Compact Array

AN2075

Features

Compact and lightweight, full-range neodymium loudspeakers

Advanced Finite Element Analysis techniques used for acoustic, mechanical

and electromagnetic modelling

Ideal for applications such as portable line arrays where actively

controlled wavefront (beam steering) is used

Delivers wider dispersion to higher frequencies than many equivalent

compact, full-range drivers on the market

Chassis purpose designed for maximum free air movement, with square

mounting frame to facilitate close coupling of multiple units

Sti and light aluminium cone remains rigid to higher frequencies,

delivering a smoother response in the critical listening band

Half roll elastomer surround provides damping for unwanted resonances and

sustained centring control at extremes of excursion

Designed to be weather resistant for outdoor applications

8 Ω Frequency Response

1.Tested for two hours using a continuous, band-limited pink noise signal as per AES standard. Power

calculated on minimum impedance. Loudspeaker tested in free air.

2.Measured on axis at 1W, 1m in 2 anechoic environment.

3.Xmax derived from: (voice coil winding width-gap depth)/2.

General Specications

Nominal diameter50mm/2in

Power rating

1

20Wrms

Nominal impedance8 Ω

Sensitivity

2

80dB

Frequency range160Hz-19kHz

Voice coil diameter20mm/0.75in

Chassis typeGlass reinforced ABS

Magnet typeNeodymium

Coil materialRound Copper

Former materialPolyimide

Cone materialAluminium

Surround materialElastomer

Xmax

3

1.5mm/0.06in

Gap depth3mm/0.12in

Voice coil winding width6mm/0.24in

Voice coil materialRound Copper

Voice coil former materialPolyimide

Bandwidth200Hz-20kHz

Small Signal Parameters

Sd12.57cm2/1.94in2

D40mm/1.57in

Fs160Hz

Mms1.37g/0.05oz

Qms10.12

Qes1.22

Qts1.09

Re5.28 Ω

Vas0.12lt/0.004ft3

BI2.60Tm

Cms0.55mm/N

Mounting Information

Overall depth43.5mm/1.7in

Overall size56.2 x 56.2mm/2.2in x 2.2in

Cut-out diameter51.1mm/2.0in

Fitting4 x M4 holes

Mounting PCD rangeØ62mm/2.45in

Unit weight97g/3.4oz

Celestion, Claydon Business Park, Great Blakenham, Ipswich, IP6 0NL United Kingdom
