McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 FAX: 607-724-0549
WS500
In-Wall Loudspeaker System
Installation Guide
2
WARNING - TO REDUCE RISK OF FIRE OR
ELECTRICAL SHOCK, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
PERSONNEL.
IMPORTANT SAFETY
INSTRUCTIONS!
PLEASE READ THEM BEFORE
OPERATING THIS EQUIPMENT.
General:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Warning: To reduce risk of fire or electrical shock, do not
expose this equipment to rain or moisture. This unit is
capable of producing high sound pressure levels. Continued
exposure to high sound pressure levels can cause permanent
hearing impairment or loss. User caution is advised and ear
protection is recommended when playing at high volumes.
6. Only use attachments/accessories specified by the
manufacturer.
Installation:
7. Install in accordance with the manufacturer’s instructions.
8.When mounting the Ceiling Loudspeaker System to a
building structure it is important to follow all of the local
building/construction codes. Make sure the ceiling structural
members can support a total weight of five times the weight
of the Ceiling Loudspeaker System.
9. Do not install near any heat sources such as radiators, heat
registers, stoves, or other equipment (including amplifiers)
that produce heat.
10. Do not use this equipment near water.
11. Do not expose this equipment to dripping or splashing and
ensure that no objects filled with liquids, such as vases, are
placed on the equipment.
Care of Equipment:
12. Clean only with a dry cloth.
13. Do not permit objects or liquids of any kind to be pushed,
spilled and/or fall into the equipment through enclosure
openings.
Repair of Equipment:
14. Refer all servicing to qualified service personnel. Servicing
is required when the equipment has been damaged in any
way, liquid has been spilled or objects have fallen into
the equipment, the equipment has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. Do not attempt to service beyond that described in the
operating instructions. All other service should be referred
to qualified service personnel.
16. When replacement parts are required, be sure the service
technician has used replacement parts specified by
McIntosh or have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
17. Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
Please read these Safety Instrucons as well
as the “Important Additional Operation
Information Guide” that is enclosed.
Thank you from all of us at McIntosh
You have invested in a precision instrument that will
provide you with many years of enjoyment. Please take a
few moments to familiarize yourself with the features and
instructions to get the maximum performance from your
equipment.
If you need further technical assistance, please contact
your McIntosh Dealer who may be more familiar with
your particular setup including other brands. You can also
contact us at McIntosh with additional questions or in the
unlikely event of needing service.
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Technical Assistance Phone: (607) 723-3512
Customer Service (for repairs)
Phone: (607) 723-3515
Fax: 607-724-1917
support@mcintoshlabs.com
Website: mcintoshlabs.com
Make a Note
For future reference, you can write your serial number and
purchase information here. We can identify your purchase
from this information if the occasion should arise.
Serial Number:
Purchase Date:
Dealer Name:
Important Safety Instrucons
3
Table of Contents
Important Safety Instructions ��������������������������������������� 2
Thank you from all of us at McIntosh ��������������������������� 2
Make a Note ������������������������������������������������������������������ 2
Tools Needed ����������������������������������������������������������������� 3
Parts Included ��������������������������������������������������������������� 3
Ready To Perform ��������������������������������������������������������� 3
Making a Hole ��������������������������������������������������������������� 3
Installing the Frame ������������������������������������������������������ 3
Connecting to Speaker Wire ���������������������������������������� 3
Putting it in the Wall ���������������������������������������������������� 4
Warranty ����������������������������������������������������������������������� 5
Specifications ���������������������������������������������������������������� 6
Tools Needed
• #2 Phillips Screwdriver
• Drywall Knife or Saw
• Pencil
• Tape Measure
• Stud nder
• Bubble Level
Parts Included
• Loudspeaker Bafe
• Bafe Box
• Frame
• Frame Gaskets (2)
• Grille
• Cutout Template
• Clamping Pieces (2)
• Fiberglass Packing
• Airtight Electrical Connector
• Frame Screws #10-24 x 3 inch (6)
• Bafe Washers #8 (6)
• Bafe Screws #10-24 x 1-1/2 inch (6)
Ready To Perform
The WS500 In-Wall Loudspeaker System is designed
to provide exceptional performance. This 3-way
loudspeaker features McIntosh’s acclaimed MTM
speaker array and shallow woofer design contained in
a fully enclosed back chamber. The design allows for
expansive sound performance with a shallow footprint
perfect for in-wall mounting.
The WS500 is a versatile loudspeaker and can be
employed in many applications. The use of audio design
specialists is recommended for complex installations to
achieve the highest level of performance. Your McIntosh
Dealer is experienced in all aspects of audio/visual setup.
The Low Prole Micro-Flange Grille is magnetically
held in place. These grilles are ready to be painted if you
wish.
Making a Hole
For new construction, the RK500 rough-in bracket
is recommended. The RK500 is available from your
McIntosh Dealer. If you have installed the RK500 skip
ahead to “Installing the Frame”.
Choose the proper position for the WS500 keeping in
mind acoustical properties, the positions of studs and
the ability to run speaker wire to the WS500. When the
proper location is found:
1. Hold the supplied cutout template against the
wall and align it using a bubble level and tape the
template to the wall.
2. Trace the opening.
3. For dry wall installation, use a drywall knife or
saw to cut a hole. The hole should be 13 1/4 inches
(33.66cm) wide by 22 7/16 inches (56.99cm) in
height.
Installing the Frame
The Frame Assembly has two Clamping Pieces
connected to the Frame by Six 3-inch screws (3 each).
The bolt at the end of each screw is there to make sure it
stays connected and need not be moved.
Install the “L” shaped self-adhesive Frame Gaskets to the
rear of the Frame so that the Gaskets will sit between the
Frame and the wall when installed.
With the Clamping Pieces loose, manipulate the frame
into the opening in the wall. The Clamping Pieces can be
moved to allow the frame to t. Once in place, position
the Clamping Pieces against the back of the wallboard on
each side.
When satised that the Frame is level (using a bubble
level), tighten all six screws until the Frame is securely
attached to the wall. Avoid over tightening to prevent
damaging the drywall.
Connecng to Speaker Wire
Prepare Speaker Wires for connection to the WS500.
Remove ½ inch (12.7mm) of insulation from the wire
end and twist the strands together. For runs under 25 feet
