Ÿ BATTERY CHARGE

Firstly, slide the USB port cover aside, then connect the flashlight to external

USB power supply, the status indicator turn on means charging is in process.

Thank you for purchasing Olight products! Please read this manual

carefully before use.

Within 30 days of purchase: Return to retailer from which you purchased

for repair or replacement.

Within 5 years of purchase:Return to Olight for repair or replacement.

This warranty does not cover normal wear and year,modifications, misuse,

isintegrations,negligence, accidents, improper maintenance, or repair by

anyone other than an Authorized retailer or Olight itself.

NOTE:

One of the following output modes low, medium, high, will be

memorized when the light shutting off. The flashlight will not

memorize the low mode when the light is activated to low mode

directly before it is turned off. For high mode, the light will only

memorize high mode for 10 minutes when the light is off, after 10

minutes the memorized mode will switch to medium mode.

Technical support: techsupport@olightworld.com

Customer service: cs@olightworld.com

Website: www.olightworld.com

WARRANTY

SPECIFICATIONS

1,600 lumens / 3 hours

600 lumens / 8 hours

120 lumens / 36 hours

10Hz

3xCree XM-L2 CW

2.8 to 6v

18,000cd

268 meters

3 x 18650 (with protecting circuit board)

Type Ⅲ hard anodized aluminum

IPX8

L 132mm x D 47.5mm / 5.2in x 1.9in

Ÿ TURN ON/OFF

Quick click the side switch to turn the flashlight on or off. The light will turn to

the last output mode before shutting off.

Ÿ CHANGE BRIGHTNESS LEVELS

With the light on, press and hold the side switch, the output will cycle through

low, medium, and high brightness levels. Release the side switch when the

desired brightness level is achieved.

Ÿ LOW MODE

With light off, press and hold the side switch for more than 1 second, the low

mode will be activated.

Ÿ TURBO MODE

Double-click the side switch to activate turbo mode if the light is in non-

locking state.

Ÿ STROBE MODE

When the light is in non-lock state, Triple-click side switch to activate strobe

mode. Click the side switch once to quit strobe mode, press and hold side

switch to turn on the setting of changing brightness level.

Ÿ LOCK MODE

With the light off, press the side switch and hold for 1 second to activate low

mode, keep holding the switch for one more second, the light will shut off

automatically and lock the side switch. Under lock state, click and release the

switch, the red indicator will last for 2 seconds.

Ÿ UNLOCK MODE

When the light is off, press and hold side switch for more than 2 seco

nds, the

switch is enable and activate low mode. User may twist the tail cap anti-

clockwise to turn off the light, tighten the tail cap clockwise to unlock the

light.

Ÿ STATUS INDICATOR

There is a multi-purpose status indicator lamp at the upside of the USB

charging port to indicate the battery low voltage or charging state:

Battery low voltage indication: When the battery voltage is less than 3.25V,

the status indicator lamp will flicker in red; when the battery voltage is less

than 3.05V, the status indicator lamp will be a constant red.

Charging state indication: red means und

er charging; green means fully

charged.

3,200 lumens

All performance claim to ANSI/NEMA FL1-2009 standard

Made in China

TURBO

HIGH

MED

LOW

STROBE

LED

Operate Voltage

Candela

Beam Distance

Supported Batteries

Material

Water-proof

Impact Resistance

Dimensions

Weight

181g / 6.4oz (excluding batteries)

1.5 meters

SUPPORTED BATTERIES

INSIDE THE BOX

Flashlight, holster, USB cable, user manual (this manual), and other optional

accessories( refer to the label marks outside of box for detail)

3 x 18650 rechargeable lithium batteries with protecting circuit board , the

batteries must have a protruding button on positive pole.

Note: Tes ts performe d with 3 x1865 0 batteri es (34 00mAh ,3.6v)

OPERATION INSTRUCTION

Ÿ BATTERY INSTALLATION

Before use, install the batteries and notice that the battery positive towards

the flashlight head, then tightly screw the tail-cap as shown below.

WARNING:

CONTACT

Do not mix rechargeable and non-rechargeable batteries.

Do not mix batteries of different types/brands.

Properly install the batteries, the positive of battery towards the head of

the flashlight, three batteries are in same direction.

The product only support the batteries with protruding button on the

positive and with protecting circuit board, recommend to use the battery

cell capacity of 18650 with 3000mAh or above.

Low battery protection: if the battery v

oltage drop down to 2.7V, the

flashlight will not turn on, the indicator will emit red color when the switch

is pressed.

Use caution for long runtimes at high level and turbo as flashlight may get

hot.

Three batteries are parallelly connected inside the flashlight, either 1 or 2

or 3 batteries are able to turn the flashlight on,it is better not to use Turbo

when using 1 or 2 batteries, it may cause to suddenly shut down due to

battery protection.

Please choose 5V 2.1A USB power supp

ly or higher rate power supply to

charge the flashlight.

Side switch

Charge indicator /

Low voltage indicator

Micro-USB

Charging Port

Output
