Sida 1/2

MEGATRON

LED Floodlight – MEGATRON ispot

Series name

Model Number

Wattage

Voltage

Frequency

IP Rating

MEGATRON

ispot

MT68020

220–240V~

50/60 Hz

IP65

MEGATRON

ispot

MT68021

18W

220–240V~

50/60 Hz

IP65

MEGATRON

ispot

MT68022

27W

220–240V~

50/60 Hz

IP65

MEGATRON

ispot

MT68023

47W

220–240V~

50/60 Hz

IP65

TECHNICAL SPECIFICATION

Instruction Manual

ATTENTION:

• Instant start is allowed.

• Designed for indoor and outdoor

applications.

• The operating temperature of the

luminaire is -25˚C to +45˚C.

CAUTIONS:

• Read the entire manual carefully before installation and operation.

• Installation or replacement should be performed only by licensed and qualified electricians.

• DO NOT disassemble the inner part of the luminaire. Doing so may result in luminaire damage or malfunction.

• Switch OFF the power source before installation, replacement and cleaning!

• Wearing gloves during installation is recommended to ensure the luminaire is kept in the best condition.

• Before replacement of the luminaire, turn it off and allow it to cool down. Heat-resistant gloves are mandatory when

handling the luminaire.

• The minimum safety distance from the illuminated object is 1,0m.

• The manufacturer accepts no liability for any damage resulting from the misuse of the luminaire or from when it is used

with inappropriate equipment.

•

Consult your dealer if you have any enquiries.

The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person.

Important warning for drilling in walls: before drilling, make sure that there are no gas and water pipes or power lines behind or near the drilling spots.

Drilling and mounting should be performed only by qualified personnel. Be sure to pay attention to the condition and material of the walls, as the supplied mounting

material is not suitable for all wall types. Please inquire about recommended screws and raw plugs for your wall type and wall condition. The manufacturer accepts

no liability for improper wall raw plug mounting and the herefrom resulting damages.

•

Correct disposal of this product:

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or

human health from uncontrolled waste disposal, recycle it responsibly, to promote the sustainable reuse of material resources. To return your device, please use the

return and collection systems, or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.

IDV GmbH | Birkenweiherstraße 2 | D-63505 Langenselbold | Germany | www.megatron-licht.eu

INSTALLATION:

OFF

2. 3.

H07RN-F 3x0.75mm

H07RN-F 3x1.0mm

7.5mm

9.5mm/10mm

N L

Brown

Ye eenllow/Gr
