Installaon and Reference Guide
2020 Voxx Electronics Corporaon. All rights reserved. APSSEC_RevC_07/20
2 Wire Harness Colors and Funcons
2 Power / Nocaon Connector
3 Input / Output Connector
6 External Components
6 Shock Sensor
6 RF Antenna Kit
6 Data Bus Interface (DBI)
6 Telemacs
7 Setup Opons
7 Remote Programming
8 Security Control
12 Negave Output Control (NOC)
14 AUX Output Control
15 PIC Input Control
16 System Operaon
16 Remote Operaon
APSSEC
Vehicle Security / Keyless Entry System
17 System Programming
17 Programming Mode Entry / Exit
18 Feature Bank Opons
18 Data Port Protocol Selecon
19 Dome Light
19 Silent Arm and Disarm
19 User Selectable LED
19 System Diagnoscs
19 Troubleshoong Trigger Zones
19 Adjusng Shock Sensor
20 Alarm Override Procedures
21 Wiring Diagrams
21 Door Lock Connecons
24 Starter Kill Relay
25 Full System Connecons
Thank you for trusng Presge products! If you are a consumer, please note:
Professional installaon is strongly recommended.
This manual assumes the installer has adequate knowledge of the following experse. Therefore, it does not
cover these topics in detail:
12-volt electronics
Tesng and verifying circuits
Making safe and lasng wiring connecons
Factory ignion, power, lighng, data bus and sensing systems
Factory systems and components to avoid
Safe wire roung, circuit protecon and product placement
Access to vehicle-specic technical informaon
In addion, this manual assumes the installer has the proper tools, skill and facilies to perform a professional installaon.
Performing an improper installaon could result in damage to the vehicle or its components, improper system funcon,
unsafe vehicle operaon or physical injury. Such instances would not be covered by the vehicle manufacturer's warranty,
nor by Voxx Electronics, Inc.
Detailed Descripons Quick Reference
APSSEC_RevC_07/20
2
Detailed Descripons: Wire Harness Colors and Funcons
4. YELLOW – Ignion Input (+)
The YELLOW wire connects to the vehicle's primary ignion wire. This wire will be used for system programming and
override.
Vericaon: This ignion wire registers 12-Volt (+) when the key is in the accessory, ignion, and start posions.
Note: Before making this connecon, remove all module fuses unl the system is completely connected.
6. RED – 12-Volt Input (+)
The RED wire connects to the vehicle’s primary 12-Volt (+) wire to power the system.
Vericaon: The power wire registers 12-Volt (+) at all mes.
Note: Before making this connecon, remove all module fuses unl the system is completely connected.
1 3 5
2 4 6
Power / Nocaon Connector (6-pin connector) See page 25 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
3. WHITE/RED – Parking Light Relay Input (Internal Relay Pin 87)
The WHITE/RED connects to vehicle 12-Volt (+) or Ground (-) to supply the relay output (WHITE wire).
Vericaon for default seng:
If the vehicle parking light wire registers 12-Volt (+) when the park lights are on, connect the WHITE/RED wire to a
constant 12-Volt (+) vehicle wire.
If the vehicle parking light wire registers Ground (-) when the park lights are on, connect the WHITE/RED wire to a
reliable vehicle ground source.
Note: This wire can be programmed to perform the Trunk Release Output funcon by changing its opons. Refer to
Bank 2, Feature 14 on page 8.
1. WHITE – Parking Light Relay Output (Internal Relay Pin 30)
At its default seng, the WHITE wire supplies 12-Volt (+) or Ground (-) to the vehicle's park light wire based on the
connecon of the relay input (WHITE/RED wire).
Vericaon: The vehicle parking light wire registers 12-Volt (+) or Ground (-) when the park lights are turned on.
Note: This wire can be programmed to perform the Trunk Release Output funcon by changing its opons. Refer to
Bank 2, Feature 14 on page 8.
2. BLACK – Ground Input (-)
The BLACK wire connects to a reliable vehicle ground (-) source to power the system.
Vericaon: The vehicle ground (-) source wire registers ground (-) at all mes.
Note: Before making this connecon, remove all module fuses unl the system is completely connected.
5. WHITE/BLACK – Siren Output (+)
The WHITE/BLACK wire supplies 12-Volt (+) to power the siren. Aer mounng the siren, connect its BLACK wire to a
reliable ground source, and connect the BROWN wire to the siren’s RED wire.
