Package Contents
SD- Side Attachment 676
User Manual
2 iButton Keys
(if the iButton reader is built in)
Features
2- -1 (MSR + iButton Reader) /17 in side attachment for Posiflex 15” ” KS
series terminals
Bi-directional swipe
3-track support
Supporting ISO 7811 magnetic card
Interface: USB
Views of the Side Attachment
Front View Rear View
SD- 676
Side Attachment
User Manual
19850905010 Ver. A0
http://www.posiex.com
3-track Magnetic Stripe Reader
iButton Reader
Mounting Screw Holes
2
Hardware Installation
During Installation of the SD- , do NOT power ON your terminal and 676
monitor.
Installation of SD-676 onto the 15 /17” ” Series TerminalsKS
Start to install - onto the terminal according to the following steps. SD 676
1. Loosen and remove the two xing screws
from the side mount cover on the back of
the right side of the terminal.
2. Remove the side mount cover from the back
of the right side of the terminal.
3. Insert the USB I/O cable connected from
the main board of the terminal into the cable
connector of the side attachment.
4. Determine that the USB I/O cable is
securely connected to the cable connector of
the side attachment.
Cover
3
5. Manage the USB I/O cable well, as shown
in the right gure.
6. Align the two mounting screw holes of the
SD- side attachment with the two screw 676
holes on the terminal.
7. 676 Fix the -SD side attachment onto the
terminal by locking the two screws shipped
with the package.
8. 676 The installation of -SD side attachment
onto the terminal is completed, as shown in
the right gure.
