XSVI-6515-NAVXSVI-6515-NAV

INSTALLATION INSTRUCTIONSINSTALLATIONINSTRUCTIONS

XSVI-6515-NAVXSVI-6515-NAV

INSTALLATIONINSTRUCTIONSINSTALLATIONINSTRUCTIONS

REV. 7/17/17REV. 7/17/17© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

REV. 7/17/17REV. 7/17/17© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

Fiat 500 accessory and NAV output CAN interface 2012-2015

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Used in both amplified and non-amplified systems

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness included (ASWC-1 sold separately)

• High level speaker input

• Retains OE BT/USB and 3.5mm audio

• Mirco "B" USB updatable

Fiat 500 accessory and NAV output CAN interface 2012-2015

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Used in both amplified and non-amplified systems

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness included (ASWC-1 sold separately)

• High level speaker input

• Retains OE BT/USB and 3.5mm audio

• Mirco "B" USB updatable

Fiat 500 accessory and NAV output CAN interface 2012-2015

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Used in both amplified and non-amplified systems

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness included (ASWC-1 sold separately)

• High level speaker input

• Retains OE BT/USB and 3.5mm audio

• Mirco "B" USB updatable

Fiat 500 accessory and NAV output CAN interface 2012-2015

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Used in both amplified and non-amplified systems

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness included (ASWC-1 sold separately)

• High level speaker input

• Retains OE BT/USB and 3.5mm audio

• Mirco "B" USB updatable

WIRING UP THE XSVI-6515-NAV

• Connect the Yellow wire to the radio’s 12-volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the aftermarket

radio has no illumination wire, tape off the Orange wire.

• Connect the Blue/White wire to the radio's amp turn on wire.

• Connect the White wire to the left front positive speaker output of the aftermarket radio.

•

Connect the White/Black wire to the left front negative speaker output of the aftermarket radio.

• Connect the

Gray

wire to the right front positive speaker output of the aftermarket radio.

•

Connect the

Gray/Black

wire to the right front negative speaker output of the aftermarket radio

.

• Connect the

Green

wire to the radio’s left rear positive speaker output.

• Connect the

Green/Black

wire to the radio’s left rear negative speaker output.

• Connect the

Purple

wire to the radio’s right rear positive speaker output.

• Connect the

Purple/Black

wire to the radio’s right rear negative speaker output.

WIRING UP THE XSVI-6515-NAV

• Connect the Yellowwire to the radio’s 12-volt battery or memory wire.

• Connect the Blackwire to the radio’s ground wire.

• Connect the Redwire to the ignition wire of the aftermarket radio

• Connect the Orangewire to the illumination wire of the aftermarket radio. If the aftermarket

radio has no illumination wire, tape off the Orangewire.

• Connect the Blue/Whitewire to the radio's amp turn on wire.

• Connect the Whitewire to the left front positive speaker output of the aftermarket radio.

•

Connect the White/Blackwire to the left front negative speaker output of the aftermarket radio.

• Connect the

Gray

wire to the right front positive speaker output of the aftermarket radio.

•

Connect the

Gray/Black

wire to the right front negative speaker output of the aftermarket radio

.

• Connect the

Green

wire to the radio’s left rear positive speaker output.

• Connect the

Green/Black

wire to the radio’s left rear negative speaker output.

• Connect the

Purple

wire to the radio’s right rear positive speaker output.

• Connect the

Purple/Black

wire to the radio’s right rear negative speaker output.

WIRING UP THE XSVI-6515-NAV

• Connect the Yellowwire to the radio’s 12-volt battery or memory wire.

• Connect the Blackwire to the radio’s ground wire.

• Connect the Redwire to the ignition wire of the aftermarket radio

• Connect the Orangewire to the illumination wire of the aftermarket radio. If the aftermarket

radio has no illumination wire, tape off the Orangewire.

• Connect the Blue/Whitewire to the radio's amp turn on wire.

• Connect the Whitewire to the left front positive speaker output of the aftermarket radio.

•

Connect the White/Blackwire to the left front negative speaker output of the aftermarket radio.

• Connect the

Gray

wire to the right front positive speaker output of the aftermarket radio.

•

Connect the

Gray/Black

wire to the right front negative speaker output of the aftermarket radio

.

• Connect the

Green

wire to the radio’s left rear positive speaker output.

• Connect the

Green/Black

wire to the radio’s left rear negative speaker output.

• Connect the

Purple

wire to the radio’s right rear positive speaker output.

• Connect the

Purple/Black

wire to the radio’s right rear negative speaker output.

WIRING UP THE XSVI-6515-NAV

• Connect the Yellowwire to the radio’s 12-volt battery or memory wire.

• Connect the Blackwire to the radio’s ground wire.

• Connect the Redwire to the ignition wire of the aftermarket radio

• Connect the Orangewire to the illumination wire of the aftermarket radio. If the aftermarket

radio has no illumination wire, tape off the Orangewire.

• Connect the Blue/Whitewire to the radio's amp turn on wire.

• Connect the Whitewire to the left front positive speaker output of the aftermarket radio.

•

Connect the White/Blackwire to the left front negative speaker output of the aftermarket radio.

• Connect the

Gray

wire to the right front positive speaker output of the aftermarket radio.

•

Connect the

Gray/Black

wire to the right front negative speaker output of the aftermarket radio

.

• Connect the

Green

wire to the radio’s left rear positive speaker output.

• Connect the

Green/Black

wire to the radio’s left rear negative speaker output.

• Connect the

Purple

wire to the radio’s right rear positive speaker output.

• Connect the

Purple/Black

wire to the radio’s right rear negative speaker output.
