Sida 1/10

INSTRUCTIONS

Form 4037-018C

Visit www.GoPresto.com

10-quart

Kitchen Kettle

™

Deep Fryer/Multi

Cooker/Steamer

• Steams, stews, roasts, boils, deep fries and more.

• Large cooking surface for convenient browning.

• Nonstick nish, inside and out, for stick-free

cooking and easy cleaning.

• Fully immersible with the heat control removed.

This is a Listed appliance. The following important safeguards are recommended by most portable appliance manufacturers.

IMPORTANT SAFEGUARDS

To reduce the risk of personal injury or property damage when using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions.

2. To protect against electrical shock or burns, do not immerse heat control or magnetic cord in water or other liquid.

3. Be sure that handles and legs are assembled and fastened properly before using this appliance. See detailed assembly instructions

on page 2.

4. Be sure that handle is properly attached to basket and locked in place. See detailed assembly instructions on pages 2 and 3.

Failure to securely attach basket handle can result in release of basket during use which may result in severe burns.

5. Do not touch hot surfaces. Use handles or knobs.

6. Do not let children handle or put electrical cords or plugs in their mouths.

7. Close supervision is necessary when any appliance is used by or near children.

8. It is recommended that this appliance not be moved when it contains hot oil or other hot liquid. If it must be moved when it

contains hot oil or other hot liquid, use extreme caution.

9. Always attach heat control and magnetic cord to appliance first, then plug cord into the wall outlet. To disconnect heat control and

magnetic cord, turn control to OFF, remove plug from wall outlet, and then remove magnetic plug end from heat control. Allow

appliance to cool, then remove heat control from appliance.

10. Unplug from outlet and remove heat control from appliance when not in use and before cleaning. Allow appliance to cool before

putting on or taking off parts and before cleaning.

11. Do not operate any appliance with a damaged cord or plug or in the event the appliance malfunctions or has been damaged in

any manner. Return the appliance to the Presto Factory Service Department for examination, repair, or electrical or mechanical

adjustment.

12. The use of accessory attachments not recommended or sold by the appliance manufacturer may cause injuries. Use only genuine

Presto

accessories and replacement parts.

13. Do not let cord hang over edge of table or counter, or touch hot surfaces.

14. Do not place on or near a hot gas or electric burner, or in a heated oven.

Estas instrucciones también están disponibles en español.

Para obtener una copia impresa:

• Descargue en formato PDF en www.GoPresto.com/espanol.

• Envíe un correo electrónico a contact@GoPresto.com.

• Llame al 1-800-877-0441, oprima 2 y deje un mensaje.

15. Do not use outdoors.

16. Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS

THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY.

Important Cord Information

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to

fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a

qualified electrician. Do not attempt to modify the plug in any way.

A short detachable power supply cord is provided to reduce the risk of becoming entangled in or tripping over a longer cord. DO NOT

USE WITH AN EXTENSION CORD. Do not allow the cord to run underneath or around the appliance. The magnetic cord may not

detach easily if the cord is positioned in this fashion.

Connect the power supply cord to a 120VAC electrical outlet only.

How to Attach Legs and Handles

Tools Required: #2 Phillips screwdriver Parts Included: 4 legs, 2 handles

To Attach Legs to Base

1. Place the appliance upside down on the table or counter.

2. Using the screwdriver, remove the screws from the four mounting

projections on the bottom of the appliance and set aside. Use these screws

to attach the legs to the base.

3. Position one of the legs, rubber foot facing up, over one of the mounting

projections (Fig. A). Align the hole in the leg with the hole in the mounting

projection and fasten securely with the screw. The leg should not rock or

move if twisted.

NOTICE: Continuing to tighten, once secure, can result in the stripping of

screws or the cracking of legs.

4. Repeat step 3 for the other three legs.

5. Turn the appliance right side up on the table or counter. When properly assembled, the

appliance should sit level with no leg rock.

To Attach Handles to Base

1. Place the multi-cooker upside down on the table or counter.

2. Using the screwdriver, remove the screws from the tabs on each side of the base and

set aside. Use these screws to attach the handles to the base.

HINT: When removing the screw under the plug guard, hold the screwdriver at a

slight angle or use a short screwdriver or a screwdriver with a long shank.

3. Slide one of the handles, with the screw hole facing up, onto the tab so the hole on the

tab aligns with the hole on the handle

(Fig. A). Fasten securely with the screw. The handle should not wobble, but slight

movement from side to side is normal.

NOTICE: Continuing to tighten, once secure, can result in the stripping of screws or

the cracking of handles.

4. Repeat step 3 for the other handle.

5. Turn the appliance right side up on the table or counter. When properly installed, the

handles should be parallel with the table or counter.

How to Attach Basket Handle for Deep Frying and Blanching

NOTE: outside When using the basket for deep frying and blanching foods, position the basket handle of the basket.

1. Slide the lock bar up on the handle (Fig. B). Then squeeze the handle bars together and fit them into the bracket guides. The pegs

should rest on the bracket tabs below the bracket guides (Fig. B).

2. After attaching the handle to the basket, slide the lock bar down (Fig. C) to the locked position to ensure against accidental

detachment of the handle from the basket.

Leg

Mounting

projection

Screw

Rubber foot

Handle

Tab

Screw

hole

Fig. A

Plug guard

Fig. B

Lock bar

Bracket

guide

Peg

Bracket

tab

Fig. C

Lock bar

How to Attach Basket Handle for Steaming

NOTE: inside When using the basket for steaming foods, position basket handle towards the of the basket.

1. Slide the lock bar up on the handle. With

the handle , facing the inside of the basket

squeeze the handle bars together and fit

them into the bracket guides. The pegs

should rest on the bracket tabs below the

bracket guides (Fig. D).

2. After attaching the handle to the basket,

slide the lock bar down until it touches the

top of the drain hook (Fig. E). This is the

locked position and will ensure against

accidental detachment of the handle from

the basket.

Before First Use

This versatile appliance braises, steams, boils,

blanches, deep fries and more. It is also great

for making soups, stews, and desserts. Before

using the appliance for the first time, become

familiar with the various parts (Fig. F), read the

instructions carefully, and wash it according to

the Care and Cleaning instructions on page 4.

CAUTION! This appliance is not intended to melt

wax, gels, plastics, or other materials for making

candles or for other hobbyist activities or in any

commercial or business application.

Using this appliance for purposes different from

those specified in the instruction manual may

cause damage to the appliance and will void the

warranty.

How to Use

NOTICE: Avoid using no-stick cooking sprays

as they may cause the cooking surface to become tacky. In addition, use heat-

resistant nylon, silicone, wooden, or rubber utensils to turn, stir, or remove food

when not using the steam/fry basket. Do not use metal utensils as they may

scratch the nonstick surface.

1. Place the appliance on a dry, level, heat-resistant surface away from the wall

and the edge of the surface. Do not let the cord hang or drape over the edge

of the counter or table within reach of children. Remove the cover from the

appliance.

NOTICE: To prevent possible heat damage to your countertop, place a

heat-resistant counter protector, such as aluminum foil, under the appliance.

To keep the appliance from moving on the counter, do not place any portion

of the foil under the legs.

2. Insert the heat control probe into the appliance so the two electrical pins on

the appliance are fully inserted into the heat control.

Then attach the magnetic cord to the heat control by aligning the magnetic

plug end with the two electrical pins located on the back of the heat control

(Fig. G).

Due to the fact the magnetic plug end is polarized, it is intended to be

attached to the heat control only one way. The printed patent information on the plug end should be facing up. The cautionary

language should be facing the counter. When properly aligned and positioned correctly, the plug end will magnetically attach itself

to the heat control.

Fig. D

Fig. E

Lock bar

Bracket guide

Peg

Bracket

tab

Drain

hook

Control Master

heat control

Basket handle

Steam/fry basket

Tempered

glass cover

Nonstick surface

inside and out

Magnetic

cord

Cover handle

Fig. F

Drain hook

Fig. G: Control Master

heat control

Probe

Indicator light

Heat selector

Magnetic

cord

Heat control

Magnetic plug end

Electrical pins

To assure the continued accuracy of the Control

Master

heat control, avoid rough handling during

use and storage. Store it in a clean, dry location away

from metal objects. Always check the magnetic plug

end of the cord before use to assure metal items have

not become attached.

Produktspecifikationer

Varumärke:	Presto
Kategori:	Multispis
Modell:	10-quart Kitchen Kettle XL
Ångkokning:	Ja
Kapacitet:	9.4 l
Produktens färg:	Svart, silver
Kontrolltyp:	Rotations-
Effekt:	1800 W
AC-inspänning:	120 V
Diskvattensäkra delar:	Ja
Teflonbehandlad:	Ja
Frityrfunktion:	Ja
Kokfunktion:	Ja
Fisk:	Ja
Stuvning:	Ja
