Sida 1/28

8kg Front Load

Washing Machine

OFLW800W

V1.0 1223User Manual

Designed to Enhance

E S T. � 9 8 �

@omegaappliances_aus

omegaappliances.com.au

02 OFLW800W

User Manual

Contents

Welcome

Safety Information

Your Front Load Washer

Installation Instructions

Quick Start Guide

Operating Instructions

Cleaning & Maintenance

Troubleshooting

Purchase Details

Warranty Information

User Manual

Congratulations on purchasing your Front Load Washer.

Omega appliances are proudly owned and distributed within

Australia by Residentia Group Pty Ltd.

Please refer to the warranty chapter at the rear of this manual

for information regarding your product’s parts and labour

warranty, or visit us online at:

→ residentiagroup.com.au

Here at Residentia Group, we are customer obsessed and our

Support Team are there to ensure you get the most out of your

appliance. Should you want to learn more about your unit, and

importantly, taking care of the appliance, our Support Team are

here to help. You can use our online Support Centre at any time

by visiting:

→ support.residentiagroup.com.au

Or you can contact us by dialling: 1300 11 HELP (4357)

It is important that you read through the following user manual

thoroughly, in order to familiarise yourself with the installation

and operation requirements of your appliance, and to ensure

optimum performance.

Again, thank you for choosing an Omega appliance.

We look forward to being of service to you.

Kind Regards,

The Residentia Team

Residentia Group

—

Head Office

165 Barkly Avenue

Burnley Victoria

Australia 3121

—

ACN

600 546 656

—

Online

residentia.group

omegaappliances.com.au

@omegaappliances_aus

—

Postage

PO BOX 5177, Burnley

VIC Australia 3121

—

Telephone

1300 11 4357

—

support@residentia.group

Welcome

Customer Care

—

At Residentia Group, we strongly encourage the use of authentic spare parts to guarantee the best results.

When contacting our spare parts team through 1300 11 HELP, or by emailing parts@residentiagroup.com.au,

please ensure that you have the model and serial numbers on hand, which are found on your appliances’ rating plate.

04 OFLW800W

User Manual

Safety Information

Intended Use

•The product is intended only for domestic home use and

for textiles in household amounts suitable for washing.

•This appliance is for indoor use only and not intended for

built in use. Only use according to these instructions.

•The appliance is not intended for commercial use.

•Any other use is considered as improper use.

The manufacturer is not responsible for any damage

or injury that may result from it.

•This appliance is intended to be used in household and

similar applications such as:

•Staff kitchen areas in shops, offices and other working

environments;

•Farm houses;

•By clients in hotels, motels and other residential type

environments;

•Bed and breakfast type environments;

•Areas for communal use in blocks of flats or in

launderettes.

Key Words

• DANGER:

This key word indicates that there are dangers to the life

and health of persons due to extremely flammable gas.

• ELECTRICAL WARNING:

These key words indicates that there is a danger to life and

health of persons due to voltage.

• WARNING:

This key word indicates a hazard with a medium level

of risk which, if not avoided, may result in death or

serious injury.

• CAUTION:

This key word indicates a hazard with a low degree

of risk which, if not avoided, may result in minor or

moderate injury.

• NOTE:

This key word indicates important information

(e.g. damage to property or appliance), but not danger.

• OBSERVE INSTRUCTIONS

These key words indicates that a service technician should

only operate and maintain this appliance in accordance

with the operating instructions.

Important Safety Instructions

•Please read the following safety information thoroughly

and follow it strictly to minimise the risk of fire or explosion,

electric shock and to prevent property damage, personal

injury or loss of life. Failing to follow these instructions shall

void any warranty.

•This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety.

• ELECTRICAL WARNING: ELECTRIC SHOCK HAZARD

If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

•If the machine is damaged, it must not be operated unless

repaired by the manufacturer, its service agent or similarly

qualified persons.

• RISK OF ELECTRIC SHOCK!

The appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge

•if they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall

not be made by children without supervision.

•Children should be supervised that they do not play with

the appliance.

•Children 3 years and under shall be kept away from the

appliance or continuously supervised.

•Animals and children may climb into the machine.

Check the machine before every operation.

•Do not climb or sit on the appliance.

User Manual

Safety Information (Continued)

Installation Location and Surrounding

•All washing and additional substances are to be kept in a

safe place out of the reach of children.

•Do not install the machine on a carpet floor.

The obstruction of the openings by a carpet can damage

the machine.

•Keep the appliance clear from heating sources and direct

sunlight to avoid plastic and rubber parts to corrode.

•Do not use the appliance in humid environments or rooms

containing explosive or caustic gas. In case of water

leakage or water splashes, let the appliance dry in the

open air.

•The appliance must not be installed behind a lockable

door, a sliding door or a door with a hinge on the opposite

side to that of the machine .

•Do not operate the machine in rooms with a temperature

of below 5°C. This can cause damages to parts of it. If it is

unavoidable, make sure to drain the water completely from

the appliance after every use (see “Maintenance - Cleaning

of drain pump filter”) to avoid damages caused by frost.

•Never use flammable sprays or substances in the

immediate proximity of the appliance.

Installation

•Remove all packaging material and transport bolts

before using the appliance. Otherwise, serious damage

may result.

•This appliance is equipped with a single inlet valve and can

be connected to the cold water supply only.

•Mains plug must be accessible after installation.

•Before washing clothes for the first time, the product shall

be operated once throughout all the procedures without

any clothes inside.

•Before using the machine, the product shall be calibrated.

•Do not put any excessively heavy objects on the appliance,

like water containers or heating devices.

•The new hose-sets supplied with the appliance are to be

used and that old hose-sets should not be reused.

•Max. Inlet water pressure 1 MPa. Min. inlet water pressure

0.05 MPa.

Electrical Connection

•Make sure the supply cable is not trapped by the machine,

or it can get damaged.

•Connect the product to a grounded outlet protected

by a fuse complying with the values in the "Product

Specifications” table. The grounding installation has to be

made by a qualified electrician. Ensure that the machine is

installed in accordance with the local regulations.

•Water and electrical connections must be carried out by a

qualified technician in accordance with the manufacturer's

instructions and local safety regulations.

• WARNING: Don't use multiple plugs or extension cords.

•The appliance must not have an external switching device

such as a timer or connected to a circuit that is regularly

switched on and off.

•Do not pull the plug out of the mains outlet if there is

flammable gas around.

•Never pull out power plug with wet hands.

•Always pull at the plug, not at the cable.

•Always unplug the appliance if it is not being used.

Water Connections

•Check the connections of the water inlet tubes, the water

tap and the outlet hose for possible problems due to

changes of water pressure. If the connections loosen or

leak, close the water tap and get it repaired.

•Do not use the appliance before the pipes and hoses are

installed properly by qualified persons.

•Glass door may become very hot during the operation.

Keep children and pets far away from the machine while it

is operating.

•The water inlet and outlet hoses have to be safely

installed and remain undamaged. Otherwise, water

leakage can occur.

•Do not remove the drain pump filter while there is still

water in the appliance. Big quantities of water can leak out,

and there is a risk of scalding due to hot water.

06 OFLW800W

User Manual

Operation and Maintenance

• WARNING: Never use any flammable, explosive or

toxic solvents. Do not use gasoline and alcohol etc. as

detergents. Only select detergents that are suitable for

machine washing.

•Make sure that all pockets are emptied. Sharp and rigid

items such as coins, brooches, nails, screws, stones etc.

may cause serious damages to this machine.

•Remove all objects from pockets such as lighters and

matches before use the appliance.

•Thoroughly rinse items that have been washed by hand.

•Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, wax and wax removers should be

washed in hot with an extra amount of detergent before

being dried in the appliance.

•Items containing foam rubber (latex foam), shower caps,

water proof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried in

the machine.

•Fabric softeners or similar products should be used are

recommended in their instructions.

•Never try to open the door forcefully.

•The door will unlock shortly after the end of a cycle.

•Please do not close the door with excessive force. If it is

found difficult to close the door, please check if the clothes

are properly inserted and distributed.

•Always unplug the appliance and close the water tap

before cleaning and maintenance and after each use.

• ELECTRICAL WARNING: RISK OF ELECTRIC SHOCK!

Never pour water over the appliance for cleaning purpose.

•Repairs shall only be carried out by the manufacturer, its

service agent or similarly qualified persons in order to

avoid a hazard.

•The producer will not be responsible for damages caused

by the intervention of not authorised persons.

Transport

Before Transport:

• IMPORTANT: Re-install the 4 transport bolts in the

back of the appliance (see page 09).

•Unplug the appliance and close the water inlet tap and

remove the water inlet pipe and the outlet hose from the

house installations.

•Check, if the door and the detergent dispenser are

closed properly.

•Let the water drain completely from the appliance

(see “Cleaning the Drain Pump Filter”)

IMPORTANT: This appliance is heavy. Transport with care.

Never hold any protruding part of the machine when lifting.

The machine door can not be used as a handle.

Disposal of Packaging

The packaging is designed to protect the appliance from

damage during transportation. The packaging materials are

environmentally friendly and should be recycled. Recycling

the packaging can reduce the use of raw materials in the

manufacturing process and the amount of waste in landfill.

Packaging materials of the product are manufactured

from recyclable materials in accordance with our National

Environment Regulations. Do not dispose of the packaging

materials together with the domestic or other wastes. Take

them to the packaging material collection points designated

by the local authorities.

Disposal & Recycling

Important Instructions for Environment: Compliance with

the WEEE Directive and Disposing of the Waster Product:

This product complies with EU WEEE Directive (2012/19/

EU). This product bears a classification symbol for waster

electrical and electronic equipment (WEEE).

This symbol indicates that this product shall not be disposed

with other household wastes at the end of its service life.

Used device must be returned to offcial collection point

for recycling of electrical electronic devices. To find these

collection systems please contact to your local authorities

or retailer where the product was purchased. Appropriate

disposal of used appliance helps prevent potential negative

consequences for the environment and human health.

Safety Information (Continued)

User Manual

Your Front Load Washer

Front Rear

A. Control Panel

B. Detergent Dispenser

C. Door

D. Service Panel

E. Adjustable Feet

F. Drain Hose

G. Power Supply Cord

NOTE: The diagrams in this user manual are for explanatory purposes only. Your appliance may appear differently.

Product Specifications

Model OFLW800W

Washing Capacity 8.0 kg

Dimensions (W × D × H) 595 × 540 × 850 mm

Depth with door open 985 mm

Height of Control Panel 135 mm

Weight 63 kg

Rated Power 1950W

Power Supply 220–240V~, 50Hz

Max. Current 10A

Standard Water Pressure 0.05MPa–1MPa

Parts and Accessories

Your Front Load Washer comes with the following

accessories:

•4 × Cover caps (for transport bolt holes)

•1 × Cold water supply hose

•4 × Acoustic sponge strips

•1 × User Manual

•1 × Quick Start Guide

User Manual

Removing the Transport Bolts

WARNING: You must remove the transport bolts from the

backside before using the product.

1. Loosen the 4 transport

bolts with a spanner.

2. Remove the bolts including

the rubber parts and keep

them for future use.

3. Close the holes using

the cover caps.

Acoustic Sponge

NOTE: Please make sure to assemble the acoustic sponge

strips, which can effectively reduce the noise caused by the

machine while working, in order to provide you with a more

peaceful and quiet living environment.

1. Lay the machine on the floor, using some soft

material like foam or clothes between the machine

and floor for protection.

2. Apply the 2× longer sponges to the long bottom edges

of machine, and the 2× shorter sponges to the short edges.

Connect the Water Supply Hose

• WARNING: To prevent leakage or water damage, follow

the instructions in this chapter.

• WARNING: Do not kink, crush or modify water inlet hose.

•Connect the water supply hose to the water inlet valve and

a water tap with cold water as indicated.

• NOTE: Check if the connections are tight.

Connect manually, do not use tools.

Drain Hose

• WARNING: Do not kink or protract the drain hose.

• WARNING: Position drain hose properly, otherwise

damage might result in water leakage.

• WARNING: Do not remove the buckle of the drain pipe.

The are two optional ways to place the end of the drain hose.

1. Put it into the water trough.

2. Connect it to the branch drain pipe of the trough.

Installation Instructions (Continued)

Water trough

Max.

100cm

Min.

60cm

Max. 100cm

Min. 60cm

10 OFLW800W

User Manual

Quick Start Guide

Prior to Operating the Front Load Washer

• CAUTION: Before washing, please make sure the machine

is installed properly.

• CAUTION: Clean your appliance before first use.

Your appliance was thoroughly checked before it left the

factory. To remove any residual water and to neutralise

potential odours, we recommend to clean the inner drum

by running the "Drum Clean" or other program with the

optional temperature of 90° C.

Be careful not to put laundry and detergent in the machine

when performing the Drum Clean program.

Calibrating the Front Load Washer

• IMPORTANT: It’s recommended to calibrate the machine,

so that provide the best performance. The appliance is

able to detect the amount of laundry loaded. This function

is optimising the product performance by minimising

energy and water consumption, saving you money and

time. For this reason it’s recommended to calibrate the

appliance for best use.

1. Remove all accessories from the drum and close the door;

2. Insert the mains plug to the socket;

3. Switch on the washing machine and within 10 seconds,

press "Wash Temp." and "Speed Wash" simultaneously until

"t19" is displayed;

• NOTE: Before calibration, ensure that there is no load or

water inside the drum.

4. Press the Start/Pause button to start the appliance and

wait till “****” is displayed.

NOTE: At the end of the cycle, the machine will sound an alert

and "End" will be shown on the display.

Before Operation

1. Plug the power plug

into the power socket.

2. Open the tap

3. Load the laundry items

and close the door

4. Add detergent

NOTE: Detergent needs to be added in compartment I

if the pre-wash function is selected.

Operating your Front Load Washer

1. Power on Select program2.

3. Select any options or

additional functions or

keep the default settings

4. Press Start/Pause to start

to program

User Manual

Operating Instructions

• WARNING: Do not wash articles that have been cleaned

in, washed in, soaked in, or dabbed with combustible or

explosive substances like wax, oil, paint, gasoline, alcohol,

kerosene, and other flammable materials.

• WARNING: Washing single clothing items may easily

create big eccentricity. Therefore it is suggested to add

one or two more laundry items to the wash so that spin can

be done smoothly.

• WARNING: Do not wash, spin water-proof seats, mats,

or clothing.

1. Remove any items from

the pockets

2. Sort laundry according by

colour and textile type

Before Each Washing Cycle

•The ambient temperature of the machine should be

5°C-40°C. If used under 0°C, the inlet valve and draining

system may be damaged. If the machine is installed under

freezing conditions, it should be transferred to normal

ambient temperature to ensure the water supply hose and

drain hose can unfreeze before use.

•Please check your laundry care labels and the detergent

use instructions before wash. Use non-foaming or less-

foaming detergent suitable for machine properly.

The Detergent Dispenser

Prewash

Main Wash

Softener

Release button to pull out the dispenser

• CAUTION: Detergent only need to be added in

"compartment I" after selecting pre-wash function.

• CAUTION: Do not put laundry beads into

the detergent dispenser.

•Refer to the table on page 16 for detergent and softener

recommendations based on the program type.

3. Tie together long textile

strings and belts, close

zips and button

4. Place delicate or small

items into a laundry bag

12 OFLW800W

User Manual

Operating Instructions (Continued)

BA C

D E

A. Program selection dial

B. LED Display: Showing settings,

estimated remaining time, options

and status messages.

C. Power button

D. Extra Options: Press these buttons to

change the program parameters

or select additional functions.

E. Start/Pause button

Control Panel

A. Display

Wash Time Delay Time Speed

Error End Temp

LED Display

B. Child Lock

C. Door Lock

D. Delay Start

E. Pre Wash → Wash → Rinse → Spin

F. Precise Purify

G. Extra Rinse

H. Pre Wash

I. Speed Wash

GF H I

NOTE: The diagram images in this user manual are for explanatory purposes only. Your appliance may appear differently.

User Manual

Operating Instructions (Continued)

Program Functions

Personalised

To save your most frequently used program and settings.

After selecting the settings and any additional options,

press the Spin Speed and Precise Purify buttons for

3 seconds before beginning the cycle.

The default program is set to Cotton.

Cotton

Hard-wearing textiles, heat-resistant textiles made of cotton

or linen.

Synthetic

Wash synthetic articles, for example: shirts, coats, blending.

While washing the knitting textiles, detergent quantity shall

be reduced due to its loose string construction and easily

forming bubbles.

Mix

Mixed load consisting of textiles made of cotton and

synthetics.

Baby

Washing using the Baby function can make the baby's wear

cleaner and make the rinse performance better to protect

the baby skin.

Sportswear

A specialised cleaning program designed to gently yet

effectively remove stains, odours, and sweat.

Denim

Optimise your denim care with our specialised washing

program, crafted to maintain colour and fabric integrity,

ensuring your jeans stay fresh and vibrant wash after wash.

Quick 45' / 15'

This procedure defaults to Quick 45' , press the “Speed

Wash” to switch to Quick 15'.

NOTE: After the Quick 15’ procedure is completed,

the moisture content of clothes is high.

Steam Shield

Steam is applicable for daily laundries.

The steam can deeply penetrate the fibre, which effectively

eliminate bacteria and germs, preventing odours and

protecting your health.

Cotton ECO

Energy-saving program for hard-wearing textiles,

heat-resistant textiles made of cotton or linen.

20° C

Program suitable for lightly soiled cotton laundry, at a

nominal temperature of 20 °C.

Wool

Hand or machine-washable wool or rich wool textiles.

Especially gentle wash program to prevent shrinkage, longer

program pauses (textiles rest in wash liquid).

Spin Only

Spins and drains the water.

Drum Clean

Specially set in this machine to clean the drum and tube.

It applies 90 °C high temperature sterilisation to make

the clothes washing more clean. When this program is

performed, the clothes or other washing cannot be added.

When proper amount of chlorine bleaching agent is put in,

the barrel cleaning effect will be better. The customer can

use this programme regularly according to the need.

14 OFLW800W

User Manual

Operating Instructions (Continued)

Extra Options

Pre Wash

Extra washing function before the main washing cycle starts

to increase the washing performance.

NOTE: Detergent needs to be added to the compartment I.

Extra Rinse

This function will add an additional extra rinse cycle.

Speed Wash

The function can decrease the washing time.

Precise Purify

Precise Purify offers specific treatments for five scenarios

(Food, Drinks, Sports, Outdoor Work and Beauty) to

intelligently solve according laundry requirements.

Icon Scenario Wash Cycle Typical Stain

Food Cotton, Mix,

Baby

Vegetables, juice

and sauces

Drinks Cotton, Mix,

Baby

Red wine, hot beverage

or soft drinks

Sports Cotton, Mix Grass, dust

or sweat stains

Outdoor

Work

Cotton, Mix Grease, mud or

carbon pigments

Beauty Cotton, Mix Cosmetic, blood

or chemical

Mute

Press the Start, then press Precise Purify & Extra Option

buttons together for 3 seconds. This setting will remain until

the next reset.

NOTE: After activating the mute function, sounds will not be

activated anymore.

Delay Start

Please follow the steps as bellow:

1. Select a program

2. Press the Delay button to choose the delaying time

between 0-24H.

3. Press the Start/Pause button to begin the delay operation.

NOTE: To cancel the Delay function, press the Delay button

before starting the program until the display shows 0H.

If the program has already started, switch the appliance off

and on again, then select a new program.

User Manual

Operating Instructions (Continued)

Washing Temperature

When required, the washing temperature can be adjusted by

pressing the temperature button in the following steps:

Cold → 20° C → 30° C → 40° C → 60° C → 90° C

Spin Speed

When required, the spinning speed can be adjusted by

pressing the Spin Speed button in the following steps:

0 → 600 → 800 → 1000 → 1200 → 1400

Reload

This operation can be executed during the washing progress.

When the drum is still rolling and there is large amount of

water with high temperature in the drum making it unsafe to

open the door – it can also not be opened forcefully.

To begin the Reload function, press the Start/Pause button

for 3 seconds to add the clothes mid cycle.

Please follow the steps as bellow:

1. Wait until the drum stops rotating.

2. The door lock is unlocked.

3. Add in your additional laundry

4. Close the door and press the Start/Pause button.

CAUTION: Do not use the Reload function when the

water level is over the edge of the inner tub or the

temperature is high.

Child Lock

Use this function to avoid any misuse of the controls.

To activate, press the Extra Option & Speed Wash buttons

together for 3 seconds until an alert sounds and the

Child Lock indicator is displayed.

• CAUTION: When activated, the display will alternately

show “CL” and the remaining time.

•Pressing any other buttons will cause the Child Lock

indicator to flash.

•When the program ends, “CL”& “End” will alternate

on the display.

•The Child Lock deactivates the function of all buttons

except the On/Off button and the Child lock button

combination. Only by simultaneous pressing Extra Option

& Speed Wash can deactivate the Child Lock.

•Please deactivate the Child Lock before selecting

a new program.

Refer to the table on page 16 for the availability of additional

functions based on the program type.

16 OFLW800W

User Manual

Operating Instructions (Continued)

Washing Program Table

Program Wash

Load (kg)

Temp.

(°C)

Default

Speed

(RPM)

Default Time

(h:min)

Pre

Wash

Main

Wash

Fabric

Softener

Additional

Functions

Cotton 8.0 40 1000 128 Optional OptionalRequired

Synthetic 4.0 40 1000 125 Optional OptionalRequired

Mix 8.0 40 1000 058 Optional OptionalRequired

Baby 8.0 60 1000 201 Optional OptionalRequired

Sportswear 4.0 20 800 047 Optional OptionalRequired

Denim 8.0 30 800 135 Optional OptionalRequired

Quick 45' 2.0 20 800 045 — Required Optional

Quick 15' 2.0 20 800 015 — Required Optional

Steam Shield 4.0 60 1000 228 RequiredOptional Optional

Cotton ECO —8.0 30 1000 059 Required Optional

20°C —4.0 20 1000 101 Required Optional

Wool —2.0 40 600 107 Required Optional

Spin Only — — — —8.0 1000 012

Drum Clean — — — — —90 118

•Cotton, Synthetic & Mix are auto Weighting programs. When these 3 programs are selected, the washing machine will

automatically adjust the appropriate water level and wash time according to the weight of the laundry during the cycle.

•Energy test program Cotton ECO.

Cotton ECO: Speed: the highest speed; Temp. : 60°C. Other as the default.

Half load for 8.0kg machine: 4.0kg.

•"Cotton ECO" is the standard washing programs to which the information in the label and the fiche relates, and they are

suitable to clean normally soiled cotton laundry and that they are the most efficient programmes in terms of combined

energy and water consumptions for washing that type of cotton laundry, that the actual water temperature may differ

from the declared cycle temperature.

• NOTE: The parameters in this table are only for user's reference. The actual parameters maybe different with the

parameters in above mentioned table

User Manual

Operating Instructions (Continued)

Testing Methods

Model: OFLW800W

ADDITIONAL INFORMATION FOR Standard performance TESTING:(AS/NZS 2040.12021,

AS/NZS 2040.22021, AS/NZS 64002016 AS/NZS 2040.12005+A1+A2+A32010,

AS/NZS 2040.22005+A12012)

1. Water connections: Cold & hot water connection

2. Water supply pressure: 320 kPa

3. Energy Warm Wash Program: Cotton ECO, 1400rpm, 60°C, Display: 629

Energy Cold Wash Program: Cotton Cold (No temperature display is cold wash)

4. Detergent type: Drum detergent

5. Detergent quantity: Default

6. Adding detergent:

The detergent is dissolved and added as Paragraph B7.3 of AS/NZS 2040.1

The detergent shall be dissolved in 1 L of water

7. Anti-sudsing agent: Max

8. Test load mass: 8.0kg

9. Water consumption: 68L

10. Test Voltage: 220-240V~, 50Hz

18 OFLW800W

User Manual

Cleaning & Care

WARNING: Always unplug the appliance and close the water

tap before cleaning and maintenance.

Cleaning the Cabinet

•Proper maintenance on the machine can extend its

working life.

•The surface can be cleaned with diluted nonabrasive

neutral detergents when necessary.

•If there is any water overflow, use a towel to wipe it off

immediately.

•Never use sharp items to clean the appliance.

• CAUTION: Never use abrasive or caustic agents.

Such as formic acids or its diluted solvents or similar

substances, like alcohol or chemical products.

Cleaning the Drum

•Any rust stains left inside the drum by metal articles must

be removed immediately using chlorine-free detergents.

Never use steel wool for cleaning the drum!

• NOTE: Do not place any laundry into the machine when

cleaning the drum.

Cleaning the Door Seals & Glass

•Wipe the glass and seal after each wash to remove lint and

stains. If lint builds up it can cause leakages.

•Remove any coins, buttons and other objects from the seal

after each wash.

•Clean the door seal and glass every month to ensure the

normal operation of the appliance.

Cleaning & Maintenance

5. Reinstall the filter to the water inlet and reconnect the

water supply hose.

6. Clean the Inlet filter every 3 months to ensure the normal

operation of the appliance.

Cleaning the Inlet Filter

NOTE: Diminishing water flow is a sign that the filter needs

to be cleaned.

1. Close the tap and remove

the water supply hose

from it.

2. Clean the filter

with a brush.

3. Unscrew the water supply

hose from the backside

of the machine. Pull out

the filter with long pliers.

4. Use a brush to clean

the filter.

User Manual

1. Open the Service Panel

cover cap.

2. Open the filter by turning

to the counter clockwise.

Cleaning & Maintenance (Continued)

Cleaning the Drain Pump Filter

(Removing foreign objects)

WARNING:

•Make sure that the machine has finished the washing cycle

and is empty. Switch it off and unplug it before cleaning the

drain pump filter.

•Be careful of hot water. Wait for water cooling down.

Risk of scalding!

•Clean the filter periodically every 3 months to ensure the

normal operation of the appliance.

CAUTION:

•Make sure that filter cap is reinstalled properly, cap plates

should be inserted aligning to hole plates otherwise water

may leak.

•Rotate filter lower cover cap directly to make water run into

a tray or basin.

•When the appliance is in use and depending on the

programme selected there can be hot water in the pump.

Never remove the pump cover during a wash cycle,

always wait until the appliance has finished the cycle,

and is empty. When replacing the cover, ensure it is

securely re-tightened.

NOTE:

•Do not use abrasive or caustic agents to clean

plastic parts.

•Clean the detergent dispenser every 3 months to ensure

the normal operation of the appliance.

1. Press the release

and remove the

dispenser drawer

2. Clean the dispenser

drawer and the softener

cover under water

3. Clean the recess with a

soft brush

4. Insert the dispenser

drawer back into place.

Cleaning the Detergent Dispenser

1. Press down the release on the softener cover and pull

the dispenser drawer out of the recess. Clean the inside of

the recess with a brush.

2. Lift the softener cover off the dispenser drawer and wash

both items with water.

3. Restore the softener cover and push the drawer back into

the recess.

3. Remove any foreign

objects matters.

4. Carefully reinsert the filter

and screw the lower cover

cap in clockwise.

User Manual

Operation in case of emergency

In the event of an emergency you should:

•Switch off all Front Load Washer controls.

•Switch the Front Load Washer off at the power outlet and immediately unplug.

•Call the Customer Service team on 1300 11 4357 or email support@residentiagroup.com.au

Some minor faults can be fixed by referring to the instructions given in this Troubleshooting section.

There is also a self-help section online at https://support.residentiagroup.com.au

IMPORTANT: If your appliance appears to be operating incorrectly, then you should disconnect it from your

electrical supply and then contact After Sales Support.

WARNING: Do not attempt to repair the Front Load Washer yourself.

Please note that if an technician is asked to attend whilst the product is under warranty and finds that the problem

is not the result of an appliance fault, then you may be liable for the cost of the call out charge.

The appliance must be accessible for the engineer to perform any necessary repair.

If your appliance is installed in such a way that an engineer is concerned that damage will be caused to the appliance

or your home, then they will not complete a repair.

Please refer to the conditions of that appear on the warranty card at the rear of this user manual.

Troubleshooting (Continued)

22 OFLW800W

User Manual

Attach Your Receipt Here

Produktspecifikationer

Varumärke:	Omega
Kategori:	tvättmaskin
Modell:	OFLW800W
Enhetsplacering:	Vrijstaand
Typ av operation:	Buttons, Rotary
Färg på produkten:	Wit
Dörrgångjärn:	Boven
Inbyggd display:	Nee
Vikt:	56000 g
Bredd:	400 mm
Djup:	600 mm
Höjd:	900 mm
Nettoskatt:	2100 W
Plugg typ:	Type F (CEE 7/4)
Typ av laddare:	Bovenbelading
Dörrfärg:	Wit
Sladdlängd:	1.2 m
Trumminnehåll:	42 l
Fördröjd starttimer:	Ja
Indikering av återstående tid:	Nee
Barnlås:	Ja
Energie-efficiëntieklasse:	C
Vattenförbrukning per cykel:	43 l
Centrifuger läkemedelsklass:	B
Ljudnivå (tvätt):	- dB
Övervakning av lödderskum:	Ja
Obalans kontrollsystem:	Ja
Justerbar centrifughastighet:	Ja
Maximal centrifugeringshastighet:	1200 RPM
Nuvarande:	10 A
Självrengörande:	Nee
Bulleremissionsklass:	B
Inverterteknik:	Nee
Lägg till klädfunktion (paus):	Ja
Ljudnivå under centrifugering:	76 dB
Restfuktprocent:	53 procent
Cykeltid (max):	195 min
Antal tvättprogram:	18
Energiförbrukning per 100 cykler:	56 kWu
Justerbara fötter:	Ja
Kåpa material:	Kunststof
Översvämningsskydd:	Ja
AquaStop-funktion:	Nee
Justerbar temperatur:	Ja
Strömförbrukning (i standby):	0.11 W
Strömförbrukning (när avstängd):	0.11 W
Minsta centrifugeringshastighet:	400 RPM
LED programförloppsindikator:	Ja
Öppen dörr:	Opening bovenkant
Nominell kapacitet:	6 kg
Universalbil:	Ja
AC-ingångsspänning:	220-230 V
AC-ingångsfrekvens:	50 Hz
Energieffektivitetsskala:	A tot G
Hjulhjul:	Ja
Wasprogramma's:	Hygiëne/anti-allergie
