PES400

PA28981A01

Rev. 02 4-2020

PORTABLE EMBOSSING SYSTEM

OPERATION MANUAL

Email:

ga-techsupport@panduit.com

EU Website:

www.panduit.com/emea

EU Email:

emeatoolservicecenter

@panduit.com

www.panduit.com

US & Canada Technical Support:

Tel: 1-866-871-4571

Panduit Europe

EMEA Service Center

Almelo, Netherlands

Tel: +31-546-580-452

Fax: +31-546-580-441

© Panduit Corp. 2018
OPERATION MANUAL
PES400
ENGLISH

PES400:  PA28981A01_01        Page: 1 of 51          4-2018
Table of contents

SETUP and INSTALLATION GUIDE ........................................................... 3
1  Unpacking ............................................................................................................. 3
2  Checking the Accessories ................................................................................... 3
3  Connecting Communication Cables .................................................................... 5
4  Install Software for the USB to Serial Adapter .................................................... 6
4.1  System Requirements ............................................................................... 6
4.2  Install Software for the USB to Serial Adapter (XP, Vista, 2000) ............ 7
4.3  Windows 7, 8 and 10 .................................................................................. 7
5  Install External Hopper ......................................................................................... 7
6  Easy-Mark Plus™ Software Installation .............................................................. 7
INTRODUCTION .......................................................................................... 9
SYSTEM SPECIFICATIONS ...................................................................... 15
1  Electrical Specification ....................................................................................... 15
1.1   Equipment Classification and Standard Reference ............................. 15
1.2   Working Condition .................................................................................. 15
1.3   Dimensions and Weight ......................................................................... 15
1.4   Production Capacity ............................................................................... 16
2  Safety Regulations and Operating Precautions ............................................... 17
 MACHINE SETUP FOR PRODUCING PLATES ....................................... 19
1  Quick Start Steps for Changing Plate Sizes and Embossing .......................... 19
2  Detailed Setup Instructions ................................................................................ 21
2.1  Remove Top Weights ............................................................................... 21
2.2  Remove Plates ......................................................................................... 21
2.3  Move RH Side Wall ................................................................................... 21
2.4  Plate Support Block Changeover ........................................................... 22
2.5.  Gate Height Adjustment ......................................................................... 26
2.6.  Guide Rail Adjustment ............................................................................ 30
2.9  Loading Marker Plates ............................................................................. 32
2.10  Side Eject Guide Plate Adjustment: ..................................................... 32
2.11  External Hopper Adjustment ................................................................. 33
2.11a  Gripper Assembly Jaw Pressure Adjustment ................................... 35
2.12  Turn on PES400 ..................................................................................... 36
2.13  Open and use Panduit Easy-Mark Plus™ software............................. 36
2.14  Embossing Plates .................................................................................. 39
2.15  Changing Plate Formats ........................................................................ 40
3  Embossing Force Adjustment ........................................................................... 40
 Error Codes .............................................................................................. 43
1  PES400 Display ................................................................................................... 43
2  Easy-Mark Plus™ Errors .................................................................................... 46
 TROUBLE SHOOTING .............................................................................. 47
 GENERAL MAINTENANCE ...................................................................... 48
 CLEANING AND MAINTENANCE SCHEDULE FOR PES400 .................. 49
