INSTRUCTIONS FOR USE
Pro-Ject AD Box S2 Phono
© Pro-Ject Audio Systems · Pro-Ject AD Box S2 Phono · Revision 9. . 201 10 07
2
Dear music lover,
thank you for purchasing this AD Bo
AD Bo
AD Bo
AD BoAD Box S
x S
x S
x Sx S2
2
2
2 2 Pho
Pho
Pho
PhoPhono
no
no
nono from P -Ject Audio Systems. ro
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
Make all connections whilst the phono amplifier is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked red, the
left channel black or white.
Do not connect the phono amplifiers output to a phono input (sometimes labelled gra
gra
gra
gragram
m
m
mm disc
disc
disc
discdisc RIAA
RIAA
RIAA
RIAARIAA, or )
on the amplifier.
Never use any other power supply than the one supplied with the unit.
Connecting the record player or a line level source
Connect the tonearm signal lead to the sockets of the phono amplifier. The earthing wire of the
Phono
Phono
Phono
Phono Phono In
In
In
InIn
tonearm signal lead may be connected to the screw terminal if you encounter hum problems when using the
record player. The signal lead of a line level source has to be connected to the socket .
Line
Line
Line
Line Line In
In
In
InIn
Setting the cartridge mode
The phono amplifier can be used in either MM (for moving magnet and high-output MC cartridges) or MC (for
low-output MC cartridges) mode according to the construction principle of the pickup cartridge to be used.
Since most cartridges use the MM principle the phono amplifier is factory set to operate in this mode. To find
out which type your cartridge is please consult the literature accompanying your cartridge. If in doubt please
consult your dealer.
A switch at the back of the phono amplifier sets the correct level of amplification for the cartridge.
Before setting MM / MC mode the unit must be disconnected from the power supply and amplifier.
Connection to the amplifier
Connect the of the phono amplifier to a line input (such as
Out
Out
Out
OutOut AUX
AUX
AUX
AUXAUX, CD
CD
CD
CDCD, Tuner
Tuner
Tuner
TunerTuner, Tape
Tape
Tape
TapeTape or Vide
Vide
Vide
VideVideo
o
o
oo) on your
amplifier.
© Pro-Ject Audio Systems · Pro-Ject AD Box S2 Phono · Revision 9. . 201 10 07
3
Mains power connection
Connect the low voltage plug from the power supply to the socket of the phono amplifier
Power
Power
Power
Power Power 5
5
5
55V
V
V
V V DC
DC
DC
DCDC
before connecting the power supply to the mains.
Front panel controls
To switch on from standby or to standby
The push button on the left hand side will toggle the phono amplifier between its fully operational status and
standby. The blue LED above the stand-by push button shows that the unit is switched on.
Input selector
Press the push button next to the two LEDs to switch between the inputs (record player) and (line level
1
1
1
11 2
2
2
22
source). The selected input will be shown by the corresponding LED on the front panel.
Setting the record level
In case of distorted playback of the recorded music, the level of the analogue signal going to the
A/D converter can be reduced with the level control ( ) on the front panel.
G
G
G
GGain
ain
ain
ainain
Connecting to a Computer
Connect the USB-output of the unit to a free USB-socket on your computer and turn it on/make sure it is
powered on.
The “new hardware found assistant“ will automatically detect the unit and announces it as a Mic
Mic
Mic
MicMicrophone
rophone
rophone
rophone rophone US
US
US
USUSB
B
B
B B
au
au
au
auaud
d
d
ddio
io
io
ioio c
c
c
c cod
od
od
odode
e
e
eec
c
c
cc. There is no need to install a driver manually.
After installation, one setting has to be done. For example - Windows 7
®
operating system:
→ → → → → → Control Panel Sound Recording
Mi
Mi
Mi
MiMicrophone
crophone
crophone
crophone crophone USB Audio CODEC
USB Audio CODEC
USB Audio CODEC
USB Audio CODECUSB Audio CODEC Properties
Advanced: set to
2
2
2
22 chann
chann
chann
chann channel, 16 bit, 48000
el, 16 bit, 48000
el, 16 bit, 48000
el, 16 bit, 48000el, 16 bit, 48000 Hz (DVD Qualit
Hz (DVD Qualit
Hz (DVD Qualit
Hz (DVD Qualit Hz (DVD Quality)
y)
y)
y)y)
Please note: Connection should be made to an USB-socket of your computer directly. Connecting to
USB-hubs or switches can cause problems.
Recording Programme
In case you do not have a recording programme installed on your computer, you may download one free from
the Internet. Recording programmes can be found easily on internet.
In the menu of the recording programme, source or input may have to be set to M
M
M
MMi
i
i
iicr
cr
cr
crcro
o
o
oop
p
p
pph
h
h
hho
o
o
oon
n
n
nne
e
e
ee U
U
U
U US
S
S
SSB
B
B
B B au
au
au
auaud
d
d
ddio
io
io
ioio c
c
c
c co
o
o
ood
d
d
dde
e
e
eec
c
c
cc.
Please be aware that downloads from the Internet are made entirely at your own risk. Under no
circumstances can Pro-Ject Audio Systems carry responsibility or provide support for third-party
software products sourced from the internet or for any damage or problems arising from the use
thereof. All downloads should be checked with an up- -date anti-virus programme. License fees may to
be applicable.
