MEGATRON
®
LED Rechargeable Table Luminaire
TAVOLA 2W
TECHNICAL SPECIFICATIONS
Instruction Manual
Model No.
MT68050-3 ~ MT68055-3, MT68056 ~ MT68058
Wattage
Color temperature
Lumen Light Source
Lumen Containing Product
Lifetime (LED-Modul)
Input current
Output current
IP Rating
Material
Dimension (mm)
Regargeable Lithium-Ion-Battery
2W
2700K (Ra80) warmwhite
350lm
200lm
20.000h
AC 100-240V, ~50/60Hz
DC5V, 1A
IP54
Die-cast Aluminum/PC
Ø110mm x H: 380mm
18650 3,7V 4.400mAh
© 03/2022 IDV GmbH
Please read the entire instruction manual carefully before installation and operation.
IDV GmbH Birkenweiherstraße 2 D-63505 Langenselbold Germany www.megatron-licht.eu| | | |
GBIP54
Type 18650 Lithium-Ion
Capacity 2x2200mAh (7,4Wh)
Voltage DC3,7V
Rechargeable Battery
Dear customer,dear customer,
Thank you for choosing the TAVOLA LED rechargeable table lamp.
OPERATION:
• Press the touch switch to turn on and off.
• Press the touch switch longer to dim up or down.
Red
(Battery is
charging)
Green
(Battery is
full)
CAUTIONS:
• Ideal for restaurants and private households as well as for indoor and outdoor use (garden, inhouse, camping).
• Bright warm white LED chips for up to 350lm luminous flux.
• Dimmable from 100% - 5% - by long press on the touch switch.
• Rechargeable Lithium-Ion battery for up to 12 hours of light duration.
• The battery is delivered partially charged. Please charge the LED table luminaire before first usage.
• Includes magnetic USB-C charging cable (1,5m) and 100-240V USB charger.
• Use a clean and dry cloth for cleaning.
• Do not use chemicals to clean the luminaire.
• Avoid use in extreme heat: Observe the ambient temperature range of -15°C to +40°C.
•
Charger
Applies only to
the luminaire
Please observe the
maximum operating
temperature of 40°C!
Do not place on metallic
surfaces! Do not use in
direct sunlight (risk of
battery overheating)!
Battery & Lamp Disposal
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To
return your used device or the used rechargeable battery, please use the return and collection systems or contact the retailer where the product
was purchased. They can take this product for environmental safe recycling. Batteries containing hazardous substance are marked by a recyc-
ling symbol and chemical symbols (Cd, Hg or Pb) of the hazardou substances involved.
The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire shall be replaced.
• If you use an alternative charger with more than 5V 1A, the warranty of the lamp will be void.
• Connect the magnetic charging cable to the magnetic convertor in the luminaire, and afterwards connect the charging
cable to a power source, e.g. USB connection of PC, mobile phone or charger (5V DC/1A) or, when using together
with the 100-240V charger, to a 230V socket.
• During the charging process, the charging indicator lamp will light up in red color on the top of the lamp head. When the
battery is fully charged, the charging indicator will light up in green color.
• Charging time: 5-6 hours.
• Use the included charger only together with the LED table luminaire TAVOLA.
• The charger must not be used outdoor and is not allowed to come into contact with moisture (rain, splash water, liquids).
• Do not leave the charger in the socket after charging is complete or when the charger is not in use.
• Never attempt to open the charger. Risk of electric shock!
• Keep the charger out of the reach of children.
• To charge the luminaire , first put the USB-C – magnetic convertor (refer to pic A) into the USB-C socket of luminaire
then make sure it is firmed.
CHARGING:
+40°C
-15°C
A
