Sida 1/4

4K 4-Port HDMI Splitter

4K@60Hz, AC Powered, Black

Part No.: 207805

EAN-13: 0766623207805 | UPC: 766623207805

Easily distribute a single Ultra-High-Definition (UHD)

signal to multiple displays

The Manhattan 4K 4-Port HDMI Splitter with built-in booster streams a 4K HDMI

signal from a single UHD source to up to four UHD displays.

Best Possible Image Quality and Easy Installation

Full compliance with HDMI and HDCP 2.2 ensures the Manhattan 4K 4-Port HDMI

Splitter provides nothing short of high-quality performance and reliability. It

delivers cinematic 4K resolution and supports 3D video, Deep Color, HDR, as

well as LPCM, DTS and Dolby TrueHD audio. Quickly connect HDMI cables (not

included) and the power supply to complete this cost-effective 4K solution — no

software or hardware configuration or complicated settings required.

Features:

Replicates an Ultra-High-Definition (UHD) digital audio/video signal for

up to four UHD HDMI displays

4K@60Hz resolution, full 3D video, Deep Color and High Dynamic

Range (HDR)

Supports video amplifier bandwidth up to 600 MHz and 6.0 Gbps per

channel (18 Gbps total) for 4Kx2K displays

Supports 36-bit Deep Color (12-bits per channel), 4:4:4 chroma

subsampling and YCbCr 4:2:0 color formatting

Supports compressed DTS-HD Master Audio, 7.1 surround sound, Dolby

TrueHD and uncompressed LPCM 8 channel audio

HDCP compliant

Multiple splitters (three total) may be cascaded up to support 10 4K

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

displays

Works with PlayStation and Xbox game systems, Blu-ray players, set-

top boxes, satellite receivers and more

Plug and play

Gold-plated contacts for corrosion-free connections

Three-year warranty

Specifications:

Standards and Certifications

• HDCP 2.2/1.4

• CTS 1.4b

• CE

• FCC

• RoHS

General

• Source-to-splitter and splitter-to-display range: up to 20 m (66 ft.)

4K@60Hz 4:4:4 — total 10 meters

Max. 5 m from source to splitter

Max. 5 m from splitter to display

4K@30Hz — total 20 meters

Max. 10 m from source to splitter

Max. 10 m from splitter to display

• Power adapter: 5 VDC / 2 A; 1.2 m (4 ft.)

• Power consumption: 5 W

Connections

• One HDMI female (input)

• Four HDMI female (output)

• One 5 VDC power female (input)

Signal Input/Output

• Input video signal: 0.5 – 1.0 V p-p

• Input DDC signal: 5 V p-p (TTL)

• Maximum single-link range: 18 Gbps and 4096x2160 at 60 Hz resolution

• Output video: HDMI 2.0, HDCP 2.2

Supported Video Resolutions

• DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p/4K@60Hz

Physical

• LED indicators: power and port connection

• On/off switch

• Dimensions: 154 x 69 x 23 mm (6.1 x 2.7 x 0.9 in.)

• Net weight: 249 g

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Produktspecifikationer

Varumärke:	Manhattan
Kategori:	delare
Modell:	207805
Vikt:	250 g
Bredd:	69 mm
Djup:	154 mm
Höjd:	23 mm
LED-indikatorer:	Ja
Maximal upplösning:	3840 x 2160 pixlar
Certifiering:	CTS 1.4b\nCE\nFCC\nRoHS2
HDCP:	Ja
HDMI-version:	2.0
Färgdjup:	36 bit
Maximal räckvidd:	20 m
Bandbredd:	600 MHz
Kabellängd:	1.2 m
Produktens färg:	Svart
HD-typ:	4K Ultra HD
Strömförbrukning (vanlig):	5 W
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	0 - 96 %
Video ut:	4x HDMI
Dolby technologies:	DTS-HD Master Audio, Dolby TrueHD
Hållbarhetscertifiering:	RoHS
AC-inspänning:	5 V
Video porttyp:	HDMI
Videoportar mängd:	5
Material, hölje:	Metall
Plätering på anslutningskontakter:	Guld
3D kompatibilitet:	Ja
Likströmsingång:	Ja
AC-adapter inkluderad:	Ja
Harmonized System (HS)-kod:	85176990
Ingående ström:	2 A
