© 2017 Phoenix Gold • www.phoenixgold.com
Features CaractéristiquesCaracterísticas:
• High and Low Pass Crossovers
• Audiophile BiPolar Output Transistors
• High Level Inputs for easy OEM Integration
• Robust Unregulated Power Supply
• Surface Mount Component Technology
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verication
• High Temperature Plexiglass cover
• RBC- Remote subwoofer level control included
(RX250.1, RX500.1, RX1100.1, RX600.5)
• Filtres croisés passe-haut et passe-bas
• Audiophile Transistors de Bipolaire
• Le Niveau Supérieur entre pour l’intégration de
fabricant d’origine facile
• Alimentation électrique robuste non
réglementée
• Technologie de composant monté en surface
• Terminaux d’alimentation et de haut-parleurs à
insertion directe
• Vérication du contrôle de la qualité de la
précision audio
• Couvercle de plexiglas résistant aux
températures élevées
• RBC- Niveau de contrôle de passe-bas inclus
(RX250.1, RX500.1, RX1100.1, RX600.5)
• High and Low Pass Crossovers
• Transistores de salida BiPolar Audiophile
• Entradas de alto nivel para fácil integración
OEM
• Robusta y no regulada Fuente de Poder
• Tecnología “Surface Mount Component”
• Conexiones directas de terminales de poder y
de parlantes
• Control de vericación de calidad de precisión
de audio
• Cubierta de Plexiglás resistente a altas
temperaturas
• RBC -Control de nivel de Subwoofer remoto
incluido (RX250.1, RX500.1, RX1100.1, RX600.5)
Models: RX250.1, RX500.1, RX1100.1, RX400.4, RX600.5
Amplifier
Manual
Manual del Amplificador
Manuel de l’amplificateur
Amplifier Owner’s Manual
© 2017 Phoenix Gold • www.phoenixgold.com
RX250.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 50%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RX500.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >100dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Efciency: 50%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RX1100.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Efciency: 80%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
IMPORTANT: A power birth certicate is included for each amplier. RX ampliers are
conservatively rated and will exceed their RMS power rating shown here. All RMS power
ratings and measurements are at 14.4 volts with no more than 1% THD.
RMS Power Output 150w x 1 @ 4 ohms
250w x 1 @ 2 ohms
Power/Ground Wire Size: 8 Gauge
Recommend Power Wire Fuse: 20a
Dimensions (Includes Feet): 9.4” L x 8.4” W x 2.1” H
238mm L x 213mm W x 53mm H
RMS Power Output 300w x 1 @ 4 ohms
500w x 1 @ 2 ohms
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 40a
Dimensions (Includes Feet): 14.5” L x 8.4” W x 2.1” H
368mm L x 213mm W x 53mm H
RMS Power Output 800w x 1 @ 2 ohms
1100w x 1 @ 1 ohm
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 80a
Dimensions (Includes Feet): 11.75” L x 8.4” W x 2.1” H
298mm L x 213mm W x 53mm H
SPECIFICATIONS
Produktspecifikationer
| Varumärke: | Phoenix Gold |
| Kategori: | mottagare |
| Modell: | RX600.5 |
