1080p 2-Port HDMI Splitter

USB Powered, Black

Part No.: 207652

EAN-13: 0766623207652 | UPC: 766623207652

Easily distribute a single HDMI signal to multiple displays.

The Manhattan 1080p 2-Port HDMI Splitter sends HDMI signals from a single Blu-

ray player, satellite receiver, digital recorder, set-top box, game console or

other HDMI source to two HDMI displays.

Flexible Solution for Many A/V Applications

Ideal for trade shows, classrooms, video conferencing, presentations and retail

applications, the Manhattan 1080p 2-Port HDMI Splitter features a built-in

booster for added signal strength. It’s also a good choice for splitting and

distributing a synchronous signal to multiple HDMI displays when source

equipment is remotely stored in a secured room or cabinet. Users can cascade

multiple units up to three levels and output HDMI video/audio to additional

displays in widely distributed applications.

Quality Construction and Easy Installation

Full compliance with HDMI, HDCP 1.0, 1.1 and 1.2 as well as DVI 1.0 ensures

that the Manhattan 1080p 2-Port HDMI Splitter can provide long service and

reliable performance. Quickly connect HDMI cables (not included) and the USB

power cable, and this affordable HDMI solution is complete — no complicated

settings or software or hardware configurations necessary.

Features:

Displays video from one HDMI source on two HD displays

Delivers a sharp, clear signal from Blu-ray players, set-top boxes,

satellite receivers and more

Cascadable up to three levels to expand signal distribution to more

displays

HDCP compliant

Supports LPCM, DTS@ Digital, DTS-HD Master Audio and Dolby TrueHD

audio

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Supports 1080p HD resolution, 3D video and Deep Color

Supports the video amplifier bandwidth up to 2.25 Gbps

Plug and play

Plug-and-play installation; no special setup or remote

Gold-plated contacts

Gold-plated contacts for corrosion-free connections

Three-year warranty

Specifications:

Standards and Certifications

• HDCP 1.0 / 1.1 / 1.2

• DVI 1.0

• CE

• FCC

• RoHS2

General

• Source-to-splitter range: up to 15 m (49 ft.)

• Splitter-to-display range: up to 15 m (49 ft.)

• Power: 5 W; USB cable, 0.7 m (2.3 ft.)

Connections

• One HDMI female, 19-pin (input)

• Two HDMI female, 19-pin (output)

• One USB Mini-B female, 5-pin (input)

Signal Input/Output

• Input video signal: 0.5 – 1.0 V p-p

• Input DDC signal: 5 V p-p (TTL)

• Maximum single-link range: 2.25 Gbps, 1920x1200, 1080p

• Output video: HDMI 1.3b, HDCP 1.0 / 1.1 / 1.2, DVI 1.0

• Frequency: 2.25 Gbps / 225 MHz

Video Resolutions

• DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p

Physical

• LED indicators: power and port connection

• On/off switch

• Dimensions: 60 x 54 x 20 mm (2.4 x 2.1 x 0.8 in.)

• Weight: 0.04 g (0.08 lb.)

• Housing: plastic

Operating Environment

• Operation Temperature: 0 – 70°C (32 – 158°F)

• Storage Temperature: -10 – 80°C (14 – 176°F)

For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and

reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.

Produktspecifikationer

Varumärke:	Manhattan
Kategori:	delare
Modell:	207652
Vikt:	40 g
Bredd:	54 mm
Djup:	60 mm
Höjd:	20 mm
LED-indikatorer:	Ja
Maximal upplösning:	1920 x 1200 pixlar
Certifiering:	CE, FCC, RoHS2
HDCP:	Ja
HDMI-version:	1.3b
Maximal räckvidd:	15 m
Bandbredd:	225 MHz
Kabellängd:	0.7 m
Produktens färg:	Svart
bruksanvisning:	Ja
Strömförbrukning (vanlig):	5 W
Temperatur vid drift:	0 - 70 ° C
Temperaturintervall (förvaring):	-10 - 80 ° C
Intervall för relativ operativ luftfuktighet:	10 - 85 %
Fuktighet (förvaring):	5 - 90 %
Video ut:	2x HDMI
Dolby technologies:	DTS, DTS-HD Master Audio, Dolby TrueHD
Video porttyp:	HDMI
Videoportar mängd:	3
Material, hölje:	Plast
Plätering på anslutningskontakter:	Guld
3D kompatibilitet:	Ja
Kabel inkluderad:	USB
USB-ström:	Ja
Plug & Play-kompatibel:	Ja
Harmonized System (HS)-kod:	85176990
