NA-SFMA1

User Manual

www.noctua.at

This manual will guide you through the instal-

lation process step by step using an NF-A12x25

fan as an example.

Should you encounter any difficulties, please

check the FAQs on our website (www.noctua.at/

faqs) and don’t hesitate to contact our support

team at support@noctua.at.

Designed in Austria, Noctua’s premium cooling

components are internationally renowned for

their superb quietness, exceptional performance

and thoroughgoing quality.

Having received more than 6000 awards and

recommendations from leading hardware

websites and magazines, Noctua’s fans and

heatsinks are chosen by more than a hundred

thousand satisfied customers around the globe.

sales@noctua.at

www.noctua.at

F = fan side

Scope of delivery:

2x NA-FMA1 adaptor

8x NA-AV4 anti-vibration mounts

NA-SFMA1

User Manual

www.noctua.at

Caution: Only pull pawl 5 through the hole. Don’t overstretch the mounts

by pulling the next pawl through!

Then put on the 120x25mm fan so that the tips of the anti-vibration

mounts stick through the fan’s mounting holes. Pull on the tips to fix the

fan until pawl number 5 is all the way through.

First pull the NA-AV4 anti-vibration mounts through the fan mounting holes of the adaptor.

Finally put the adaptor on your water cooling radiator (or other application)

and fix it with the screws supplied with the radiator. For other applications,

you can use either standard fan screws or other, custom screws to fix the

adaptor.

If the long ends of the mounts are in the way, you can use scissors to

cut them after installation. Note that this will then make them difficult to

reinstall in the future.
