and value in everything we make. To ensure you get the most out of your new patio speakers, please take a moment to read this manual before you get started.

Installing Speakers

These weather resistant patio speakers are manufactured to resist

a variety of weather condition. The most ideal place to install these

speakers is the undersides of most eaves and overhangs as they

provide the best protection.

Like all speakers, they sound the best when placed no more than

seven feet apart from each other, and slightly higher than ear level.

If the speakers are more than seven feet apart, toe them in toward

the center of the listening area.

These speakers are not waterproof and cannot be submerged under

water.

Placing Speakers

If your application requires the speaker to be mounted, please

follow these directions. Mount the

plastic knobs supplied. Never mount a speaker on a wall made

of unreinforced drywall or plasterboard. If you are unsure,

consult a professional contractor. (See Diagram 1)

Painting the grilles

The metal grilles may also be painted. Use very thin paint (5:1). It will

plugging up the holes with excess paint.

Mounting

To install the bracket on the speaker. Screw the bracket knobs into the

cabinet. Point the speaker toward the listening area. Once the direction

of the speaker has been determined tighten the bracket knobs securely.

(See Diagram 2)

Diagram 1

Screw

Bracket

Diagram 2

First remove the grille from the speaker then using spray paint lightly go

over the front of the grille and then go over the back of the grille.

Two coats may be nessesary for desired look.

Knob

Patio Speaker Installation Manual

Produktspecifikationer

Varumärke:	OSD Audio
Kategori:	högtalare
Modell:	AP640
Vikt:	- g
Bredd:	217.48 mm
Djup:	188.91 mm
Höjd:	292.1 mm
Rekommenderad användning:	Universal
Impedans:	8 Ω
Lämplig för utomhusbruk:	Ja
Ljudutgångskanaler:	1.0 kanaler
Högtalarplacering:	Floor, Tabletop/bookshelf, Wall-mountable
Antal förare:	1
Bashögtalare:	Ja
Känslighet:	89 dB
Förstärkare:	Inbyggd
Förstärkarklass:	A/B
Produktens färg:	Vit
Uteffekt (RMS):	150 W
diskanthögtalare:	Ja
Equalizer:	Nej
Frekvensområde:	39 - 20000 hz
Anslutningsteknologi:	Kabel
Woofer diameter:	165.1 mm
Woofer diameter (imperial):	6.5 "
Högtalartyp:	5-vägs
Antal woofer-drivenheter:	1
Disktanthögtalare diameter:	1 "
Antal tweeter förare:	1
