto, Copy
and Scaler. These EDID modes dictate what video
Operating temperature
0° C to 70° C
Operating humidity 5% to 90%
Power
P
o
we
r
co
n
su
m
p
t
i
o
n
(
max)
10
W
• ‘Copy’: Only detects the image resolution and audio
Power supply 5 VDC/1A(612, 614),2 A(618, 6116)
Declaration of Conformity
Hereby, Marmitek BV, declares that the Split 61x Pro is in compliance with the essential requirements of the
2014/30/EU Directives.
Full Declaration of Conformity is available at www.marmitek.com/en/declarations-of-conformity/
