PACKAGENTNT COESF lattrs ck www.Phante.mores veionhecksco
INSTALLATION GUIDE V1.0
gigabyteaorusRtX 3090/3080
GLACIER BACKPLATE
PH-GB3090GBARSBP_BK01/CR01
WARNING - This product is intended for advanced users. Improper installation may result in damage to your equipment. While all eorts
have been made to provide the most comprehensive information possible, Phanteks assumes no liability expressed or implied for any damage(s)
occurring to your components as a result of using Phanteks cooling products, either due to mistake or omission on our part in the below
instructions, or due to failure or defect in the Phanteks cooling products. Do not disassemble the water block. Warranty will be voided.
Turn o the power to your system and discharge your body’s static electric charge before proceeding with the installation procedure. If you do not
feel comfortable with performing the installation procedure, consult a qualied computer technician.
GLACIER BACKPLATE
QTY: 1
This product requires the PH-GB3090GBARS GPU water block. Please follow step 1 to 3 of the GPU
water block’s installation guide before proceeding.
M2.5x8 Flush Screws
QTY: 9
Thermal Pads
QTY: 2
FINISH STEPS 1 TO 3 FROM THE WATER BLOCK INSTALLATION GUIDE BEFORE PROCEEDING:
STEP 4. APPLYING THERMAL PADS
Remove the protective lm and place the
thermal pads on the correct position on
the backplate.
Make sure to remove the protective lm on
both sides of the thermal pads.
1
2
2
3
4
5
1
2
2
3
4
5
1
22
3
45
