Amplifier Manual
Manuel de l’amplificateur
Features: Caractéristiques:
Model: SD1300.1, SD1300.5
© 2011 Phoenix Gold • www.phoenixgold.com
• High Eciency Class D Topology
• Compact Size for Easy Installation
• High and Low Pass Crossovers
• Robust Unregulated Power Supply
• Surface Mount Component Technology
• Panel Mounted RCAs
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verication
• High Temperature Plexiglass cover
• Remote subwoofer level control included
• Topologie de classe D de gamme complète
• Petit format pour faciliter l’installation
• Filtres croisés passe-haut et passe-bas
• Alimentation électrique robuste non réglementée
• Technologie de composant monté en surface
• Amplicateurs à couplage RC montés sur des panneaux
• Terminaux d’alimentation et de haut-parleurs à insertion directe
• Vérication du contrôle de la qualité de la précision audio
• Couvercle de plexiglas résistant aux températures élevées
• Niveau de contrôle de passe-bas inclus
Amplier Owner’s Manual
© 2011 Phoenix Gold • www.phoenixgold.com
Specifications
SD1300.5 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High Pass Crossovers: 12dB per Octave
Low Pass Crossover: 18dB per Octave
High Pass Crossover Range: 15Hz to 250Hz
Low Pass Crossover Range: 30Hz to 300Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Front and Rear Channels Lowest Load: 4 ohms Bridged or 2 ohms Stereo
Subwoofer Channel Lowest Load: 2 ohm
Typical Eciency: 70%
Damping Factor Greater than 200
Note: All SD ampliers operate correctly up to 14.4 volts. Do not
operate the amplier above 14.4 volts. The amplier will engage its
overvoltage protection, the result is no audio output on one or
more channels.
RMS Power 14.4Vdc ≤1% THD 80 x 4 @ 4 ohms Stereo
125 x 4 @ 2 ohms Stereo
250 x 2 @ 4 ohms Bridged
plus
500 x 1 @ 4 ohms
800 x 1 @ 2 ohms
Dynamic Power 14.4Vdc >1% THD 95 x 4 @ 4 ohms Stereo
150 x 4 @ 2 ohms Stereo
300 x 2 @ 4 ohms Bridged
plus
700 x 1 @ 4 ohms
1000 x 1 @ 2 ohms
Recommended Fuse Size: 100 amp
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Mounting Feet): 14.33” L x 6.93” W x 2.0” H
364mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 14.96” L x 6.93” W x 2.0” H
380mm L x 176mm W x 51mm H
SD1300.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 18dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Eciency: 70%
Damping Factor: Greater than 200
RMS Power 14.4Vdc ≤ 1% THD 900 x 1 @ 2 ohms
1300 x 1 @ 1 ohm
Dynamic Power 14.4Vdc >1% THD 1200 x 1 @ 2 ohms
1600 x 1 @ 1 ohm
Recommended Fuse Size: 120 amp
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Mounting Feet): 14.33” L x 6.93” W x 2.0” H
364mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 14.96” L x 6.93” W x 2.0” H
380mm L x 176mm W x 51mm H
