Sida 1/24

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This is Wireless Network Device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most important technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, brochures, and more info about products at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

Depending on the antenna used, you must set its gain. This is to ensure that EIRP meets the limit set by the local authorities. This is done in the Quickset menu.

This Device accepts input of a 24V DC power adapter, which is provided in the original packaging of this device. This Device can be powered using a PoE injector

(Provided in the packaging).

First steps:

First steps:First steps:

Connect the device to the included PoE injector with an Ethernet cable to the end;data+power

Connect the data end of the PoE injector to the computer;

Connect the power adapter to the PoE injector;

Configure your device using a web browser through or the tool at

WebFig

 

Winbox

https://mt.lv/winbox;

Access by opening , and for , download the tool, navigate to the tab, and click on the MAC address. The 

WebFig

  http://192.168.88.1

Winbox



Neighbors

username is with no password ;

"admin"

(or, for some models, check user and wireless passwords on the sticker)

For a manual update of the device, visit the products page at to find your product. The required packages are accessible under  https://mikrotik.com/products

the menu;

"Support&Downloads"



Upload downloaded packages to the or menu and reboot the device;

WebFig Winbox



"Files"

Updating your RouterOS software to the latest version will ensure the best performance, stability, and security updates;

In the menu set up the following: Choose your country, to apply country regulation settings;

"Quick Set"

Set up your wireless network password in the left field;

Set up your router password in the bottom field.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correc .t hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.

This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

Exposu

ExposuExposure

re re to

toto

Radi

RadiRadio

o o Fre

Fre

FreFrequenc

quenc

quencquency

y y Rad

Rad

RadRadiation

iation

iationiation:

: :

uncontrolled environment. This MikroTik device should be installed and operated no closer than 40 centimeters from your body, occupational user, or the general

public.

Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.

BG - Български. Бързо ръководство

BG - Български. Бързо ръководствоBG - Български. Бързо ръководство:



Това е устройство за безжична мрежа. Можете да намерите името на модела на продукта на етикета на регистъра (ID).

Моля, посетете страницата с ръководството за потребителя на за пълното актуализирано ръководство за употреба.https://mt.lv/um-bg

Или сканирайте QR кода с мобилния си телефон.

Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.

Технически спецификации, брошури и повече информация за продуктите наhttps://mikrotik.com/products

Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на https://mt.lv/help-bg

Устройствата MikroTik са за професионална употреба. Ако нямате квалификация, моля, потърсете консултантhttps://mikrotik.com/consultants

В зависимост от използваната антена, трябва да зададете нейното усилване. Това е за да се гарантира, че EIRP отговаря на ограничението,

определено от местните власти. Това се прави в менюто за бърз набор Quickset.

This device needs to be upgraded to RouterOS v6.49.1 or the latest version to ensure compliance with local authority regulations!

It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be professionally installed

Това устройство трябва да бъде надстроено до RouterOS v6.49.1 или най-новата версия, за да се гарантира спазването на местните

регулаторни разпоредби.

Крайните потребители са отговорни за спазването на местните разпоредби, включително работата в рамките на законни честотни канали,



извеждане на продукцияизисквания за захранване, окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства

на MikroTik трябва да бъдатпрофесионално инсталиран.

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	Inte kategoriserad
Modell:	SXTsq Lite2
Vikt:	295 g
Bredd:	129 mm
Djup:	129 mm
Höjd:	34 mm
Förpackningens bredd:	255 mm
Strömförbrukning (max):	5 W
Internminne:	64 MB
Flashminne:	16 MB
Maximal dataöverföringshastighet:	100 Mbit/s
2,4 GHz:	Ja
5 GHz:	Nej
Antennfunktioner:	Integrerad antenn
WAN-port:	Ethernet (RJ-45)
Produktens färg:	Vit
Låddjup:	180 mm
Vikt inkl. förpackning:	492 g
Inbyggd processor:	Ja
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	-40 - 70 ° C
AC-inspänning:	10 - 30 V
Kommunikationsstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Harmonized System (HS)-kod:	85176990
Intern:	Ja
