HDMI 4x4 Matrix Switch, 4K/60
Operation Manual
500444
HDMI 4x4 Matrix Switch, 4K/60 Operation Manual
© Muxlab Inc. 2017 2
SAFETY PRECAUTIONS
To insure the best performance from the product, please read all instructions
carefully before using the device. Save this manual for future reference.
Follow basic safety precautions to reduce the risk of fire, electrical shock and
injury.
Do not dismantle the housing or modify the module. It may result in electrical
shock or burn.
Do not open or remove the housing of the device as you may be exposed to
dangerous voltage or other hazards.
To prevent fire or shock hazard, do not expose the unit to rain, moisture and
do not install this product near water. Keep the product away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment
damage. If an object or liquid falls or spills on to the housing, unplug the
module immediately.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the
power to the device before cleaning.
Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
Refer all servicing to qualified service personnel.
Install the device in a place with adequate ventilation to avoid damage caused
by overheat.
Unplug the power when left unused for a long period of time.
Information on disposal of devices: do not burn or mix with general household
waste, please treat them as normal electrical waste.
NOTICE: Please read this manual carefully before using this product.
HDMI 4x4 Matrix Switch, 4K/60 Operation Manual
© Muxlab Inc. 2017 3
Table of Contents
1.Introduction.................................................................................................................. 4
2. Features ...................................................................................................................... 5
3. Package Contents ......................................................................................................... 5
4. Specifications ............................................................................................................... 6
5. Panels Description and Unit Installation .......................................................................... 7
5.1 Front Panel ........................................................................................................ 7
5.2 Rear Panel ......................................................................................................... 7
5.3 Matrix Switch Installation .................................................................................... 8
5.4 Management Options ......................................................................................... 9
6. Front Panel Control ..................................................................................................... 10
6.1 Navigating the Menu ........................................................................................ 10
6.2 Menu – Scaler Function per Port ........................................................................ 10
6.3 Menu – Select EDID per Port ............................................................................. 11
6.4 Menu – View IP Config ...................................................................................... 13
6.5 Connectivity Operation ..................................................................................... 14
7. IR Handheld Remote Control ....................................................................................... 15
8. RS232 Remote Control ................................................................................................ 16
9. Telnet Remote Control ................................................................................................ 19
Regulatory Compliance ................................................................................................... 20
