ENGLISH · FRANÇAIS · ESPAÑOL · DEUTSCH

ITALIANO · PORTUGUÊS · POLSKI

DOMO

REPEATER

EXTENDED RANGE

WIRELESS REPEATER

HIGH-GAIN ANTENNA

USER’S

MANUAL

USER’S MANUAL

OPEn SOURcE cODE

This product includes software codes developed by third parties. These

software codes are subject to either the GNU General Public License (GPL),

Version 2, June 1991 or the GNU Lesser General Public License (LGPL), Version

2.1, February 1999. You can copy, distribute, and/or modify in accordance with

the terms and conditions of GPL or LGPL.

The source code should be complete, if you think our need to provide any

additional source code ﬁles under GNU General Public License (GPL), please

Public License (GPL) . You are welcome to contact us local oﬀice to get the

corresponding software and licenses. Please inform us your contact details and

the product code. We will send you a CD with the software and license for free.

Please refer to the GNU GPL Web site for further information.

http://www.gnu.org/licenses/licenses.en.html.

WELcOME

NGS thanks you for your trust in purchasing this product.

This document provides all the necessary information for a correct setup and

data needed to fully enjoy your device.

Visit our website for further details www.ngs.eu

PAckAgE cOnTEnTS

Before you starting to use this router, please check if there’s anything missing in

the package, and contact your dealer of purchase to claim for missing items:

1 Wireless-N repeater

1 RJ-45 networking cable

1 CD with software and user’s manual

note: If you need to reset the Domo Repeater, you need press and hold the reset

button inside the tiny hole for 10 seconds.

InTRODUcTIOn

The Domo Repeater is a combined wired/wireless network connection device

designed speciﬁcally for small business, oﬀice, and home oﬀice networking

requirements. It allows a wireless network to be expanded using multiple access

points without the need for a wired backbone to link them. It also works well

with other 11b/g and 11n protocol wireless products.

Power indicator

Wireless indicator

WPS indicator

LAN indicator

WPS button

RJ-45 port

Reset

USER’S MANUAL

Wireless AP Mode

You will need broadband

Router Internet access

Connect the Domo Repeater to your

Router/Switch with RJ-45 cable.

GETTING STARTED HOW TO CONFIGURE THE DOMO REPEATER

Setting up a Wireless Infrastructure Network

For a typical wireless setup at home (as shown below), please do the following:

You can conﬁgure the Domo Repeater after connecting it with your computer/

laptop with enclosed RJ45 cable or wirelessly.

Note: Please check whether the Domo Repeater accord with factory default

settings once you can’t open http://192.168.10.1. If you are still not sure what

reasons, you can reset the Domo Repeater, just need to press the reset button

for 10 seconds, then try again.

A. Conﬁgure the Domo Repeater wirelessly

A1. Plug the Domo Repeater to a wall socket.

A2. Click on the network icon or on the

right bottom of your desktop. You will ﬁnd

the signal from the Domo Repeater. Click

on “Connect” and wait for a few seconds.

A3. Open web browser and type

http://192.168.10.1 in the browser’s

address box. This number is the default IP

address for this device.

Wireless Repeater Mode

You will need WiFi

AP/Router Internet access

Router
