PRIER Products, Inc.

4515 E 139th St.

Grandview, MO 64030

800-362-9055 Fax: 800-362-1463

www.PRIER.com

Installation, Operation & Maintenance Instructions for the

PRIER C-144/244 Diamond Series Freezeless Wall Hydrant

*Please leave this sheet for the property homeowner*

Thank you for purchasing the PRIER C-144/244 Diamond Series Freezeless Wall Hydrant, the nest quality freezeless

wall hydrant available. Your C-144/244 will provide you years of dependable service with little or no maintenance.

Installation:

Installation procedures may vary slightly depending on the seat option purchased and the installation inlet options. PRIER

freezeless wall hydrants are available with the following inlet options:

1. Determine the location for the installation of the hydrant. The valve must be installed into a heated area of the struc-

ture that will not drop below freezing. Ensure there is adequate work room in the interior of the structure for securing

the hydrant to the plumbing piping. Bore the whole size listed above through the wall in the desired position for the

installation.

2. All freezeless wall hydrants require a slight downward pitch to aid the draining process of the hydrant once the prod-

uct is turned to the “off” position. PRIER has machined an appropriate pitch into the casted backange to assist and

ensure that a proper drainage pitch results after installation.

3. Position the spout of the hydrant in the downward position. From the interior of the structure, utilize the spout aligning

mark on the seat. When the mark is pointed down, the spout is oriented in the proper position on the outside of the

structure.

4. If you are planning to solder the connection (D, S or F style seats), be certain the hydrant is in the fully open position

to prevent seat damage from the heat.

5. Connect the water supply piping to the freezeless wall hydrant as desired. With a closed-end hose on the valve creat-

ing back pressure, test the installation for leakage.

6. After the water supply connection is made, secure the hydrant to the structure using appropriate screws through the

two mounting holes on the casted back ange.

Operation:

Operation of the C-144/244 Diamond Series Freezeless Wall Hydrant is a simple process. Water ows through the

hydrant after turning the handle (or operating key for the C-244 style) counter-clockwise to the “on” position. Turn off the

hydrant by turning the handle clockwise to the “off” position.

The hydrant will drain for a few moments. If the dripping persists after a few moments, tighten the handle slightly until the

dripping stops. Be careful not to overtighten the hydrant.

The C-144/244 incorporates an integral atmospheric anti-siphon vacuum breaker that, in the rare occurrence of a back

siphonage, opens to the atmosphere preventing contamination of the water supply.

As well as an atmospheric vacuum breaker, the C-144/244 incorporates a backow preventer that operates as a check

valve in the rare case that water is forced backwards into the valve. The backow preventer has been tested to 125 PSI

pressure.

*ALWAYS REMOVE HOSE DURING FREEZING TEMPERATURES*

*INTENDED FOR IRRIGATION USE AND OUTDOOR WATERING*

Maintenance:

The PRIER C-144/244 series freezeless wall hydrant leaves the factory fully air tested and operational. It is treated with

an FDA approved lubrication. The hydrant requires no scheduled maintenance to provide long life.

D1/2” MIP x 1/2” SWT Bore 1” Hole

S1/2” SWT x 3/4” Push-On Bore 1” Hole

X1/2” Crimp PEX Bore 1” Hole

W1/2” Wirsbo

®

PEX Bore 1” Hole

C 1/2” CPVC Bore 1” Hole

T3/4” MIP x 1/2” FIP Bore 1 1/8” Hole

F3/4” MIP x 3/4” SWT Bore 1 1/8” Hole

FX3/4” Crimp PEX Bore 1 1/8” Hole

FW3/4” Wirsbo

®

PEX Bore 1 1/8” Hole
