Sida 1/8
www.noctua.at/home
1
8 channel fan hub for 5V, 12V, and 24V fans
User
Manual
NOCTUA NV-FH2
The NV-FH2 is a flexible, premium-quality 8 channel PWM fan hub that is ideal for powering up to eight fans in
home, office or multi-purpose ventilation applications using an external power supply with 5.5mm barrel
connector such as Noctua’s optional NV-PS1. It’s compatible with 5, 12, and 24V fans with 4-pin PWM and 3-pin
connectors and supports up to 60W total power draw.
Topped off with CE, UKCA and UL certifications, full compliance with all applicable safety standards as well as
Noctua’s 6-year manufacturer’s warranty, the NV-FH2 represents the gold standard in highly robust
multi-purpose splitter boards that work just as nicely inside a PC as in other ventilation applications.
NV-FH2
fan hub
Included parts
NOCTUA NV-FH2
8 channel fan hub for 5V, 12V, and 24V fans
www.noctua.at/home
2
NV-FH1 SPECIFICATIONS
Output connectors
Input connectors
8x 4-pin PWM
1x 5.5mm (outer diameter) / 2.1mm
(inner diameter) barrel connector,
1x 4-pin PWM
Max. power via barrel conector input 60 W
Max. power via 4-pin PWM input 22 W
Operating voltage
5-24 V
Operating temperature -40°C to +60°C
Flammability class
Safety standards
Certifications
EN 62368-1, EN 55035, EN 55032,
UL-62368
CE, UKCA, UL
Size
Weight 47 g
Fan compatibility All Noctua 24V, 12V, and 5V fans,
many third party fans
UL-94 V-0
93x62x12.5mm (without cover) /
93x62x19mm (with cover)
Warranty 6 years
NV-FHC2
Top cover
www.noctua.at/home
3
Resettable fuses
For maximum safety, the NV-FH2 has auto-
resetting fuses on the 4-pin input (1.85A) and each
individual 4-pin output (0.75A) so that it can
automatically shut down in case of overcurrent or
short-circuits on one of the connected devices or
cables. If one of the fuses has blown, simply
disconnect the NV-FH2 from all power sources for
1 minute to reset it.
Make sure that current ratings and maximum
operating temperature are within the specified
limits before reconnecting.
Interfaces
5.5mm (outer diameter) /
2.1mm (inner diameter)
barrel power input
4-pin power input
& control interface
Fan output 1
(RPM monitoring input)
Fan output 5
Fan output 3
Fan output 7
Fan output 2
Fan output 6
Fan output 4
Fan output 8
- 24/12/5V
- 60W max.
- 5V/12V/24V fans
- 22W max.
- PWM control input
(from motherboard, NA-FC1, etc.)
- RPM monitoring output
(to motherboard, NA-FC1, etc.)
When powering the NV-FH2 via the 4-pin input
from a PC motherboard, please check your
motherboard manual for the maximum current of
the fan header and make sure not to exceed it.
Caution!
