INSTALLATIONINSTRUCTIONS

©PanduitCorp.2020

E-mail:

[email protected]

Phone:

866-405-6654

ForInstructionsinLocalLanguages

andTechnicalSupport:

www.panduit.com/resources/install_maintain.asp

Page1of1

www.panduit.com

V00029SW

PR2HF2(WH)

PR2HF3(WH)

Installthemanagerstotherackwith#12-24x1”screwsprovided.Installthecoverto

themanagerbypositioningthemagneticlatchesnearthehingepinsofthemanager.

Note:Therecommendedassemblytorqueshallbe9.0+/-1in-lb.for#12-24screws.

Toopenthecoverdownwards,pullout

anddownonthemiddleofthecover

top.Toopencoverupwards,pullout

anduponthemiddleofthecoverbot-

tom.Toremovethecovercompletely,

pullstraightoutonbothendsofthe

coversimultaneously.

Screws

Cover

19”Rack

PR2HF2(Shown)

ThecablemanagerisrecommendedforusewithPanduit24or48porthighdensitypatchpanelsand/orswitchesmountedP2ATCHRUNNER

aboveandbelowthemanager.

Whenroutingthecablesfromapatchpanelorswitch,eitherofthefollowingtwomethodsarerecommendedtohelpmaintainthecable

bendradius.

METHOD1:Foreachrowof24ports,placecablesingroupsoffourbetweenthefingers.Routehalfthecablesthrougheachendofthe

manager.

METHOD2:Foreachrowof24ports,placecablesingroupsoffourbetweenthefingers.Routeallthecablesthroughoneendofthe

manager.

Method1

Method2

PartNumbers:PR2HF2,PR2HF2WH,PR2HF3,PR2HF3WH,PR2HF4,PR2HF4WH

P2ATCHRUNNERHorizontalCableManagers

PR2HF4(WH)

Closeupof

MagneticLatch

andHingePin

(4)Places

HingePin

Magnetic

Latch

MagneticLatch

(4)Places

SeeImage

Below
