INSTALLATION INSTRUCTIONSPR143N-AST
© Panduit Corp.2014
www.panduit.com
For instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
E-mail:
Phone:
866-405-6654
Rev. 03Page 1 of 1
INSTALLATION INSTRUCTIONSPR143N-AST
© Panduit Corp.2014
www.panduit.com
For instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
E-mail:
Phone:
866-405-6654
Rev. 03Page 1 of 1
1.Snap groove portion of tie onto
support strand.
2.Position cable against tie spacer
and thread tail through slot in
head. Push upwards on body of
tie until snug.
3.Use pliers utilizing tension steps
on tie to tighten completely.
4.Support tie shown when properly
installed. If releasability is not
required, tip can be cut off.
TORELEASE:
Use screwdriver to push locking tab
towards support strand.
Tab
1.Snap groove portion of tie onto
support strand.
2.Position cable against tie spacer
and thread tail through slot in
head. Push upwards on body of
tie until snug.
3.Use pliers utilizing tension steps
on tie to tighten completely.
4.Support tie shown when properly
installed. If releasability is not
required, tip can be cut off.
TORELEASE:
Use screwdriver to push locking tab
towards support strand.
Tab
Aerial Support Ties
Part Numbers: AST10-5-C100, AST15-5-C100,
AST20-5-C100, AST25-5-C100
Aerial Support Ties
Part Numbers: AST10-5-C100, AST15-5-C100,
AST20-5-C100, AST25-5-C100
Produktspecifikationer
| Varumärke: | Panduit |
| Kategori: | ej kategoriserat |
| Modell: | AST20-5-C100 |
| Material: | Polypropylen (PP) |
| Modell: | Buntband med pärlor |
| Produktens färg: | Svart |
| Antal per förpackning: | 100 styck |
| Identifieringstagg: | Ja |
