DSP8.8 Manual

Digital Signal Processor

FEATURES

● 8-channel high level inputs with signal sense turn on and load resistors

● 6-channel low level inputs

● Aux input (3.5mm, high level for external NAVI/hands-free)

● USB input for uncompressed hi-res audio from iOS/Android smart devices/thumb drives up to 24bit/192kHz

● Wi-Fi input for wireless connectivity and uncompressed hi-res audio streaming up to 24bit/192kHz

● Toslink optical hi-res audio input up to 24bit/192kHz

● 8-channel 5 volt low level outputs

● Real time DSP tuning via DSP8.8 congurator app for iOS, Android, Mac and Windows PC

● 240 bands of 1/3 octave parametric EQ adjustment (30 bands per channel)

● DRC Included (Dash Mount Remote Control): multi-function remote for source select, volume, sub level, 6

selectable presets, and custom illumination

● DSP8.8 RC remote control app for iOS and Android phones/tablets for source select, volume, sub level, and

6 selectable presets

● Dimensions (WxHxD): 7.5” x 2” x 7.75” 190.5 x 51 x 197mm

1. Product Overview

2. General Safety Instructions

3. Box Contents

4. DSP Features

5. Technical Specications

6. Technical Data

7. Device Connections

8. Connecting Wi-Fi module/PC/iOS and Android Devices

9. Connecting Analog Sources

10. Connecting Digital Sources

11. Installing Software and Apps

12. Windows Installation for XP, 7, 8, 10

13. Mac App Installation

14. Establishing a Connection

15. Conguration Screen

16. Using the Conguration Screen

17. DRC Functions

718. DSP RC App

19. Troubleshooting

Table of Contents DSP8.8

DSP Features DSP8.8

Wi-Fi Functionality

2.4 GHz Wi-Fi Module built into the DRC

Real time DSP conguration over Wi-Fi with smart device app for iOS and Android

Real time DSP conguration over Wi-Fi with Mac OS software

Real time DSP conguration over Wi-Fi with Windows PC software

Audio streaming from Mac OS using Airplay

Audio streaming from iOS using Airplay*

Audio streaming from Android devices using casting apps that UPnP/DLNA formats*

*Hi-Resolution audio streaming apps required for 24-bit/92-196kHz audio les

Micro-USB

Real time DSP conguration through Windows PC software

Uncompressed hi-res audio streaming from Windows PC

Uncompressed hi-res audio streaming from iOS device with iOS Camera Connection Kit

Uncompressed hi-res audio streaming from Android device with OTG adapter

APP/Software Features

30 band parametric equalizer per channel

Selectable crossovers: High/Low/Band-Pass slopes 0 – 30dB, Butterworth/Bessel/Linkwitz Riley

Time delay: automatic or manual setup 0 to 5 meters or 14.6ms adjustable in 0.01ms steps

Large setup overview page for fast check of current system settings

DSP conguration les can be saved, imported, exported, copied and reloaded

Autoremote for customizable thresholds and timing for system on and off

Input Vu Meters for RCA and high level sources

Software controllable analog attenuation on preamp and high level inputs

Customizable name/alias on each preset and output channel

DRC backlight color customization through app and conguration software

INPUTS

6 RCA preamp inputs

8 High level inputs w/ load resistors

1 Stereo aux input 3.5mm jack

1 Telephone/navigation input

1 Micro-USB input

1 SPDIF optical input

OUTPUTS

8 RCA preamp outputs

1 SPDIF optical output
