Nanlite Forza 500 Bruksanvisning

Nanlite Lampa Forza 500

Läs gratis den bruksanvisning för Nanlite Forza 500 (2 sidor) i kategorin Lampa. Guiden har ansetts hjälpsam av 3 personer och har ett genomsnittsbetyg på 4.6 stjärnor baserat på 2 recensioner. Har du en fråga om Nanlite Forza 500 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/2

Item # 12-2026MAP $1990.00

NanliteUS.com

• Monolight style COB LED

• Output 11950 Lux of 5600K

daylight-balanced light at 1 meter

• Weighs only 5.7 lbs

• Flicker-Free Dimming from 100% to 1%

up to 25,000 fps

• High CRI/TLCI of 95/96

• Includes Light, Power Adapter, Reflector

& Carry Case

Lightweight,

Compact Design

Created to eliminate the difficulties of

traveling with large light fixtures the

Forza 500 weights only 5.7 lbs and is

compact enough to be easily packed into

most gear cases.

Bowens Style Light

Modifier Mount

By utilizing the near-universal Bowens

style light modifier mount, the Forza 500

is compatible with a massive selection of

light modifiers. Including, but not limited to

NanLite’s line of softboxes and umbrellas.

Practical Effects

With pre-programmed special effects in a

simple-to-master menu system, the Forza

makes it easy to imitate lighting scenarios

that can otherwise be tricky to recreate. At

the touch of a button, you can simulate the

lighting effects of lightning, a TV screen, a

flash, and a malfunctioning light bulb.

FL-20 Fresnel Lens for

Forza 300/500

RC-1 Remote Control

Nanlink App

Control System

SB-PR-90

Para 90 Softbox with

Bowens Mount (35in)

SB-PR-120

Para 120 Softbox with

Bowens Mount (47in)

SB-PR-150

Para 150 Softbox with

Bowens Mount (59in)

Additional Accessories:

Technical Data

Power Consumption 500W

Power Supply DC48V / 12.5A 100-240V AC

Battery Compatibility Sony V-Mount 26v Battery (Not Included)

Charge Time to Full Battery Dependent

Runtime @ 100% Brightness

(2x) 26V Sony V-Mount Style 230WH: 1.5 hours

Lumen Output 5600K 46613

CRI (Ra) 98

TLCI 95

Color Temperature 5600K

Dimming 0 to 100% continuous

Control Dimming, 2.4G wireless control, Wifi control, DMX

Dimensions 12.2 x 8.1 x 5.6 In

Weight

Light 5.5 Lbs

Light + Adapter +

Power Box

10.6Lbs

Cooling System Active Silent Fan

DMX Control Yes

Mount 5/8" reciever with rotating yoke/Bowns S Style

Warranty Limited 1-Year

Distance 1M 3M

With Standard

Reflector

66300 lux 6257 lux

6159 fc 582 fc

Without Lens

19820 lux 2217 lux

1841 fc 205 fc

With Fresnel lens

Spot 10°

N/A lux 25090 lux

N/A fc 2330 fc

With Fresnel lens

Flood 45°

48810 lux 13520 lux

4534 fc 1256 fc

Produktspecifikationer

Varumärke:	Nanlite
Kategori:	Lampa
Modell:	Forza 500
Vikt:	2495 g
Bredd:	310 mm
Djup:	206 mm
Antal lampor:	- lampor
Ljusflöde:	46613 LM
Lampans livslängd:	- h
Dimbar:	Ja
Färgåtergivningsindex (CRI):	98
Färgtemperatur (min):	5600 K
Produktens färg:	Svart
väska:	Ja
Höjd (max.):	142 mm
AC-inspänning:	100 - 240 V
Lamptyp:	LED
Antal:	1
Total effekt:	500 W
Energiförbrukning per 1 000 timmar:	- kWh
