Installation, Satellite Information & Fault Finding
MXL028/50/65/85 Connect (all models)
UK contact:
Helpline: +44 (0)1553 811000
Email: support@maxview.co.uk
Web: www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
9111420 Iss 4G
Booklet 1 of 2
Contents
Installation
Application Example 4
Connections & Features 5
Product Contents 5
Required Tools & Equipment 5
Selecting an installation location 6
Positioning Control Box 6
Attaching Antenna Mount Cover 7
and LNB Park Plate
Electrical installation 8
Attaching Antenna Unit to Mount Plate 9
Installing Cables 9
Installing Cable Entry Plate 10
Installing Control Box 10
Connection Diagram 11
Attaching Satellite Dish to Unit 11
Testing Bluetooth Connectivity & Installing 12
Updates
Introduction
Please read these instructions fully before using the antenna for the first time. The operation of the antenna has
been designed to be as simple as possible however should you require any technical assistance please contact
Maxview customer service on +44 (0)1553 811000 or visit www.maxview.co.uk.
Proper Use & Operation
The Connect is designed to be installed in a motorhome, caravan or horsebox to automatically locate a television
broadcast satellite when the vehicle is stationary. The system comprises of 2 main components.
1. The Antenna which is to be permanently mounted externally to the roof structure of a motorhome/caravan/
horsebox. The construction of the roof structure should be suitably robust and have no protruding obstacles
2. The Control Box is designed to be mounted internally in a cupboard. This controls the antenna unit through a
cable connection and is powered by 12v DC only.
Use of the equipment for any other purpose than the one specified is not permitted and will invalidate the
warranty.
All instructions and models are subject to change. In accordance with policy of progressive product, the company
reserve the right to alter specifications.
Copyright© these instructions are the sole property of Maxview Ltd and may not be reproduced.
Please keep these instructions safe for future reference.
Recycle packaging where facilities exist.
Satellite Information
Finding a Satellite 13
Skew Adjustment 14
Fault Finding
On Screen Error Modes 15
Control Box Error Modes 16
General Faults & FAQs 18
Portable Connectivity Troubleshooting 19
Ignition 20
Connecting to a Satellite Receiver 20
Power Consumption 20
3 Year Guarantee 21
Environment 22
Specifications 24
