Flat Panel Display Stand

For up to 70" Displays

FPZ-600 Flat Panel Display stands provide a safe and secure solution for displaying digital

content in public areas like conference rooms, lobbies or convention centers. The versatility

and functionality of this solidly engineered stand enables single display, two displays

back-to-back, two displays in portrait orientation or even four displays in either landscape

or portrait orientations (may require additional accessory). Integrated security fasteners lock

the displays in place, virtually eliminating theft, while internal cable management completely

hides all wires and cables enabling a clean, professional look.

Display size: up to 70" Max load: 200lb (90.7kg)

per display up to 4 displays

FPZ-600

 Fits single or back-to-back

mounted displays up to 70"

(up to four with additional

dual-display cartridge)

 VESA

100, 200 x 100,

200 x 200mm compatible.

Additional display

mounting patterns

supported by optional

PLP display adaptor plate

(sold separately)

 Continuous vertical

adjustment on 6' (1.83m)

columns for perfect

viewing height

 Hook-on design for quick

and simple installation

 Easy to switch from portrait

to landscape orientation

 Integrated cable

management protects,

contains and conceals

cables for a clean,

professional installation

 Includes theft resistant

hardware for attaching

display to mount

FeatureS

Single or back-to-back

Multiple congurations for

at panel displays up to 70"

HeigHt adjuStment

Ideal display position

along the 6’ (1.83m)

columns

Back-to-back

Landscape

Single display

Portrait

Dual Display

Portrait

(requires ACC604 adaptor)

integrated cable management

Integrated cable management protects,

contains and conceals cables for a clean,

professional installation

Heavy duty Steel baSe

Provides exceptional stability

and safety

click: peerless-av.com call: 800.865.2112 FaX: 800.359.6500

A R C H I T E C T S S P E C I F I C A T I O N S

The Flat Panel Display Stand shall be a Peerless-AV model FPZ-600 and shall be installed where indicated on the plans.

It shall be constructed of heavy gauge cold rolled steel. Assembly and installation shall be done according to instructions provided by the manufacturer.

LIT-1115

PACKAGE SIZE (W x H x D) PACKAGE SHIP WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE

FPZ-600

Box 1:

37.25" x 30.50" x 9.38"

(946 x 775 x 238mm)

Box 2 and 3:

72.00" x 4.00" x 8.00"

(1830 x 102 x 203mm)

Box 1:

82.9lb (37.6kg)

Box 2 and 3:

17.6lb (7.9kg)

735029242604

Floor base, 2 columns,

dual-display cartridge,

2 VESA

display

adaptor brackets &

mounting hardware

Package Speciﬁcations

DImENSIONS (W x H x D) PRODUCT WEIGHT LOAD CAPACITy FINISH AVAILABLE COLORS

FPZ-600

28.91” x 72.33” x 36.00”

(734 x 1837 x 914mm)

108.2lb (49kg)

200lb (90.7kg)

per display up

to 4 displays

Powder Coat Black

Product Speciﬁcations

Model Numbers

WARRANTY: Limited 5-year

All dimensions = inch (mm)

FPZ-600 Flat Panel Display Stand for up to 70" Displays

Accessories

Visit www.peerless-av.com to see the complete line of AV solutions from Peerless-AV, including at panel mounts, projector mounts, carts/stands, furniture, cables, screen cleaners and a full assortment of accessories.

Peerless Industries, Inc.  2300 White Oak Circle  Aurora, IL 60502  (800) 865-2112  (630) 375-5100  Fax: (800) 359-6500  peerless-av.com

PLP-UNL: Universal Adaptor Plate

ACC604: Dual-Display Cartridge

ACC325: Accessory Shelf

ACC340: Media Player Shelf

Produktspecifikationer

Varumärke:	Peerless-AV
Kategori:	ej kategoriserat
Modell:	FPZ-600
Vikt:	49000 g
Bredd:	734 mm
Djup:	914 mm
Höjd:	1837 mm
Certifiering:	RoHS
Modell:	Bärbart golvstativ
Rekommenderad användning:	Plattskärm
Förbättrad kabelhantering:	Ja
Maximal skärmstorlek:	75 "
Maxvikt:	90.7 kg
Produktens färg:	Svart
Monteringssats:	Ja
Vikt inkl. förpackning:	54000 g
Orientering:	Liggande / Stående
Monteringssätt:	Golv
Harmonized System (HS)-kod:	94031098
Gränsssnitt för panelmontering:	100 x 100,200 x 100,200 x 200 mm
Höjdjustering:	Ja
Antal displayer som stöds:	2
Monteringsgränssnitt kompatibilitet (min):	100 x 100 mm
Monteringsgränssnitt kompatibilitet (max):	200 x 200 mm
Stöldskydd funktion:	Ja
Paket 2, vikt:	8600 g
Paket 2, mått (B x D x H):	1854 x 105 x 105 mm
Paket 1, mått (BxDxH):	940 x 241 x 768 mm
Paket 1, vikt:	39500 g
