Installation instructions for part LC-GMRC-044
REV. 12/2/2016 INSTLC-GMRC-044
®
axxessinterfaces.com
•
metraonline.com
© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
Axxess Integrate
®
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• Provides accessory power (12-
volt 10-amp)
• Retains R.A.P. (retained
accessory power)
•
Provides NAV outputs (parking
brake, reverse, and speed sense)
• Used in non-amplified
models, or when bypassing a
factory amplifier
•
Used in models without OnStar
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Micro “B” USB updatable
INTERFACE FEATURES
• Wire cutter • Crimping tool • Tape • Solder gun
• Connectors (butt-connectors, bell caps, etc.)
TOOLS REQUIRED
LC-GMRC-044
GM Data Interface
2012-2016
APPLICATIONS
• LC-GMRC-044 interface
• LC-GMRC-044 harness
INTERFACE COMPONENTS
*Only for models with factory navigation.
Note: This interface will not retain OnStar.
CADILLAC
Escalade, Escalade ESV & EXT*
2012-2014
CHEVROLET
Avalanche* 2012-2013
Express* 2013-2015
Malibu (with single color,
monochrome screen)
2013-2015
CHEVROLET (CONT)
Malibu Limited (with single
color, monochrome screen)
2016
Silverado* 2012-2013
Silverado 2500/3500* 2014
Suburban* 2012-2014
Tahoe* 2012-2014
Trax 2015-2016
GMC
Savana* 2013-2015
Sierra * 2012-2013
Sierra 2500/3500* 2014
Yukon / Yukon XL* 2012-2014
Connections to be made ........................................ 2
Installing the LC-GMRC-044 .................................. 3
Initializing the LC-GMRC-044 ................................ 3
Vehicle customization with the optional AX-LCD
... 3
Table of Contents
LC-GMRC-044
®
2
From the LC-GMRC-044 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Tape off and disregard the Pink wire, it will not be used in this application.
• Connect the Blue/White wire to the power antenna wire.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these
wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
Connections to be made
