User’s Guide
C610/C711
59320301 my.okidata.com
2 – C610/C711 User’s Guide
Copyright Information
Copyright © 2009 by Oki Data. All Rights Reserved
C610/C711 User’s Guide
P/N 59320301, Revision 1.0
September, 2009
Disclaimer
Every effort has been made to ensure that the information in this
document is complete, accurate, and up-to-date. The
manufacturer assumes no responsibility for the results of errors
beyond its control. The manufacturer also cannot guarantee that
changes in software and equipment made by other manufacturers
and referred to in this guide will not affect the applicability of the
information in it. Mention of software products manufactured by
other companies does not necessarily constitute endorsement by
the manufacturer.
While all reasonable efforts have been made to make this
document as accurate and helpful as possible, we make no
warranty of any kind, expressed or implied, as to the accuracy or
completeness of the information contained herein.
The most up-to-date drivers and manuals are available from the
web site:
http://www.okiprintingsolutions.com
Trademark Information
Oki and Oki Data are registered trademarks of Oki Electric Industry
Company Ltd.
Apple, Macintosh and Mac OS are registered trademarks of Apple
Computers Inc.
Hewlett-Packard, HP, and LaserJet are registered trademarks of
Hewlett-Packard Company.
Microsoft, MS-DOS and Windows are either registered trademarks
or trademarks of Microsoft Corporation in the United States and/
or other countries.
Other product names and brand names are registered trademarks
or trademarks of their proprietors.
3 – C610/C711 User’s Guide
Emergency First Aid
Take care with toner powder:
If swallowed, give small amounts of cold water and seek
medical attention. DO NOT attempt to induce vomiting.
If inhaled, move the person to an open area for fresh
air. Seek medical attention.
If it gets into the eyes, flush with large amounts of water
for at least 15 minutes keeping eyelids open. Seek
medical attention.
Spillages should be treated with cold water and soap to
help reduce risk of staining skin or clothing.
Note:
Images used in this manual may include optional
features that your product does not have installed.
5 – C610/C711 User’s Guide
Contents (cont.)
Available Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Duplex (two-sided printing) Unit . . . . . . . . . . . . . . . . . . . . . . 67
Additional RAM Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Additional Paper Tray(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Major Printer Components and Paper Path . . . . . . . . . . . . . 70
Paper Sensor Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Clearing Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Replacing Consumables and Maintenance Items . . . . . . . . . . . .83
Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Toner Cartridge Replacement . . . . . . . . . . . . . . . . . . . . . . . 84
Image Drum Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . 90
Replacing the Transfer Belt Unit . . . . . . . . . . . . . . . . . . . . . . 96
Fuser Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Cleaning the LED Head . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Summary of Utilities Provided. . . . . . . . . . . . . . . . . . . . . . . 106
Utilities on the CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Utilities on the Web (Windows Only) . . . . . . . . . . . . . . . . 107
Installing the Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
6 – C610/C711 User’s Guide
Notes, Cautions and Warnings
Note:
A note appears in this manual like this. A note provides
additional information to supplement the main text
which may help you to use and understand the product.
CAUTION!
A caution appears in this manual like this. A caution
provides additional information which, if ignored, may
result in equipment malfunction or damage.
WARNING!
A warning appears in this manual like this. A warning
provides additional information which, if ignored, may
result in a risk of personal injury.
8 – C610/C711 User’s Guide
Printer Overview ________________
C610 Front View
*The display language can be changed to show English, French,
Spanish or Portuuese.
1. Output stacker, face down
Standard printed copy delivery
point. Holds up to 250 sheets at
80 g/m².
2. Operator panel
Menu driven operator controls and
LCD* panel.
3. Paper tray
Standard paper tray. Holds up to
300 sheets of 80 g/m² paper.
4. Multi purpose tray
Used for feeding heavier paper
stocks, envelopes and other
special media. Also for manual
feeding of single sheets when
required.
5. Paper level indicator
6. Front cover release lever
7. Multi-purpose tray release
recess
8. Top cover release button
9. LED heads
10. Fuser release levers
11. Toner cartridges (C,M,Y,K)
12. ID units (C,M,Y,K)
13. Duplex unit (when fitted)
1
2
3
4
5
9
10
11
6
12
13
7
7
13
8
