Natec Genesis GX77 1

EN – NATEC GENESIS GX77 – USER MANUAL

I. Introduction

Natec Genesis GX77 is a wired gaming mouse with 9 fully customizable buttons, high precision

laser engine and comfortable design.

II. Features

- High-end laser engine, precise positioning

- Adjustable resolution up to 5670DPI

- Different LED indicator colors

- Two modes of LED lightning: full lightened and breathing.

- 9 fully programmable keys – more than 40 settings to choose for each

- Adjustable polling rate: 125/250/500/1000 Hz.

- Advanced profiles management

- Ergonomic design

III. Driver description

A. System

- Compatible with Windows XP/Vista/7 operation system

- USB (1.1/2.0) port

- CD-ROM drive (for installing the driver from CD attached) / internet connection (for

downloading the driver)

- 50 MB of hard disk space

- Screen resolution: minimum 1024x768

B. Windows XP/Vista/7 installation guide

1. Insert the Genesis GX77 gaming mouse USB plug into the computer USB port

2. Insert the Genesis GX77 driver CD into the CD-ROM drive (or download the driver from

www.natec-europe.com)

3. Launch the setup application and click next on the window displayed

4. Select the install path, then click next

5. Wait for the end of the installing process

6. Click finish

7. You are ready to use the device.

IV. Mouse configuration

A. Button settings

Button settings tab allows you to assign individual functions to each button.

You can bind one of more than 40 functions to keys labeled by numbers on the schema above. In

the right side of the window, you can see actual configuration of the buttons. Each position on the

list is in fact a combo box, from which you can choose a preferred function for an individual button.

Natec Genesis GX77 2

On-To-Go

The On-To-Go function works similarly to the fire button – but, as fire button simulates repeating

presses of left button of the mouse, the On-To-Go can do so with any button of the mouse. To use

this function:

1. Assign On-To-Go to any button in the Button Settings

2. Click Apply

3. Hold down the On-To-Go button and the button that you want to press repeatedly.

Defining Macros

In brief speaking, a macro is a series of actions that you can bind to the mouse. More precisely,

macro is a recorded sequence of key presses, releases and time delays between them. Output delays

can be recorded or predefined by user.

To define a macro, you have to choose from available function list assign macro, and then macro

manager.

Natec Genesis GX77 3

Adding a macro:

1. Click new

2. Choose name for your macro

3. Click start record

4. Press desired sequence of keys

5. Press stop record

Now you can assign your macro to the key by selecting it from group assign macro on the list

related to the programmed key.

Deleting macros:

1. Open macro manager

2. Choose a macro from the list

3. Click delete

Additional options:

Record delays between key commands – you can choose whether to record time intervals between

pressing and releasing the keys

Loop times – you can define how many times macro should be used after single button press.

B. Advanced Settings

In this tab, you can adjust advanced settings of the mouse.

Polling rate – defines how often the mouse sends information of its position to the computer.

Available options: 125/250/500/1000Hz

On-To-Go Speed – defines time intervals between key presses simulated by the On-To-Go function

Restoring factory defaults

To restore factory defaults, click reset in the advanced settings tab. Warning – resetting the

configuration will delete all settings and macros stored in the driver!

Produktspecifikationer

Varumärke:	Natec
Kategori:	gå
Modell:	GX77
Vikt:	- g
LED-indikatorer:	Ja
Gränssnitt:	USB Type-A
Rekommenderad användning:	PC / bärbar dator
Antal knappar:	7
Ytfärg:	Monokromatiskt
Rörelseupplösning:	5670 DPI
Typ av knappar:	Tryckbara knappar
Programmerbara musknappar:	Ja
Kabellängd:	2 m
Produktens färg:	Black, Red
Formfaktor:	högerhand
Mac-operativsystem som stöds:	Mac OS X 10.10 Yosemite, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Plug & Play-kompatibel:	Ja
Linux operativsystem som stöds:	Ja
Ändamål:	Spela
Rörelsedetektor-teknik:	laser
Skrollhjul:	Ja
Scroll-typ:	Hjul
Antalet rullningshjul:	1
Rullande riktningar:	Vågrät
