IGS-800T-PN/IGS-820TF-PN

Compact Industrial 8-port Gigabit PROFINET Switch

Compact and Rugged Design for Industrial Environments

PLANET IGS-800T-PN and IGS-820TF-PN are compact industrial PROFINET switches

designed to meet the demanding requirements of smart factories. The IGS-800T-PN

features 8 auto-negotiation 10/100/1000BASE-T RJ45 ports, while the IGS-820TF-PN

provides 6 RJ45 ports and 2 dual-speed 100/1000BASE-X SFP fiber interfaces for

extended deployment flexibility. Both models come in IP30-rated rugged metal cases

and operate reliably within a wide temperature range of -40 to 75°C.

Physical Port

• IGS-800T-PN: 8-port 10/100/1000BASE-T RJ45 with auto-

MDI/MDI-X.

• IGS-820TF-PN: 6-port 10/100/1000BASE-T RJ45 and 2

100/1000BASE-XSFPportsforexibleberuplinkoptions.

Layer 2 Features

• Complies with IEEE 802.3 10BASE-T, IEEE 802.3u

100BASE-TX, IEEE 802.3ab 1000BASE-T Ethernet

standard

• Supports auto-negotiation and 10/100Mbps half/full duplex

and 1000Mbps full duplex

• Preventspacketlosswithbackpressure(half-duplex)and

IEEE802.3xpauseframeowcontrol(fullduplex)

• High-performance Store and Forward architecture,

broadcaststormcontrolandrunt/CRClteringeliminate

erroneouspacketstooptimizethenetworkbandwidth

• Switching fabric: 16Gbps

• Integratedaddresslook-upengine,supporting4Kabsolute

MAC addresses

• Supportsjumboframesupto9Kbytes

• Automatic MAC address learning and aging

• Supports CSMA/CD Protocol

• Compliant with PROFINET Conformance Class A

• SupportsPROFINETPTCPlterforreliablecommunication

onPROFINETnetwork

• SupportsPROFINETTrafcPass-throughwithQoS

Industrial Case and Installation

• IP30-rated compact metal enclosure

• Supports both DIN-rail and wall-mount installation

• 9~48V DC redundant power input with reverse polarity

protection;includesremovableterminalblockformaster

and slave power connections

• Supports 24V AC power input

• Supports 6000 VDC Ethernet ESD protection.

• Operating temperature range: -40 to 75°C

• Designedtowithstandfreefall,shock,andvibrationin

industrial environments

IGS-800T-PN IGS-801T

Compact Industrial 8-Port Switch

115mm

135mm

Plug-and-Play Deployment for IIoT and AIoT Systems

As the trend for an IIoT (Industrial Internet of Things) infrastructure continues to

grow,theIGS-800T-PNandIGS-820TF-PNsimplifyindustrialnetworkdeploymentwith

plug-and-play functionality. These switches enable seamless integration of intelligent

systems,allowingvaluabledatacollection,real-timedecision-making,andoperational

efciencyimprovementsacrossavarietyofautomationapplications.

IGS-800T-PN/IGS-820TF-PN

PROFINET Trafc Prioritization for Real-Time Control

Both switches support PROFINET Conformance Class A (CC-A)todeliverreal-timeandreliableEthernetcommunicationinautomationnetworks.They

feature advanced functions that detect and prioritize PROFINET traffic, forwarding time-sensitive control packets ahead of other data. This ensures

fast,synchronizedcommunicationbetweenPLCs,HMIs,sensors,andactuatorsmakingtheswitchesidealforuseinfactoryautomationandcontrol

environments.

Flexible Network Expansion with Energy Efciency

WhiletheIGS-800T-PNfocusesonhigh-speedcopperconnectivity,theIGS-820TF-PNoffersdualSFPportsforflexiblefiberuplinks,supportingboth

100BASE-FXand1000BASE-Xtransceivers.Theseswitchesarealsobuiltwithadvancedgreennetworkingtechnology,includingIEEE 802.3az Energy

Efcient Ethernet and auto power-saving functions, allowing dynamic adjustment of power consumptionbasedoncablelengthandnetworkactivity.

Other Ethernet Traffic

PROFINET Traffic

PLANET PROFINET CC-A Protocol Conformance Industrial Switch

(Higher Delivery Priority)

Data In

Data Out

Industrial Switch

PROFINET Traffic

Other Ethernet Traffic

IGS-820TF-PN

Energy Eciency

Optimized

Fiber-Optic Link Capability Enables Seamless Extension

The IGS-820TF-PN is equipped with two dual-speed 100/1000BASE-X SFP interfaces, enabling long-distance fiber-optic uplinks that can extend

networkdeploymentup to 120kmdepending onthebermodule.Thisallowsseamless integrationwithremoteautomationsystemsanddistributedcontrol

sites,makingitidealforuseintransportationinfrastructure,energyplants,andsmartcityenvironments.

Industrial

SFP Switch

MGB-TL120

Fiber Optic Cabling Enables Cascade Application

Switch Mode

IGS-820TF-PN

Switch Mode

IGS-820TF-PN

1000BASE-X Fiber

1000

1000BASE-X Fiber
