Contact Details for Oricom Support

and Warranty claims in Australia

Oricom International Pty Ltd

Unit 1, 4 Sovereign Place

South Windsor, NSW 2756

Australia

Email: [email protected]

Phone: (02) 4574 8888 (Monday to

Friday 8am to 6pm AEST)

Web: www.oricom.com.au

Fax: (02) 4574 8898

Contact details for Oricom Support

and WarrantyClaims in New Zealand

Email: [email protected]

Phone: 0800 674 266

(Monday to Friday 10am to 8pm NZST)

ORICOM BRACKETMBL001/MBL002 User Guide

•A completed Return Authorisation form

•A copy of your Proof of Purchase (please keepyour original copy)

•The faulty product, including all accessories.

Send the approved returns to: Oricom

International Pty Ltd Locked Bag658

South Windsor NSW 2756 Australia

Please notethat this Express Warranty excludes expenses incurred by you in

returningany faulty product to us.You must arrange and pay any expenses

incurred (including postage, delivery, freight, transportation or insurance ofthe

product)o return the faulty product to us, however, wewill t arrange delivery of the

repaired or replaced faulty product to you.

Important Information

Repair Notice

Please be aware that the repair of your goods may result in the loss of any user-

generated data (such as storedtelephone numbers, textand contact messages

information). Please ensuredata saved on that you have madea copy of any

your goods before sending for repair.

Please alsobe aware that goods presented for repair may be replaced by

refurbished goods or parts of the same type rather than being repaired.

MBL001 / MBL002

FITTING INSTRUCTIONS (For use with Oricom range of detachable antenna whips)

Choose a location:

1) Select an open position which will work to reduce the signal shadowing, and in turn,mounting ,

improvetransmission range. The antenna should be mounted as far as possible from any

metalstructure, including .vertical metal strips, cables, rods or railing

2) When selecting a position, ensure that the cable routing and distance to radio are considered.

It should also be considered that antenna whip will flex during motion, which will add stresstos

the bracket mounting point. A flat surface will aid in reducing any stress on the mounting

bracket.

3) Ensure that the selected location is free of electrical wiring, or otherhazard, before safely

commencing the install (as per below instruction)ation.

4) An important consideration is the ability to fold down antenna bracket and whip, when not in

use. Select a location where the desired fold down of antenna whip is suitable.

USER GUIDE ORICOM ANTENNA BRACKET - VHF MBL001/MBL002

Installation:

1)Each marine bracket is supplied with a drilling template, located on the reverse side of the

bracket packaging card. Locate the template, and in the desired location, use this template as

your guide, drilling from the outside. Ensure that the antenna fold down position is considered

before drilling a hole.

2)

3)

Each of the four securing holes can be drilled using a suitable 7mm drill bit.

If the desire is to have the coaxial cable passing through the base of the bracket, blind holes

have been allocated for reference on the drilling template. It is recommended that a mm9.5

drill bit is used to remove the blind hole. The blind hole will also need to be removed from the

antenna base, so using the mm drill bit, locate the matching hole, and remove.9.5

4)Once holes are removed, antenna coaxial cable can be fed through the drilled hole on the

base of the bracket, and through the hole drilled into the suitable boat location. Each bracket

includes a split rubber grommet, which is designed to be wrapped around cable on underside

of the base of the bracket, and securely pushed into place in drilled hole. This is to ensurethat

when the base is screwed into place, there is a seal of the gap between the cable andthe

base.

5)Each of the four affixing screws can now be tightened, but be careful not to over tighten which

could damage the base or vessel. It is recommended that after 1 month of use, that the

retention screws are tightened once more.

6)waterproof A neutral cure silicon sealant can be used around the base of the bracket, to

ensure that thebracket is affixed and secure.

7)toThe antenna coaxial cable can now be installed the radio.

Note:EachOricommarinewhipisfactorypre-tunedandmustnotbealteredinanyway. Itisnot

recommended tocutoralterthesuppliedcoaxial cable inanyway.
