99-7892

Acura CL 1997-1999

1. Unclip the radio trim bezel and disconnect the

clock and climate control wiring. (Figure A)

2. Remove (2) 8mm hex-head screws securing the

factory radio and disconnect the wiring.

Continue on the next page

Dash Disassembly

• Phillips screwdriver • Cutting tool • Socket wrench

;663:9,8<09,+

Table of Contents

Dash Disassembly

Acura

– CL 1997-1999 ....................................................5.1

– Integra 1990-1993 ..............................................5.1

– Integra 1994-2001 ..............................................5.2

– Legend 1990.................................................5.2-5.3

– Legend 1991-1996 .............................................5.3

– TL 1996-1998 .....................................................5.4

– Vigor 1992-1994 .................................................5.4

Honda

– Accord 1990-1993 ..............................................5.5

– Accord 1994-1997 ..............................................5.5

– Odyssey 1995-1998 ...........................................5.6

– Isuzu Oasis 1996-1999 .......................................5.6

Kit Assembly

– 2-shaft radio provision with pocket .....................5.6

– DIN radio provision with pocket ...........................5.7

– ISO DIN radio provision with pocket .....................5.7

Section 5

Acura/Honda/Isuzu

1997-2001

99-7892

• A) Radio housing • B) Faceplate

• C) ISO DIN brackets • D) Rear support bracket

• E) (2) Phillips screws

20;-,(;<9,:

20;*64765,5;:

• 2-shaft radio provision with pocket

• DIN radio provision with pocket

• ISO DIN radio provision with pocket

• Rear support provision

BA

CD

E

(Figure A)
