Sida 1/16

Features CaractéristiquesCaracterísticas:

• High and Low Pass Crossovers

• Audiophile BiPolar Output Transistors

• High Level Inputs for easy OEM Integration

• Robust Unregulated Power Supply

• Surface Mount Component Technology

• Direct Insert Power and Speaker Terminals

• Audio Precision Quality Control Verication

• High Temperature Plexiglass cover

• RBC- Remote subwoofer level control included

(RX250.1, RX500.1, RX1100.1, RX600.5)

• Filtres croisés passe-haut et passe-bas

• Audiophile Transistors de Bipolaire

• Le Niveau Supérieur entre pour l’intégration de

fabricant d’origine facile

• Alimentation électrique robuste non

réglementée

• Technologie de composant monté en surface

• Terminaux d’alimentation et de haut-parleurs à

insertion directe

• Vérication du contrôle de la qualité de la

précision audio

• Couvercle de plexiglas résistant aux

températures élevées

• RBC- Niveau de contrôle de passe-bas inclus

(RX250.1, RX500.1, RX1100.1, RX600.5)

• High and Low Pass Crossovers

• Transistores de salida BiPolar Audiophile

• Entradas de alto nivel para fácil integración

OEM

• Robusta y no regulada Fuente de Poder

• Tecnología “Surface Mount Component”

• Conexiones directas de terminales de poder y

de parlantes

• Control de vericación de calidad de precisión

de audio

• Cubierta de Plexiglás resistente a altas

temperaturas

• RBC -Control de nivel de Subwoofer remoto

incluido (RX250.1, RX500.1, RX1100.1, RX600.5)

Models: RX250.1, RX500.1, RX1100.1, RX400.4, RX600.5

Amplifier

Manual

Manual del Amplificador

Manuel de l’amplificateur

Amplifier Owner’s Manual

RX250.1 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >100dB

Low Pass Crossover: 12dB per Octave

Subsonic Filter: 12dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 2 ohms

Typical Efciency: 50%

Damping Factor: Greater than 200

Variable Phase Adjustment: 0 to 180 Degrees

RX500.1 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >100dB

Low Pass Crossover: 12dB per Octave

Subsonic Filter: 12dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 2 ohms

Typical Efciency: 50%

Damping Factor: Greater than 200

Variable Phase Adjustment: 0 to 180 Degrees

RX1100.1 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >90dB

Low Pass Crossover: 12dB per Octave

Subsonic Filter: 12dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 1 ohm

Typical Efciency: 80%

Damping Factor: Greater than 200

Variable Phase Adjustment: 0 to 180 Degrees

IMPORTANT: A power birth certicate is included for each amplier. RX ampliers are

conservatively rated and will exceed their RMS power rating shown here. All RMS power

ratings and measurements are at 14.4 volts with no more than 1% THD.

RMS Power Output 150w x 1 @ 4 ohms

250w x 1 @ 2 ohms

Power/Ground Wire Size: 8 Gauge

Recommend Power Wire Fuse: 20a

Dimensions (Includes Feet): 9.4” L x 8.4” W x 2.1” H

238mm L x 213mm W x 53mm H

RMS Power Output 300w x 1 @ 4 ohms

500w x 1 @ 2 ohms

Power/Ground Wire Size: 4 Gauge

Recommend Power Wire Fuse: 40a

Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H

368mm L x 213mm W x 53mm H

RMS Power Output 800w x 1 @ 2 ohms

1100w x 1 @ 1 ohm

Power/Ground Wire Size: 4 Gauge

Recommend Power Wire Fuse: 80a

Dimensions (Includes Feet): 11.75” L x 8.4” W x 2.1” H

298mm L x 213mm W x 53mm H

SPECIFICATIONS

Amplifier Owner’s Manual

RX400.4 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 20kHz

Signal to Noise Ratio: >100dB

High and Low Pass Crossovers: 12dB per Octave

Crossover Range: 40Hz to 400Hz

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 4 ohms Bridged/2 ohms Stereo

Typical Efciency: 50%

Damping Factor: Greater than 200

RX600.5 SPECIFICATIONS

FRONT AND REAR CHANNELS:

Frequency Response: ± 1dB from 20Hz to 20kHz

Signal to Noise Ratio: >100dB

High and Low Pass Crossovers: 12dB per Octave

Front/Rear High Pass Crossover Range: 15Hz to 250Hz

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 4 ohms Bridged/2 ohms Stereo

Typical Efciency: 55%

Damping Factor: Greater than 200

SUBWOOFER CHANNEL:

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >100dB

Low Pass Crossover: 12dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 2 ohms

Typical Efciency: 85%

Damping Factor: Greater than 200

RMS Power Output 75w x 4 @ 4 ohms Stereo

100w x 4 @ 2 ohms Stereo

200w x 2 @ 4 ohms Bridged

Power/Ground Wire Size: 8 Gauge

Recommend Power Wire Fuse: 30a

Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H

368mm L x 213mm W x 53mm H

RMS Power Output 60w x 4 @ 4 ohms Stereo

80w x 4 @ 2 ohms Stereo

160w x 2 @ 4 ohms Bridged

RMS Power Output 200w x 1 @ 4 ohms

300w x 1 @ 2 ohms

Recommend Power Wire Fuse: 60a

Power/Ground Wire Size: 4 Gauge

Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H

368mm L x 213mm W x 53mm H

SPECIFICATIONS
