Sida 1/2
ORICOM CUSTOMER SUPPORT
Oricom have a trained and dedicated team of Customer Support
Representatives, each with the knowledge and resources to assist in
answering your questions quickly and efficiently.
Oricom Support - Australia
For all product enquiries, troubleshooting or to discuss the range of Oricom
products, feel free to contact Oricom or visit our website for answers to
frequently asked questions.
02 4574 8888
Monday - Friday 8am – 6pm AEST
Email: support@oricom.com.au
www.oricom.com.au
Oricom Support - New Zealand
0800 674 266
Monday - Friday 10am - 8pm NZST
Email: support@oricom.co.nz
MARINE RADIO CUTTING TEMPLATES
Scan the QR code below for the cutting template designed to suit each of
the Oricom MX1000 and MX1100G VHF marine radios.
USER GUIDE - ORICOM MFMB01 BRACKET
Installation of Flush Mount Bracket
1)
Cut a hole into the location of where the radio is to be flush mount installed,
using the template downloadable on the supplied QR codes.
2)
Slide the transceiver through the cutout, as the drawing shows below.
3)
On the rear side with access to the back of the transceiver, affix the MFMB01
brackets to the left and right side of the transceiver with the supplied Philips
head screws, in the direction the image below shows.
4)
Once secured to the transceiver, tighten the cap screws until firmly flush
mounted. Securely tighten with Hex key (not supplied).
5)
Tighten locking nut to secure.
Images are for illustration purposes only.
MX1000 MX1100G
Note: Cap
screw should
be at the rear
of the radio.
