En_02
D The Lenses Supplied with Lens Kits
Documentation for the lenses supplied with lens kits is available from
the Nikon Download Center.
D The Nikon Download Center
Visit the Nikon Download Center to download rmware
updates, NX Studio and other Nikon software, and
documentation for Nikon products including cameras,
NIKKOR lenses, and ash units.
https://downloadcenter.nikonimglib.com/
D Downloading Nikon Software
NX Studio and other computer software is available from the Nikon
Download Center. SnapBridge and other Smartphone (tablet) apps
are available from the Apple App Store® and Google Play™. For more
information, see the “Reference Guide.”
Package Contents
Be sure all items listed here were included with your camera.
• Camera body
• BS‑1 accessory shoe cover
(comes attached to camera)
• DK‑29 rubber eyecup (comes
attached to camera)
• BF‑N1 body cap
• EN‑EL15c rechargeable Li‑ion
battery with terminal cover
• AN‑DC26 strap
• USB cable with Type‑C
connectors at both ends
• User’s Manual
• Warranty (see left)
• Memory cards are sold separately.
• This camera uses SD, SDHC, and SDXC memory cards.
Throughout this document, memory cards of all types are
referred to as “memory cards,” “SD memory cards,” or “SD cards”.
Parts of the Camera
7
6
9
8
9
11 1012
13
4123 5
14 15
16
17
18
24
22
19
20
23
21
30
29
26
28
27
25
36
35
37
4243
39
40
41
38
333231 34
51
54
53
52
50
47
46
48
49
44
45
1 Speaker
2
Focal plane mark (E)
3 Stereo microphone
4 Video‑record button
5 Power switch
6 Shutter‑release button
7 Exposure compensation button
(E)
8
ISO sensitivity button (S)
9 Eyelet for camera strap
10 Main command dial
11
Picture Control button (h)
12 Mode dial
13 Accessory shoe (for optional
ash unit)
14
Monitor mode button (M)
15 AF‑assist illuminator
Red‑eye reduction lamp
Self‑timer lamp
16 Cover for USB and HDMI
connectors
17 Cover for microphone and
headphone/remote cord
connectors
18 Lens mounting mark
19 Charge lamp
20 Connector for external
microphone
21 USB connector
22 Headphone/remote cord
connector
23 HDMI connector
24 Body cap
25 Monitor
26
Delete button (O)
27
Release mode button (c)
Protect button
Self‑timer button (E)
28 Rubber eyecup
29 Viewnder
30 Eye sensor
31 Diopter adjustment control
32
DISP button (d)
33 Photo/video selector
34
AF‑ON button (B)
35 Sub‑selector
36
“i” button (i)
37
OK button (J)
38 Multi selector
39
Playback zoom in button (X)
40
MENU button (G)
41
Playback button (K)
42 Playback zoom out/thumbnails
button (W)
Help button (Q)
43 Memory card access lamp
44 Lens release button
45 Lens mount
46 CPU contacts
47 Image sensor
48 Tripod socket
49 Battery chamber cover
50 Battery chamber cover latch
51 Memory card slot cover
52
Fn2 button (k)
53
Fn1 button (j)
54 Sub‑command dial
• Throughout this document, the display in camera monitor
and viewnder during shooting is referred to as the “shooting
display”. In most cases, the illustrations show the monitor.
First Steps
Attaching the Strap
To attach a strap, follow the steps below.
Inserting the Battery
• Turn the camera o before inserting or removing the battery.
• Using the battery to keep the orange battery latch pressed to
one side, slide the battery into the battery chamber until the
latch locks it in place.
Charging the Battery
Charge the supplied EN‑EL15c rechargeable Li‑ion battery before
use. The battery can be charged while inserted in the camera by
connecting the camera to an optional EH‑8P AC adapter using the
supplied USB cable.
D Cautions: Using Batteries
Read and follow the warnings and cautions in “For Your Safety”
(overleaf) and “Caring for the Camera and Battery: Cautions” (overleaf).
1
Insert the battery.
2
After conrming that the camera is o, connect it to an
optional EH-8P AC adapter using the supplied USB cable
(q).
Plug the AC adapter into a household power outlet. The
battery will charge while the camera is o. Keep the plug
straight during insertion and removal.
• The camera charge lamp (w) lights amber while charging is
in progress. The lamp turns o when charging is complete.
• An exhausted battery will fully charge in about 2hours and
30minutes.
• Disconnect the USB cable when charging is complete. Keep
the connector straight when disconnecting it from the
camera.
• The shape of the plug varies with the country or region of
purchase.
D Cautions: Charging
• Only EN‑EL15c and EN‑EL15b batteries can be charged while inserted
in the camera. EN‑EL15a batteries can be charged using an optional
MH‑25a battery charger.
• Charging errors caused by, for example, elevated camera
temperatures or attempts to charge an EN‑EL15a are indicated by the
charge lamp ashing rapidly for about 30 seconds before turning o.
• After the charge lamp turns o, we recommend that you turn the
camera on (or activate the standby timer) and conrm that the battery
is charged.
Tip: Charging with Third-Party USB Type-C and PD (Power Delivery) Compatible
AC Adapters
• You can use third‑party AC adapters to charge the camera battery. Use
an AC adapter equipped with USB Type‑C connectors that supports
USB PD (power delivery).
• Use an AC adapter with a minimum output of 27 W (9 V/3 A).
• Use a USB cable that has Type‑C connectors on both ends to connect
to the camera.
• We do not guarantee that all third‑party AC adapters and USB cables
will be able to charge the camera battery.
Tip: Computer USB Power Delivery and Battery Charging
Computers connected by the supplied USB cable can charge the battery
or supply power to the camera when the battery is inserted into the
camera. For more information, see the “Reference Guide.”
Inserting Memory Cards
The camera is equipped with two memory card slots (Slots 1 and
2), allowing simultaneous use of two memory cards.
• Turn the camera o before inserting or removing memory cards.
• Holding the memory card in the orientation shown, slide it
straight into the slot until it clicks into place.
128
GB
Attaching a Lens
• The camera can be used with Z mount lenses. For more
information on lenses, see the lens documentation available from
the Nikon Download Center.
• The lens generally used in this document for illustrative purposes
is a NIKKOR Z 24–70mm f/4 S.
• Be careful to prevent dust entering the camera.
• Conrm that the camera is o before attaching the lens.
Ŭ Remove the camera body cap (q, w) and rear lens cap (e, r).
Ŭ Align the mounting marks on the camera (t) and lens (y). Do not
touch the image sensor or lens contacts.
Ŭ Rotate the lens as shown until it clicks into place (u).
• Remove the front lens cap before taking pictures.
Opening the Monitor
Rotate the monitor gently; do not use force.
Camera Setup
Turn the camera on, choose a language, and set the clock. Before
using the camera for the rst time, follow the steps below to
choose a language and time zone and set the clock so that the
correct time and date will be recorded with any pictures you take.
1
Press G, and in the setup menu
highlight [Language] and press 2.
2
Select a language.
Press 1 or 3 to highlight the desired language and press J
(the languages available vary with the country or region in
which the camera was originally purchased).
3
Highlight [Time zone and date] and
press 2.
4
Choose a time zone.
• Select [Time zone] in the [Time zone
and date] display.
• The display lists selected cities in
the chosen zone and the dierence
between the time in the chosen zone
and UTC.
• Highlight a time zone in the [Time
zone] display and press J.
5
Turn daylight saving time on or o.
• Select [Daylight saving time] in the
[Time zone and date] display.
• Select [ON] (daylight saving time on)
or [OFF] (daylight saving time o).
• Selecting [ON] advances the clock
one hour; to undo the eect, select
[OFF].
6
Set the clock.
• Select [Date and time] in the [Time
zone and date] display.
• Press J after using the multi selector
to set the clock to the date and time
in the selected time zone in the [Date
and time] display (note that the
camera uses a 24‑hour clock).
7
Choose a date format.
• Select [Date format] in the [Time
zone and date] display.
• Highlight the desired date (year,
month, and day) display order and
press J.
8
Exit the menus.
Lightly press the shutter‑release button halfway to
exit to shooting mode.
Easy Photography (b Mode)
D Lenses with Retractable Barrels
Lenses with retractable barrels must be
extended before use. Rotate the zoom
ring as shown until the lens clicks into
place in the extended position.
1
Select photo mode by rotating the
photo/video selector to C.
2
Rotate the mode dial to AUTO (b).
3
Ready the camera.
4
Frame the photograph.
5
To focus, press the shutter-release button halfway
(i.e., lightly press the shutter-release button,
stopping when it is pressed halfway).
6
Without lifting your nger from the shutter-
release button, press the button the rest of the
way down to take the picture.
Easy Video Recording (b Mode)
1
Select video mode by rotating the
photo/video selector to 1.
2
Rotate the mode dial to AUTO (b).
3
Press the video-record button to start
recording.
• A recording indicator will be displayed
and the borders of the shooting
display will turn red. The display also
shows the time remaining, or in other
words the approximate amount of
new footage that can be recorded to
the memory card.
12
4
3
1
Recording indicator
2 Video recording time (length
of footage recorded)
3 Available recording time
4 Recording indicator (red
border)
4
Press the video-record button again to end recording.
Playback
Press the K button to view photos and
videos in the monitor or viewnder after
shooting.
• Press 4 or 2 or ick left or right to view
additional pictures.
• Videos are indicated by a 1 icon at the top left corner of
the display. Tap the a icon in the display or press J to start
playback.
• To end playback and return to shooting mode, press the shutter‑
release button halfway.
Caring for the Camera
Long-Term Storage
Remove the battery if the product will not be used for an extended period. Before
removing the battery, conrm that the camera is o.
Do not store the camera in locations that:
• are poorly ventilated or subject to humidities of over 60%,
• are next to equipment that produces strong electromagnetic elds, such as
televisions or radios, or
• are exposed to temperatures above 50 °C (122 °F) or below −10 °C (14 °F).
Troubleshooting
You may be able to resolve any issues with the camera by following the steps
below. Check this list before consulting your retailer or Nikon‑authorized service
representative.
1
Check the list of common problems.
Common problems and solutions are listed in the troubleshooting section of
the Reference Guide.
2
Turn the camera o and remove the battery, then wait about a minute, re-insert the battery
and turn the camera on.
D The camera may continue to write data to the memory card after shooting.
Wait at least a minute before removing the battery.
3
Search Nikon websites.
• For support information and answers to frequently asked questions, visit the
website for your country or region (see “Nikon User Support” at the top left
corner of this page).
• To download the latest rmware for your camera, visit:
https://downloadcenter.nikonimglib.com/
4
Consult a Nikon-authorized service representative.
DIGITAL CAMERA
Printed in Thailand
6MO17311-02
SB5D02(11)
User's Manual (with Warranty)
En
Nikon Z5II
Warranty Terms - Nikon Europe Service Warranty
Dear Nikon Customer,
We thank you for your purchasing this Nikon product. Should your Nikon product
require warranty service, please contact the dealer from whom it was purchased
or a member of our authorized service network within the sales territory of Nikon
Europe B.V. (e.g. Europe/Russia/others). See details under:
https://www.nikoneurope.com/
In order to avoid any unnecessary inconvenience, we advise you to read the user
manuals carefully before contacting the dealer or our authorized service network.
Your Nikon equipment is guaranteed against any manufacturing defects for one
full year from the date of original purchase. If during this period of guarantee
the product proves defective due to improper material or workmanship, our
authorized service network within the sales territory of Nikon Europe B.V. will,
without charge for labor and parts, repair the product in the terms and conditions
set as below. Nikon reserves the right (at its sole discretion) to replace or repair
the product.
1. This warranty is only provided upon presentation of the completed warranty
card and original invoice or purchase receipt indicating the date of purchase,
product type and dealer’s name, together with the product. Nikon reserves the
right to refuse free-of-charge warranty service if the above documents cannot
be presented or if the information contained in it is incomplete or illegible.
2. This warranty will not cover:
• necessary maintenance and repair or replacement of parts due to normal
wear and tear.
• modifications to upgrade the product from its normal purpose as described
in user manuals, without the prior written consent of Nikon.
• transport costs and all risks of transport relating directly or indirectly to the
warranty of the products.
• any damage resulting from modifications or adjustments which may be
made to the product, without the prior written consent of Nikon, in order
to comply with local or national technical standards in force in any other
country than the ones for which the product was originally designed and/or
manufactured.
3. The warranty will not be applicable in the case of:
• damage caused by misuse including but not limited to failure to use the
product for its normal purpose or according to the user instructions on
the proper use and maintenance, and to installation or use of the product
inconsistent with the safety standards in force in the country where it is used.
• damage caused by accidents including but not limited to lightning, water,
fire, misuse or neglect.
• defacing, illegibility or removal of the model or serial number on the
product.
• damage resulting from repairs or adjustments which have been conducted
by unauthorized service organizations or persons.
• defects in any system into which the product is incorporated or with which
it is used.
4. This service warranty does not affect the consumer’s statutory rights under
applicable national laws in force, nor the consumer’s right against the dealer
arising from their sales/purchase contract.
Notice: An overview of all authorized Nikon Service Stations can be found online
by following this Link
(URL = https://www.nikoneurope.com/).
Z5II Model Name: N2326
Nikon User Support
Should you need technical support, we
oer a number of options.
• For users in the U.S.A.:
https://www.nikonusa.com/
• For users in Canada:
https://www.nikon.ca/
• For users in Mexico:
https://www.nikon.com.mx/
• For users in Latin America:
https://www.nikonamericalatina.com/
• For users in Europe:
https://www.nikoneurope.com/
• For users in Asia, Oceania, the Middle East, and
Africa: https://www.nikon-asia.com/
• Read this document thoroughly before using the camera.
• To ensure proper use of the camera, be sure to read “For Your Safety” (overleaf).
• After reading this document, keep it readily accessible for future reference.
No reproduction in any form of this document, in whole or in part (except for brief quotation in
critical articles or reviews), may be made without written authorization from NIKON CORPORATION.
En_02
The Z5II User’s Manual and Reference Guide
In addition to this User’s Manual, a Reference Guide is available
for your camera.
The User’s Manual (This Document)
The User’s Manual describes basic camera operations.
The Reference Guide
Camera features and operations are detailed
in a Reference Guide, a supplement to the
User’s Manual. The Reference Guide can be
viewed on computers, smartphones, and
tablets.
View the Reference Guide (Web Edition):
nikon reference guide Z5II
https://onlinemanual.nikonimglib.com/z5II/en/
Download the Reference Guide
(PDF Edition):
nikon download center Z5II
SAMPLE
Produktspecifikationer
| Varumärke: | Nikon |
| Kategori: | fotokamera |
| Modell: | Z5 II |
Behöver du hjälp?
Om du behöver hjälp med Nikon Z5 II ställ en fråga nedan och andra användare kommer att svara dig
fotokamera Nikon Manualer
6 Oktober 2025
23 Augusti 2025
1 Juni 2025
fotokamera Manualer
- Denver
- Chauvet
- Sony
- Minolta
- Speco Technologies
- Fujifilm
- Hamilton Buhl
- Lorex
- Agfaphoto
- Roesle
- Fluke
- Rollei
- Flir
- Aida
- Casio
Nyaste fotokamera Manualer
13 Oktober 2025
13 Oktober 2025
13 Oktober 2025
11 Oktober 2025
11 Oktober 2025
10 Oktober 2025
10 Oktober 2025
10 Oktober 2025
9 Oktober 2025
