COMPONENT loudSpeaker Manual
Manual De Composantes
Features:
Model: RX65CS
• -Advancedlaminatingprocessproducesexcellentsti󰘯nesstoweightratio,superiordampingqualitiesLAMINATE-TREATED PAPER CONE
• -Excellentreproductionofhighfrequencies19mm BALANCED DRIVE MYLAR TWEETER
• -Hightemperaturelight-weightvoicecoilstructureforincreasedsensitivityPOLYMIDE VOICE COIL FORMER
• -PremiumdesignforlongtermreliabilityandsensitivityTRIPLE-LAYER UV TREATED FOAM SURROUND
• RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment
Component Speaker Owner’s Manual
© 2013 Phoenix Gold • www.phoenixgold.com
BASIC INSTALLATION
SelectingtheplacementofyournewRXComponentspeakerscouldbeaseasy
asusingtheexistingfactorylocationsormayrequireyoutocreateanewlocation.
Speakerplacementinthedoor,dash,orreardeckisthemostcommon.Seeyour
localPhoenixGoldDealerforadditionallocationandmountingassistance.
DOORS/REAR DECK
1.Manyvehiclesalreadyhavefactorylocations(Figure1)tohousethe“DROP
IN”featureoftheRXComponentspeakers.Ifnoexistinglocationsareavailable
orarenotused,checkthedesiredlocationforadequatecutoutareaandany
depthobstructions.Makesuretoallowsu󰘲cientclearanceforwindowtracks,
structuralbraces,trunklidsprings,etc.
2.Assumingenoughareaanddepthisavailable,usetheprovidedtemplateand
tracethespeakercutoutandmountingholesontothesurfaceofthemounting
location.
3.Ifthemountingsurfaceisnotstructurallystrongenoughtoaccommodate
screws,(i.e.plastic,cardboard)usetheprovidedspeedclipswhichwillactasa
nutforthesuppliedscrews.
4.Alwaysprovidewaterprotection,ifnotsuppliedinthevehicle.Wesuggest
usingarainshieldorequivalent.Ifindoubt,pleasecontactyour
PhoenixGoldDealer.
SPEAKER INSTALLATION WITHOUT GRILL
PhoenixGoldhasprovidedafoammountinggasket.Wheninstallingyournew
componentspeakersinafactorylocationmakesuretousethefoammounting
gasketasshownin󰘰gure1.Forreversemountedspeakersplacethefoam
gasketinfrontofthespeaker.ThiswillensureanairtightsealforyourRX
speakers.Formorecustomapplications,orcaseswherethefactorygrillwillnot
beused,ahighexcursionprotectivegrillhasbeenprovided.Wheninstalling
yournewcomponentspeakerswiththeprovidedRXgrilluse󰘰gure2.
TWEETER ADJUSTMENT
Thetweeterspivotintheirhousings.Whenmountedlowinthedoor,anglethe
tweeterupforbetterhighfrequencyperformance.Inreardeckordashboard
installations,anglethetweeterawayfromtherearglasstoreducedestructive
re󰘱ections.
CROSSOVER ADJUSTMENT
ThecrossoverprovidedwiththeRXSeriescomponentsetisoptimizedtogivethe
mostaccuratein-carresponse.Useonlythecross-overprovided;theuseofany
othercrossovermayresultindamagetooneormoreoftheRXSeries
components.Connecttheleftampli󰘰eroutputtothecrossoverfortheleft
componentset,andtherightampli󰘰eroutputtothecrossoverfortheright
componentset.Fromthereconnectyourcomponentwooferandtweeterstothe
correspondingcrossoverobservingpolarity(+to+,-to-).(󰘰gure3)
CROSSOVER INSTALLATION
Wesuggestyouselectamountinglocationforthecrossoverswithinthecab
ofthevehicle,suchasthekickpanelsorneartheampli󰘰er.Ifcrossoversmust
bemountedinthedoor,mountthembetweenthemoisturebarrierandthe
innermostdoorpanel.MOISTUREDAMAGEWILLVOIDYOURWARRANTY.
Figure 1
Mountingthespeakerinafactorylocation.
Figure 2
Mountingthespeakerinacustomapplication.
© 2013 Phoenix Gold • www.phoenixgold.com
Component Speaker Owner’s Manual
TWEETER INSTALLATION
FLUSH MOUNT
Withavarietyofsuppliedmountingoptions,theRXSeriesseriestweeteris
easytoinstallinanyvehicle.Eachcomponentsetcomeswitha󰘱ushmountand
surfacemountinstallationkit.Forothercustommountingcon󰘰gurations,please
contactyourauthorizedPhoenixGoldDealer.
FlushMount:Foroptimaltweeterinstallation,usetheFlushMountoption.The
Flushmountrequires3⁄4”depthanda1-13/16”holeinthemountingsurface.
(󰘰gure4)(󰘰gure5)
TheRXSeriestweeterspivotintheirhousings.Thisallowstheusertoalignthe
tweeterduringtheinstallationprocessforoptimumlisteningresults.
Forbestresults,alwaystrytomaintainequalpathlengthsbetweentheright
andthelefttweeterandthelisteningposition.Thisisusuallyaccomplishedby
mountingaslowanddeepaspossibleinakickpanelinstallation,orhighand
deepinadashboardinstallation.Becautiousindashboardinstallationsnotto
re󰘱ectthetweetero󰘯ofthewindshield:thisincreasesre󰘱ectionsandcangreatly
diminishtheoverallsystemlisteningquality.Fordoorpanelinstallations,tryto
anglethetweeterstowardthelistenertooptimizehighfrequencyperformance.
SURFACE MOUNT
SurfaceMountingOptions:Screwsareprovidedforusewhencuttingaholein
thedoorpanelorothermountingsurfaceisnotanoption.Makesurethatthe
surfacemountlocationisfreeofpassengermovementthatmightdamagethe
tweeter.(󰘰gure6)
